INT500
EN
Testing the fuse
TEST
TEST
TEST
0
• Remove the test leads before testing the fuse.
• If the display reading is FUSE, the fuse is bad and should be
replaced.
Specifications
General Specifications
Display Count : 4000 counts.
Overrange display : " >OL Reading " or " >-OL Reading "
Conversion Rate : 2 times / second
Dimensions (W x H x D) : 96mm x207mm x 54mm with holster
Weight : 630g including battery.
Power requirement : AA size ALKALINE Battery * 4
Batteries Life : 1.5 AA ALKALINE battery
Resistance Measurements : Tester can perform at least
2600 earth-bond resistance measurements with new alkaline
batteries at room temperature. These are standard tests of 1Ω
with a duty cycle of 5 seconds on and 25 seconds off.
22
