Qleen PROFI II Quick Manual

1. Connection water and power
1.1 The water input (Fig. 1) can be connected as follows:
• With the Gardena adapter via a Gardena hose to the house water connection and
• Then open the water inlet of the house water connection
• Remove the Gardena adapter and connect the suction hose to the machine and sink the side with the
filter into the water tank
1.2 Connect the mains plug (Fig. 1) supply to the power socket
1.3 Unroll the hose to the required length and connect the connection for the black hose (Fig. 1) to the reel
1.4 Switch on the machine with
1.5 If the battery indicator (Fig. 5) shows red
see Chapter 9. Charging the battery
Suction hose for
cleaning solution
Water input
1
2. Bleeding
2.1 Open the bleeding tap (Fig. 1)
2.2 Switch on with the key
2.3 Switch on with the key
2.4 Place the suction hose for the cleaning solution (Fig. 1) into the cleaning solution tank
2.5 Set the dosing pump regulator (Fig. 2) to 100%
2.6 Switch on with the key
2.7 Switch off with the key
2.8 Attach the hose to the rod and brush bow or ROTAQLEEN, connect cable for the ROTAQLEEN to the
ROTAQLEEN socket (Fig. 1) and the ROTAQLEEN.
2.9 The machine is ready for operation
3. Cleaning with pure water
3.1 Switch on the machine with the key
3.2 After a short time, the clean water arrives at the nozzles via the blue hose
4. Cleaning with cleaning solution
4.1 Switch on the machine with the key
dosing pump controller (Fig. 2) is set to 0 % and must be turned up
4.2 After a short time, the cleaning agent solution arrives at the nozzles via the black hose
Quick Guide PROFI II
button lights green
red
Connections
Connection for
the black hose
Water flow regulator
black hose
Bleeding tap
ROTAQLEEN socket
Mains plug
(off ⇒ green green) and wait until water comes evenly from the vent hose under the machine
(green green ⇒ off)
(off ⇒ green green/turquoise turquoise) and wait until the key
(green green ⇒ off)
(off ⇒ green
(off ⇒ green
green for battery operation and turquoise
and the machine does not start, the battery must be charged,
Control buttons and dosing pump regulator
line water
2
green)
green), if the key
turquoise for mains operation.
Cleaning solution/
line water
Pure/
Power switch Dosiung pump regulator
lights up green green
should light up turquoise turquoise
(turquoise turquoise ⇒ green green)
ROTAQLEEN
direction
continuously
the
