Parts List
• (A) 1 x Fabric
• (B) 4 x Top Corners
• (C) 4 x Bottom Corners
• (D) 8 x Bolts
• (E) 8 x Nuts
• (F) 8 x Washers
• (G) 4 x Screws
Pipes
• (H) 2 x Long Frame Pipes
• (I) 2 x Short Frame Pipes
• (J) 4 x Leg Pipes
• (K) 2 x Long Rods
• (L) 2 x Short Rods
Tools Required
• Flat Surface To Work On
• Phillips Head Screwdriver
• Adjustable Wrench or Pliers
• Optional: Rubber Mallet
*Do not use power tools.
Assembly Instructions
