prox.pad
System Installer Guide
This equipment is designed to be installed and serviced by security and lock industry profes-
sionals. More comprehensive information is supplied in the prox.pad plus Installation/Program-
ming Manual (located on the CD-ROM).
Service Company, Put Contact Information Here:
Company Name:
Service Number:
Access system programming: This access system possesses serial communications capability and can be man-
aged as part of an overall access control system with Hub Manager Professional
for system requirements.
Optional Keypad Programming: The prox.pad plus unit can be programmed manually using the keypad on each
unit and without the use of a personal computer (PC) and software. This manual contains the optional keypad pro-
gramming instructions. Keypad programming can be helpful to get a door or doors up and running prior to having
the availability of the host computer. In all cases, the personal computer programming options supersede the key-
pad programming options.
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate the equipment.
Part No. 6045679, Rev. 1.2, D5b
TM
plus Access
15.21 Information to User
1
TM
software. See the inside cover

Advertisement

loading
Need help?

Need help?

Do you have a question about the prox.pad plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for International Electronics prox.pad plus

Summary of Contents for International Electronics prox.pad plus

  • Page 1 See the inside cover for system requirements. Optional Keypad Programming: The prox.pad plus unit can be programmed manually using the keypad on each unit and without the use of a personal computer (PC) and software. This manual contains the optional keypad pro- gramming instructions.
  • Page 2 Prox.pad plus Access System Installer Guide Access system programming - System Requirements • Hub Manager Professional access control software version 5 or higher (part number HUBSWR includes software installation instructions) PC Hardware Requirements • IBM-compatible Pentium-class computer • 30MB available hard disk space •...
  • Page 3 IEI access systems. The prox.pad plus unit is unique in that no separate controller is needed and there is no need to run cables from a reader to a control. The unit is self-contained and includes built in HID proximity and IEI keypad readers as well as the controller.
  • Page 4 NOTE: Use with IEI Secured Series™ (Hub, Hub Max, Hub MiniMax) Networks—The RS 485 network characteristics for the prox.pad plus unit are different than those of IEI’s Secured Series access systems. This means the prox.pad plus unit can operate in the same system as Secured Series controllers but not on the same physical network.
  • Page 5 Prox.pad plus Access System Installer Guide prox.pad plus Wiring Connection Overview Figure 1 below illustrates the Pin connectors on the prox.pad plus main circuit board; the ta- ble on page 7 describes the four Pin connectors (P1, P2, P4, and P5) in detail. Specifica- tions are listed on page 23.

  • Page 6: Default Settings

    Prox.pad plus Access System Installer Guide IEI-Supplied Parts/Optional Items Quantity Description Keypad/control unit assembly, with Prox Sensor, Backplate, hex socket screw Filler Piece/REX Button Press to Exit Label Wall Anchors Mounting Screws Antenna Backplate for remote mounting Silicone Rubber “dogbone”...
  • Page 7 Prox.pad plus Access System Installer Guide prox.pad plus Pin Connectors Pin Connector (on main Description/Use circuit board) Wire Color GRAY Main Relay, Normally Closed (N.C.) P1 (5-pin connector, top GREEN Main Relay, Normally Open (N.O.) left-most location) BLUE Main Relay, Common...
  • Page 8 Prox.pad plus Access System Installer Guide Performing a Secure Installation (keypad/controller away from antenna) In this configuration, the prox.pad plus keypad/controller antenna housing is removed from the keypad/controller and located a maximum of 10 feet away. The controller/keypad is located inside a secure area.
  • Page 9 Prox.pad plus Access System Installer Guide Mount the antenna backplate in a vertical orientation and secure it to the wall through the two screw holes using two IEI-provided screws. Ensure that the two “weep holes” (drainage holes), provided to remove possible moisture, are positioned on the bottom.
  • Page 10 Prox.pad plus Access System Installer Guide Removing/Inserting Circuit Boards If it proves necessary to remove or insert the main circuit board from/into the prox.pad plus controller/keypad, follow the steps below. Disconnect the back housing of the prox.pad plus unit from the front keypad/controller.
  • Page 11 Prox.pad plus Access System Installer Guide ORANGE DOOR CONTACT (Normally Closed) WHITE Figure 4 Wiring the Door Contact Input TO ALARM PANEL DOOR CONTACT GOING BACK TO ALARM BLUE ( C ) PANEL TO ALARM PANEL ORANGE GREEN (N/O) DEDICATED DOOR...
  • Page 12 Prox.pad plus Access System Installer Guide TO POWER SUPPLY BLUE ORANGE GREEN (NO) DEDICATED DOOR CONTACT (NC) BEING MONITORED BY THE prox.pad unit WHITE Figure 6 Wiring the Aux Relay for Forced Door Alarm TO POWER SUPPLY BLUE ORANGE GREEN...
  • Page 13 Wiring the REX Switch (Request to Exit) The prox.pad plus unit can be wired to monitor a remote switching device, which is intended to be installed on the “safe” side of a door. The Request to Exit (REX) switch is a momentary input closure that engages the main relay for the same length of time for which the main relay is programmed.
  • Page 14 Electric Strike (Fail Secure) wiring diagram, Figure 10 a MagLock (Fail Safe) wiring diagram. Power for the prox.pad plus unit must be from a minimum 10-15 volt DC linear, filtered and regulated power supply. It is typical for the chosen power supply to power BOTH the prox.pad plus unit and the selected locking device.
  • Page 15 Prox.pad plus Access System Installer Guide MAGLOCK (FAIL SAFE) POWER SUPPLY BLACK (V-) BLUE (MAIN RELAY C) GRAY (MAIN RELAY N/C) (V + IN) Figure 10 MagLock (Fail Safe) Wiring Diagram Part No. 6045679, Rev. 1.2, D5b...
  • Page 16 COM (serial) port or over a computer network to manage the system using Hub Man- ager Professional (v 5 or higher) software. To connect the prox.pad plus unit to a computer COM port (which is RS-232), an RS-232 to RS-485 converter is required. To connect the prox.pad plus unit via a computer network, the IEI Gateway device is required.
  • Page 17 For multiple door applications, the prox.pad plus can be networked together. When network- ing prox.pad plus devices together on an RS-485 system, the prox.pad plus units are all wired in parallel. This networking capability is available when connecting directly to your personal computer’s COM port or when communicating over a computer network with the IEI Gateway.

  • Page 18: Program Commands

    Prox.pad plus Access System Installer Guide Program Commands In addition to personal computer (PC) programming, the prox.pad plus unit can be pro- grammed manually using the keypad on each unit and without the use of a personal com- puter and software. Keypad programming can be helpful to get a door or doors up and run- ning prior to having the availability of the host computer.
  • Page 19 Prox.pad plus Access System Installer Guide Program Commands (continued) Action Desired Press Details 6a. Print programmed 25 # 0 # 0# ** user list 6b. Print programmed 25 # 0 # start user # ** user list (starting at a certain user) 7.
  • Page 20 Prox.pad plus Access System Installer Guide Program Commands (continued) Action Press Details ttt=forced door time, to nearest 10’s seconds, 14. Set forced door 45 # ttt # 0 # ** entered as 00-990 (00 output time latches it); default=10 secs 15.
  • Page 21 Prox.pad plus Access System Installer Guide Program Commands (continued) Action Press Details 58 # start user # start user # number of users 22. Delete block of * number of users * consecutive users This command must be 23. Dump transactions...
  • Page 22 Prox.pad plus Access System Installer Guide Led Indicators/Sounder Operations Visual/Audible LED or Sounder Description Condition Yellow LED Slow blink Unit is in Program mode Verify mode is active (checking that the last two Rapid blink values in sequence match) Steady Program error;...
  • Page 23 Prox.pad plus Access System Installer Guide prox.pad plus Specifications ELECTRICAL Power Supply/Current 10-15 VDC, linear filtered and regulated power supply Requirements 500 mA (not including locking device or peripherals) WIRING ALPHA 1174C (22AWG) 4-wire, stranded (this is required Remote Antenna Cable...
  • Page 24 Prox.pad plus Access System Installer Guide All 26-bit HID card, including the following: ProxCard II, COMPATIBLE PROXIMITY IsoProx II, Duo Prox II, and Proxkey FOB; 26-bit cards are CARDS required for manual or batch programming UNIT CAPACITY 2,000 users maximum; each user can have a card/tag, a...
  • Page 25 Prox.pad plus Access System Installer Guide This page is left blank intentionally. Part No. 6045679, Rev. 1.2, D5b...
  • Page 26 Prox.pad plus Access System Installer Guide This page is left blank intentionally. Part No. 6045679, Rev. 1.2, D5b...
  • Page 27 Prox.pad plus Access System Installer Guide This page is left blank intentionally. Part No. 6045679, Rev. 1.2, D5b...

  • Page 28: Questions Or Problems

    Prox.pad plus Access System Installer Guide Questions or Problems If you have any questions about initial prox.pad plus programming or operation, or encounter any installation problems, contact your prox.pad plus dealer or distributor. The complete Installation/Programming Reference manual is contained on the supplied CD-ROM.
