- Page 1 4871 Process Controller Supplemental Operating Instruction Manual...
- Page 2 USB Flash Drive which accompanied the controller. The 4871 Process Controller is a complex piece of equipment and will require some time to understand its capabilities. You must carefully read and understand the contents of this manual prior to the use of this equipment.
-
Page 3: Explanation Of Symbols
50 or 60 Hertz power supply without maintenance or servicing. affecting their operation or calibration. Current. Loads drawn from the back of the 4871 To avoid personal injury: must not exceed 5 amperes. 1. Do not use in the presence of flammable Thermocouple. -
Page 4: Environmental Conditions
The replacement of protective fuses and backup AA Storage: -25 °C to 65 °C; 10% to 85% relative size, 3.6 V battery for the 4871 Controller are humidity. the only internal maintenance procedures that should be performed by qualified personnel. -
Page 5: Controller Setup
CONTROLLER SETUP 1. Connect Ethernet cable from 4871 to PC 2. Identify the 6 digit order/project number on the paperwork. • The last two digits of the project/order number will identify the IP address of the 4871. Example: Order/Project Number: 912345 = IP address: 10.1.50.45... - Page 6 • In the left-hand column, click Change adapter settings. A new screen will open with a list of network connections. • Locate the Local Area Connection that is connected to the 4871. • Right click on this icon and go to Properties.
- Page 7 • Select it and click on “go online” . 8. SpecView main screen • SpecView should show the configured screen with proper values. It is a good idea to connect the reactor to the 4871 at this time to check readings.
