Cusack-Music STEREO PEDAL TAMER Quick Start Manual

Connect LOOP RETURN from output(s)
of guitar pedal.
Connect to the next
device in your chain with
the OUTPUT.
Tap the footswitch to
engage/bypass the
LOOP. Hold the switch
for momentary.
POP STOP
If you are getting a pop when engaging/bypassing the
loop, you can move the internal jumpers to move the
"Pop Stop" circuit. (see image below)
• TB (top two posts) puts the Pop Stop on the loop
return, leaving the loop true bypass
• Putting the jumper on the bottom two posts puts the
Pop Stop in the audio path. It won't be true bypass,
but may reduce pops.
• You can remove the jumper altogether to remove
Pop Stop.
STEREO
PEDAL TAMER
Connect LOOP SEND to
input(s) of guitar pedal.
TECH SPECS
• Soft switch relay
• Latching operation with quick tap
Hold for momentary operation
• Standard 9v DC center negative power supply
• Current Draw ~5mA
• 5" x 3.85" x 1.9" (L x D x H)
Cusack Music
514 Lincoln Ave
Holland, MI 49423
CUSACKMUSIC.COM
Manufactured in
Holland, Michigan, USA
Power with a standard 9V
DC, center-negative power
supply. Current draw ~5mA
Connect an INPUT signal
here. You can connect a:
1) stereo signal using both
inputs
2) single mono path using
the BLUE input
3) split mono using the
RED input. Mono signal will
be sent to both both RED
and BLUE signal paths.
