Connect an EXPression pedal with a TRS
plug. This can control any one parame-
ter per preset. To configure, see next
page.
Use PAR.1 and PAR.2 to control
parameters of selected program. See
program parameters on next page.
CASCADE sets whether signal
is added to reverb signal after
EXTEND is engaged. To the
right, new signal cascades
into EXTEND. To the left, new
signal is dry.
DECAY adjusts the time
that the reverb signal
decays. Set low for a short
dwell, or high for large
ambiance.
LEVEL adjusts the
output volume.
BYPASS
Tap
to
engage/disengage
the
effect. In Preset (startup)
mode, this engages the left
preset.
To cycle through preset banks, tap
BYPASS-left and EXTEND. There are
four banks: red, green, blue, and
pink. Each BANK can store a preset
for the left and right footswitches,
for a total of eight possible presets.
Power with a standard 9V DC
center-negative power supply.
Current draw ~85mA
[R] OUT
EXP
INTERNAL
SELECT
EXTEND
sets
DECAY
time
maximum for long,
lush ambiance. LED
above will blink when
engaged.
For a mono output signal, use [L] OUT. For a stereo output
signal use both [R] and [L] OUT. Use INTERNAL SELECT
switch to select [R] OUT function. See next page for details.
Connect INPUT signal
here. INPUT is mono.
[L] OUT
INPUT
the
to
Tap BYPASS to engage/disengage
the effect. In Preset (startup) mode,
this engages the right preset.
To enter LIVE mode, hold EXTEND
and BYPASS-right for two seconds.
LIVE mode disables preset mode, all
knobs function in their physically set
positions. Center LED will alternate
white.
Cusack Music
514 Lincoln Ave
Holland, MI 49423
CUSACKMUSIC.COM
Manufactured in
Holland, Michigan, USA
Use the numbered knob to
select the desired reverb
PROGRAM. See next page
for details.
TRAILS sets how the reverb
decays when the pedal is
bypassed.
Set right, the
reverb trail decays naturally
when effect is bypassed. Set
left, the reverb cuts off
when bypassed.
MIX controls the wet and
dry balance. Left is dry,
right is wet.
SAVE
PRESET,
To
hold
BYPASS-left and BYPASS-right.
See next page for details.
Advertisement
Table of Contents
Related Manuals for Cusack-Music RESOUND
Summary of Contents for Cusack-Music RESOUND
- Page 1 Cusack Music 514 Lincoln Ave Holland, MI 49423 CUSACKMUSIC.COM Manufactured in Holland, Michigan, USA For a mono output signal, use [L] OUT. For a stereo output Power with a standard 9V DC Connect an EXPression pedal with a TRS signal use both [R] and [L] OUT. Use INTERNAL SELECT center-negative power supply.
- Page 2 Thank you for purchasing a Resound Reverb! We designed the Resound with simplicity in mind so you'll spend more time playing and less time reading the manual. On your way to learning the pedal, you’ll find a few hidden features it is capable of such as the ability to: change the Extend level by toggling the switch, carry trails between like program presets on a shared bank, or summon Shimurmur by the Extend even when the parameters of the program are turned off.
