KONA Electric.
Emergency Response Guide.
Hyundai Premium Roadside Support.
1800 186 306
WARNING
•
If severe damage causes high-voltage components to become exposed, emergency responders should take appropriate precautions
and wear appropriate insulated personal protective equipment.
•
Do not attempt to remove the safety plug while standing in the water.
•
Never cut or disconnect the high-voltage orange cabling and connectors without first disabling the system by removing the safety plug.
•
Exposed cables or wires may be visible inside or outside the vehicle. Never touch the wires, cables, connectors, or any electric
components before disabling the system, to prevent injury or death due to electrical shock.
Failure to follow any of these instructions may result in serious injury or death by electrocution.
•
Do not cut through any component of the Airbag (SRS) system (Supplementary Restraint System).
•
SRS components may remain powered and active for up to 3 minutes after the 12V electrical system is shut off or disabled.
Disconnect the battery negative cable and wait for at least 3 minutes before beginning work.
Failure to follow any of these instructions may result in serious injury or death from accidental deployment of the airbag system.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KONA Electric and is the answer not in the manual?

Questions and answers

Related Manuals for Hyundai KONA Electric

Summary of Contents for Hyundai KONA Electric

  • Page 1 KONA Electric. Emergency Response Guide. Hyundai Premium Roadside Support. 1800 186 306 WARNING • If severe damage causes high-voltage components to become exposed, emergency responders should take appropriate precautions and wear appropriate insulated personal protective equipment. • Do not attempt to remove the safety plug while standing in the water.

  • Page 2: Table Of Contents

    Contents. 1. Identification/Recognition 2. Immobilisation/Stabilisation/Lifting 3. Disable direct hazards/Safety regulations 4. Access to the occupants 5. Stored energy/Liquid/Gases/Solids 6. In case of fire 7. In case of submersion 8. Towing/Transportation/Storage 9. Important additional information...

  • Page 3: Identification/Recognition

    1. Identification/Recognition. Initial response: Identify, Immobilise and Disable The following procedures should be used whenever you are dealing with a KONA EV at an emergency scene. However, all operations should be consistent with your department’s standard operating procedures, guidelines, and any applicable laws.
  • Page 4 1.1 Identifying a Hyundai KONA EV 1.1 Identifying a Hyundai KONA EV 1.1 Identifying a Hyundai KONA EV The Hyundai KONA EV can be easily identified by the exterior design. KONA EV KONA EV The Hyundai KONA EV can be easily identified by the exterior design.
  • Page 5 1 1 . . � � I I d d e e n n t t i i f f i i c c a a t t i i o o n n / / r r e e c c o o g g n n i i t t i i o o n n 1.1 Identifying a Hyundai KONA EV 1.1 Identifying a Hyundai KONA EV...

  • Page 6: Immobilisation/Stabilisation/Lifting

    2. Immobilisation/stabilisation/lifting 2. Immobilisation/stabilisation/lifting 2. Immobilisation/Stabilisation/Lifting. 2.1 Immobilisation 2.1 Immobilisation The next step is to immobilise the vehicle to prevent any accidental movement that can The next step is to immobilise the vehicle to prevent any accidental movement that can endanger response personnel or civilians.

  • Page 7: Disable Direct Hazards/Safety Regulations

    3. Disable direct hazards/Safety regulations. 3. Disable direct hazards/safety regulations The final step in the initial response process, conducted after immobilising the vehicle, is to disable the vehicle, its SRS components and the high-voltage electrical system. To prevent The final step in the initial response process, conducted after immobilising the vehicle, is to disable the vehicle, its SRS current flow through the system, use the following procedure to disable the vehicle.
  • Page 8 3. Disable direct hazards/safety regulations 3. Disable direct hazards/Safety regulations. Without depressing the brake pedal P P r r e e s s s s i i n n g g B B u u t t t t o o n n � � V V e e h h i i c c l l e e �...
  • Page 9 3. Disable direct hazards/Safety regulations. 3. Disable direct hazards/safety regulations 3. Disable direct hazards/safety regulations 3. Disable direct hazards/safety regulations c. Remove the fuse box cover in the engine compartment. c. Remove the fuse box cover in the engine compartment. Remove the fuse box cover in the engine compartment.

  • Page 10: Access To The Occupants

    4. Access to the occupants 4. Access to the occupants. 4.1 Extraction operations The KONA EV is an electric model. Because of the high-voltage components contained therein, first responders should pay special attention when they extract occupants in the car. 4.1 Extraction operations Before performing any extraction operations, the first responders should "Identify, The KONA EV is an electric model.
  • Page 11 4. Access to the occupants. 4. Access to the occupants 4.4 Location of ultra-high strength steel In the below images, high strength steel is used in the areas coloured in blue and ultra-high 4.4 Location of ultra-high strength steel strength steel is used in the red coloured areas. Depending on the tools used, ultra-high In the below images, high strength steel is used in the areas coloured in blue and ultra-high strength steel is used in the red strength steel can be challenging or impossible to cut.
  • Page 12 4. Access to the occupants. 4. Access to the occupants 4.5 Occupants rescue guide 4.5 Occupants rescue guide When dealing with an emergency situation, check the components as below. When dealing with an emergency situation, check the components as below. Supplemental Restraint System Airbag Airbag Gas Inflators...

  • Page 13: Stored Energy/Liquid/Gases/Solids

    5. Stored energy/Liquid/Gases/Solids. 5. Stored energy/liquid/gases/solids 5.1 High-voltage system 5.1 High-voltage system Supplies electric energy to traction motor and High-voltage battery stores generated electric energy. Supplies electric energy to traction motor and stores generated High-voltage battery electric energy. High-voltage Supplies electricity from battery to the inverter, LDC, Junction box (FRT, RR) air conditioner compressor, etc.
  • Page 14 5. Stored energy/Liquid/Gases/Solids. 5. Stored energy/liquid/gases/solids 5.1 High-voltage system 5.1 High-voltage system High-voltage battery The HV Lithium-ion battery supplies and stores electric energy, to the traction motor, and is High-voltage battery located under the KONA EV chassis. The HV Lithium-ion battery supplies and stores electric energy, to the traction motor, and is located under the KONA EV chassis.
  • Page 15 5. Stored energy/Liquid/Gases/Solids. 5. Stored energy/liquid/gases/solids 5.2 High-voltage orange cabling The high-voltage cabling is orange, per Society of Automotive Engineers (SAE) standards. 5.2 High-voltage orange cabling Cables run under the floor of the vehicle and connect the high-voltage battery to the ICCU, motor, A/C compressor and other high-voltage components located towards the front and The high-voltage cabling is orange, per Society of Automotive Engineers (SAE) standards.

  • Page 16: In Case Of Fire

    6. In case of fire. 6.1 Firefighting operations Strict precautions must be taken while conducting firefighting operations due to following reasons: • Lithium-ion batteries contain electrolytes that can vent, ignite, and produce sparks when subjected to temperatures above 300°F/149°C. • Vehicle may burn rapidly with a flare-burning effect.
  • Page 17 6. In case of fire 6. In case of fire. 6.3 How to deal with the situation Extinguish the fire with a large amount of water. Fire Don’t use seawater or salt water, as it can generate a toxic vapor or cause the re-ignition. 6.3 How to deal with the situation Disconnecting 12V Battery (+) terminal, Damaged...
  • Page 18 6. In case of fire. 6.3.2 High-voltage battery damage and fluid leaks If electrolyte solution leakage, or any damage to the lithium-ion battery casing is observed, the first responders should attempt to neutralise the battery by applying a large volume of water to the battery pack while wearing appropriate Personal Protective Equipment (PPE).
  • Page 19 6. In case of fire. 6.4 High-voltage battery re-ignition by stranded energy Damaged cells in the high-voltage battery can experience thermal runaway* and re-ignition. To prevent re-ignition, the first responder and second responder need to be aware of the risk of stranded energy* which remains in the damaged cells and lead to re-ignition.

  • Page 20: In Case Of Submersion

    7. In case of submersion. 7.1 Submerged or partially submerged vehicles Some emergency responses can involve a submerged vehicle. A KONA EV that is submerged does not have high-voltage components on the vehicle’s body or framework. It is safe to touch the vehicle’s body or framework if there is no severe damage to the vehicle, whether it is in water or on land.

  • Page 21: Towing/Transportation/Storage

    If emergency towing is necessary, we recommend having it done from towing a conventional electric vehicle. If emergency towing is necessary, we by an authorised Hyundai dealer or a commercial tow-truck service. Proper lifting and towing procedures are necessary to If emergency towing is necessary, we recommend having it done by an authorised prevent damage to the vehicle.
  • Page 22 8. Towing/transportation/storage 8. Towing/transportation/storage 8.2 Storage of damaged vehicle with the damaged battery 8.2 Storage of damaged vehicle with the damaged battery • Drain fluids and water, then disconnect the negative (-) terminal of the 12V battery before • Drain fluids and water, then disconnect the negative (-) terminal of the 12V battery before 8.
  • Page 23 • To store the damaged battery safely, the battery must be discharged. • If the battery can be removed from the vehicle, discharge the battery to prevent re-ignition. • Place the battery into a sufficiently large container and add water until the battery is 8.

  • Page 24: Important Additional Information

    9. Important additional information 9. Important additional information. 9.1 Emergency starting Jump starting 9.1 Emergency starting Do not attempt to jump start the high-voltage battery, as it cannot be jump started. In case of full discharge of the high-voltage battery, the vehicle must be towed as mentioned on the Jump starting previous page.
  • Page 25 9. Important additional information. 9. Important additional information 9.2 Airbag system (SRS: Supplemental Restraint System) 9.2 Airbag system (SRS: Supplemental Restraint System) Airbag Six airbags are installed in the KONA EV, located in the areas shown in the image below. Airbag Before performing any emergency procedure, make sure the vehicle ignition switch is turned Six airbags are installed in the KONA EV, located in the areas shown in the image below.
  • Page 26 9. Important additional information. 9. Important additional information Airbag system components Airbag system components 1.� Driver’s� front� airbag 8.� Front� Impact� Sensor 1. Driver’s front airbag 8. Front Impact Sensor 2.� Passenger’s� front� airbag 9.� Side� Impact� Sensor 2. Passenger’s front airbag 9.
  • Page 27 9. Important additional information. 9. Important additional information Seat belt system Seat belt system 1. Front Seatbelt Pretensioner 1.� Front� Seatbelt� Pretensioner 2. Emergency Fastening Device 3. Rear Seatbelt Pretensioner 2.� Emergency� Fastening� Device 3.� Rear� Seatbelt� Pretensioner Undeployed airbags CAUTION Undeployed Airbags To avoid injuries caused by accidental deployment of undeployed airbags:...
  • Page 28 Australia or may be optional. To the extent permitted by law, neither HMC nor HMCA shall be liable to any person as a result of reliance on the content of this brochure. Please consult your Hyundai Dealer for the latest specifications, equipment levels, options, prices, colours and vehicle Hyundai Motor Company Australia availability.
