Stand Assembly & Kiln Placement
Statement of Use - Overview of Salt Bath Operation
The salt bath heat treating process involves heating solid heat treating salts to a given temperature which causes them to liquefy by heat (become molten). These
salts are contained within a vessel that is commonly known as a salt pot. Once the salts become molten, and at the desired heat treat temperature, steel work-pieces
(blades, receivers, tools, etc.) are immersed into the molten salts and are allowed to remain there for the desired time period. Once the desired time period has
elapsed, the work-pieces are removed from the molten salt to undergo further processing as necessary.
Advantages of the salt bath heat treat process include a heat treat environment that is absent of oxygen. Oxygen oxidizes and decarburizes steel when taken to
temperature: neither effect is generally preferred in the finished product. Also a salt bath, by its nature, tends to offer phenomenal temperature distribution
throughout the work piece.
