SAFETY
Read and understand these installation instructions for safe and proper installation. Installation requires the lifting and moving of individual kiln sections.
Personnel capable of lifting and managing the moving process must be used. If you have any questions please contact Evenheat Kiln at 989-856-2281 or at
evenheat-kiln.com.
Kilns are as safe as any other electrical appliance when used under normal and proper operating conditions. To create and maintain this safe environment
observe all installation and safety precautions.
Warning Symbol Descriptions
Warning symbols are used throughout these installation instructions. These symbols alert the installation personnel to certain hazards and important
information. Pictured below are symbols used along with a description of each.
The Exclamation Point alerts you to particular cautions, hazards and information.
The Lightning Bolt alerts you to specific information regarding the risk of electric shock.
Electric shock may result in injury or death.
Emergency Shut Off Provision
The kilns power supply connection (plug/receptacle, breaker or disconnect) acts as the emergency electrical power shut off. Access to these
devises should be unobstructed and safe at all times.
All electrical installations for direct wired models (those without a plug/receptacle connection) must include a power disconnect near the kiln and that
is easily accessible and safe for emergency power shutoff.
Electrical Safety
A licensed electrician should be used for all electrical installation and service. All applicable local, state and federal electrical codes must be
followed.
Use correct voltage, wire size and fuse or breakers. Kiln electrical requirements are located on the kiln nameplate. Make sure all electrical connections
are tight. Avoid using aluminum wire.
Always use the proper electrical receptacle. Never alter the kiln cordset or cordset plug. Alterations can be dangerous. Alterations will void any
warranties along with nullifying any Listing Agency markings.
Evenheat recommends that a voltage check be performed before placing the kiln into service, ideally before actual purchase. Operating
voltage varies, with common operating voltages being 208V and 240V. The kilns operating voltage (printed on the kilns nameplate) must
match the applied voltage (actual electrical service voltage). If it does not, do not install or operate the kiln as potential electrical and fire
hazards exist. Contact Evenheat for guidance in such cases.
The kiln must be properly grounded.
Unplug or disconnect the kiln from the electrical service before accessing the chamber for servicing or vacuuming. Do not attempt to touch
or replace the heating elements while the kiln is plugged in or connected to the electrical service. Electric shock may result in serious injury
or death.
Never, ever use an extension cord to operate a kiln.
Kiln Location Safety
The best location for the kiln is a concrete floor. If not available, the kiln must be placed on a minimum of 2" of masonry extending at least 12" beyond
the outside perimeter of the kiln.
Do not place or use kiln on combustible surface.
Glass Kiln
General Operation Manual
March 2021
Page 1 of 5
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Evenheat Glass Kiln GTS 18
Summary of Contents for Evenheat Glass Kiln GTS 18
- Page 1 Read and understand these installation instructions for safe and proper installation. Installation requires the lifting and moving of individual kiln sections. Personnel capable of lifting and managing the moving process must be used. If you have any questions please contact Evenheat Kiln at 989-856-2281 or at evenheat-kiln.com.
- Page 2 General Operation Manual March 2021 Place only on the metal stand provided by Evenheat Kiln, Inc. The surface on which the kiln is placed shall be capable of safely supporting the combined weight of the kiln, kiln load and any operating personnel.
- Page 3 Replace any worn, damaged or defective parts immediately with Evenheat Kiln replacement parts only. Discontinue use until parts are replaced. When vacuuming the kiln use only HEPA filters on the vacuum. Prolonged expose to brick dust and other refractory materials can cause lung injury.
- Page 4 While holding the worm-gear clamp securely with a pair of pliers or channel locks, use a 5/16” socket to tighten each worm-gear. Snug is good, do not overtighten. Evenheat recommends that these clamps be checked for tightness after each of the first three firings and then after every other third firing. Page 4 of 5...
-
Page 5: This Warranty Does Not Cover
ARRANTY Evenheat Kiln, Inc. guarantees to the original purchaser that for a period of two full years (1 year for Superwool lids) from the date of purchase the kiln will be free of defects in workmanship and materials when used under normal and proper operating conditions. Evenheat will replace or repair any defective part as specified.. - Page 6 GTS 18 Kiln Stand Assembly Instructions Step 1: Step 2: A. Position the 4 frame angles to form a square as shown A. Position legs as shown B. Bolt holes positioned as shown B. Insert all bolts through bolt holes - total of 16 bolts C.
- Page 7 GTS 23 Stand Assembly Instructions North American Model June 2019 The glass kiln manual included with your kiln includes kiln stand assembly instructions for many models. However, if you have purchased model GTS 23 please use the updated assembly instructions shown below. GTS 23 Stand Parts Include: 27”...
- Page 8 GTS 23 Stand Assembly Instructions North American Model June 2019 Step 2: Place all stand legs as shown below. Please note that the 2 Dyna-Lift Ready legs are placed, on one side, at the center positions. See image for guidance. Position these 2 legs so the single square hole is to the inside of the frame.
- Page 9 GTS 23 Stand Assembly Instructions North American Model June 2019 Step 4: Install the trusses as shown below. Finger tighten and place plastic feet on each leg. Step 5: Turn the stand over and tighten all bolts. You will have 4 nuts and bolts left over. Don’t throw these away. These nuts and bolts are provided for attaching the Dyna-Lift lid lift assist. If you are not installing the Dyna-Lift we suggest that you insert these extra nuts and bolts to the 2 Dyna-Lift Ready legs.
- Page 10 GTS 23 Stand Assembly Instructions North American Model June 2019 Step 6: If you have purchased a Dyna-Lift this is the point where you’ll attach it to the kiln stand. Please refer to the Dyna-Lift instructions for specific steps. If you have not purchased a Dyna-Lift for your new GTS 23 you may want to consider it. The Dyna-Lift lightens the force needed to operate the kiln lid. It does so with ease and grace and with no negative effects upon the kiln itself.
- Page 11 GTS 2541 / GTS 41 Stand Assembly Instructions North American Model Jan 2024 The glass kiln manual included with your kiln includes kiln stand assembly instructions for many models. However, if you have purchased model GTS 2541 or GTS 41 please use the updated assembly instructions shown below. GTS 2541 / GTS 41 Stand Parts Include: 30.5”...
- Page 12 GTS 2541 / GTS 41 Stand Assembly Instructions North American Model Jan 2024 Step 2: Place all stand legs as shown below. Please note that the 2 Dyna-Lift Ready legs are placed, on one side, at the center positions of the long, 36.5” stand sections.
- Page 13 GTS 2541 / GTS 41 Stand Assembly Instructions North American Model Jan 2024 Step 4: Install the trusses as shown below. Finger tighten and place plastic feet on each leg. Step 5: Turn the stand over and tighten all bolts. You will have 4 nuts and bolts left over.
- Page 14 GTS 2541 / GTS 41 Stand Assembly Instructions North American Model Jan 2024 Step 6: If you have purchased a Dyna-Lift this is the point where you’ll attach it to the kiln stand. Please refer to the Dyna-Lift instructions for specific steps. If you have not purchased a Dyna-Lift for your new GTS 2541 you may want to consider it (The GTS 41 does not use a Dyna-Lift).
