Summary of Contents for ACIQ SC-12WGLD-HP230
- Page 1 HIGH-WALL DUCTLESS AIR CONDITIONING & HEATING SYSTEM OWNER’S MANUAL Models: SC-09WGLD-HP230 SC-09ZGLD-HP230 SC-12ZGLD-HP230 SC-12WGLD-HP230 SC-18ZGLD-HP230 SC-18WGLD-HP230 SC-24WGLD-HP230 SC-24ZGLD-HP230 SC-30ZGLD-HP230 SC-30WGLD-HP230 SC-36ZGLD-HP230 SC-36WGLD-HP230...
-
Page 2: Table Of Contents
Table of Contents Introduction ......... . . 2 Safety Precautions . -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Please read the following before operation. Recognize safety information. This is the safety-alert symbol. When you see this symbol on the unit and in instructions or manuals, be alert to the potential for personal injury. Understand these signal words: DANGER, WARNING, and CAUTION. These words are used with the safety-alert symbol. - Page 4 : SET TEMP Front Panel Display The front panel on the ACiQ indoor unit contains system status lights and a modern, easy-to-read LED display. NOTE: The indoor unit display panel can be turned ON or OFF via the LIGHT button...
-
Page 5: Installation Schematic
INSTALLATION SCHEMATIC Indoor unit Air inlet Air outlet Installation Components* 1. Front Panel 2. Aux. Button 3. Air Filter 4. Horizontal Louver 5. Remote Controller Wired Programmable Controller (not shown, sold separately) 6. Inter-Connecting Wire (sold separately) 7. Drain Hose (sold separately) 8. -
Page 6: System Functions
SYSTEM FUNCTIONS WHISPER QUIET Not only are the ACiQ systems energy efficient but they are quiet too. Our High-Wall units operate with sound pressure levels starting as low as 26 dB(A). MULTI FAN SPEEDS Whether operating in either Cooling or Heating mode, the indoor fan can be set to your choice of four different speeds (Low, Medium, High or Turbo) to achieve maximum comfort. - Page 7 Power interruptions are no problem for the ACiQ system. User selections and system parameters are stored in non-volatile memory. These parameters are retained during a power failure. When power is returned, the ACiQ system will automatically return to the last operating mode.
- Page 8 SYSTEM FUNCTIONS INTELLIGENT DEFROST The ACiQ Defrost function increases room comfort and saves energy by eliminating unnecessary defrost cycles. In heating mode, the unit will monitor the outdoor coil for frost build up. Once frost buildup has been detected, the system will switch into a defrost mode to remove the frost.
-
Page 9: Operation Of Wireless Remote Contoller
OPERATION OF WIRELESS REMOTE CONTROLLER Remote Controller Part Name 1. ON/OFF Button 2. Fan Button 3. Mode Button 4. Up Button 5. Swing Button 6. Turbo Button 7. Down Button 8. Temp Button 9. Sleep Button 10. I Feel Button 11. - Page 10 OPERATION OF WIRELESS REMOTE CONTROLLER REMOTE CONTROLLER OPERATIONS The wireless remote controller is sleek, versatile and allows you to change room temperatures and functions on your Stealthsystem from the palm of your hand. The large LCD display and buttons make it easy-to-understand and easy-to-use. The remote controller is set from factory to display temperatures in °F.
- Page 11 OPERATION OF WIRELESS REMOTE CONTROLLER VERTICAL SWING LOUVERS • Press the Vertical Swing Louver button to select five different vertical (up & down) air discharge directions including Continuous Sweep. The Swing Louver icon will be displayed. Press this button to set swing angle, which changes in direction as below: Swing Louver Display Indicates louver swings up and down in the five directions, as shown.
- Page 12 OPERATION OF WIRELESS REMOTE CONTROLLER MODE BUTTON : AUTO Use the “MODE” button to select one of the available modes. : COOL The selected mode will be displayed on the remote controller and : DRY the appropriate light will illuminate on the front display panel. : FAN ONLY AUTO –...
- Page 13 OPERATION OF WIRELESS REMOTE CONTROLLER TIMER SETTING Timer-ON / Timer-OFF BUTTON To set when you want the unit to turn On at the end of a selected time period, use the button labeled “Timer-ON /Timer-OFF”on the remote controller. Press this button to make the clock icon disappear, replaced with the word “ON”...
- Page 14 • When Auto is selected, the unit will select the proper fan speed automatically, according to the ambient temperature. Fan Display NOTE: Turbo function is not available in Dry and Auto Modes. The ACiQ unit will select proper fan speed automatically according to ambient temperature. CLOCK SETTING Press this button to set clock time.“...
- Page 15 OPERATION OF WIRELESS REMOTE CONTROLLER SLEEP MODE The ACiQ system will automatically adjust room temperature during your sleep time. This slight change in temperature will not affect your comfort level due to the natural effects that sleeping has on the body, but it will save on energy consumption and will lower your electric bill.
- Page 16 OPERATION OF WIRELESS REMOTE CONTROLLER DIY MODE - SLEEP 3 You will be required to enter eight (8) room setpoint values for eight (8) hours of run time. The last room setpoint value will be maintained until sleep mode is cancelled. In Sleep Mode 3, press "Prog"...
- Page 17 DAMAGED OR LOST REMOTE CONTROLLER If remote controller is lost or damaged, the ACiQ system can be turned off directly from the indoor unit. Lift the front panel of the indoor wall unit, then press the AUX button to turn on or turn off. When the unit is on, it will operate in AUTO Mode.
-
Page 18: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE/SOLUTION System does not restart. Cause: The system has a built-in three-minute delay to prevent short and/or rapid cycling of the compressor. Solution: Wait three minutes for the protection delay to expire. Indoor unit emits unpleasant odor Cause: Typically unpleasant odors are the result of mold or mildew forming on when started. - Page 19 TROUBLESHOOTING PROBLEM CAUSE/SOLUTION Water leaking from the indoor Cause: While it is normal for the system to generate condensate water in cooling unit into the room. mode, it is designed to drain this water via a condensate drain system to a safe location. Solution: If water is leaking into the room, it may indicate one of the following.
-
Page 20: Care And Cleaning
CARE AND CLEANING W RNING Take notice of the following items before cleaning your Stealthindoor wall unit. • To avoid electric shock or injury, do not attempt to clean the unit unless it has been turned off and the indoor and outdoor units have been disconnected from the main power supply. •... -
Page 21: Energy Saving Tips
ENERGY SAVING TIPS 1. Reduce room setpoint at night: During the nighttime hours you don't require the same level of conscious cooling or heating. Try using Sleep Mode to gradually relax room temperature and allow the unit to run less and save energy. 2. - Page 22 ACiQ system. 4. Once the faulty part(s) are sent to ACiQ, they will be tested to ensure the issue is a result of a factory fault. If the part(s) are deemed faulty, the amount paid for the part will be reimbursed.
- Page 23 7. All ACiQ equipment must be operated following the equipment's designated owner's manual and cannot be misused. 8. All ACiQ equipment must have an intact faceplate with its specifications, model number, and serial number still legible. If the equipment is not in this condition, both the standard and extended warranties are void.
- Page 24 3. Class-Arbitration Waiver: Arbitration is handled on an individual basis and if a dispute is arbitrated, you and ACiQ expressly waive any right to participate as a class representative or class member on any class claim you may have against ACiQ or that ACiQ has against you.
