Amart Furniture TORELLI 48824 Assembly Instruction Manual

Coffee table
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
410mm
Imported by Amart Furniture Pty Ltd,Qld, Brisbane Australia
For any assistance with assembly or for missing parts, please phone
Amart Furniture, Customer Service Freecall 1800 351 084.
ASSEMBLY INSTRUCTION
TORELLI COFFEE TABLE
ITEM CODE - 48824
Imported by Amart Furniture Pty Ltd,Qld, Brisbane Australia
For any assistance with assembly or for missing parts, please phone
Amart Furniture, Customer Service Freecall 1800 351 084.
1000mm
1-8
600mm
Item Code: 48824

Advertisement

loading
Need help?

Need help?

Do you have a question about the TORELLI 48824 and is the answer not in the manual?

Questions and answers

Related Manuals for Amart Furniture TORELLI 48824

Summary of Contents for Amart Furniture TORELLI 48824

  • Page 1 ASSEMBLY INSTRUCTION TORELLI COFFEE TABLE ITEM CODE - 48824 Imported by Amart Furniture Pty Ltd,Qld, Brisbane Australia For any assistance with assembly or for missing parts, please phone Amart Furniture, Customer Service Freecall 1800 351 084. 1000mm 600mm 410mm Imported by Amart Furniture Pty Ltd,Qld, Brisbane Australia For any assistance with assembly or for missing parts, please phone Amart Furniture, Customer Service Freecall 1800 351 084.

  • Page 2: Pre-Assembly Preparation

    PRE-ASSEMBLY PREPARATION BEFORE YOU START 1. Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product. 2. Take care when lifting. Product should be assembled as near as possible to the point of use. 3. Ensure that you have all required contents for complete assembly. 4.
  • Page 3 EXPLODED EXAMPLE Item Code: 48824...
  • Page 4 CHECKLIST Rods 396mm x 4 Plate x 12 Hex Nut x 4 PART NUMBER DIMENSION 1000mm x 600mm x 8mm 500mm x 550mm x 5mm 38mm x 260mm 38mm x 190mm 38mm x 63mm 38mm x 120mm Chrome Feet Item Code: 48824...
  • Page 5 REQUIRED FOR STEP 1 Rods 400mm x 4 Attach the Rods to the aluminium plate on glass as shown. REQUIRED FOR STEP 2 Plate x 4 Insert the Tube over the Rods and follow by the hardware stated. Item Code: 48824...
  • Page 6 REQUIRED FOR STEP 3 Plate x 6 Place the glass and insert the Tube and hardware stated over the glass as shown REQUIRED FOR STEP 4 Plate x 3 Place the glass and insert the Tube and hardware stated over the glass as shown Item Code: 48824...
  • Page 7 REQUIRED FOR STEP 5 Hex Nut x 4 Insert the Tube over the Rods and follow by the hardware stated. Tighten all nuts, being careful not to over tighten. Now you can turn the assembled product upside down. Item Code: 48824...

  • Page 8: Care And Maintenance

    ASSEMBLY IS COMPLETE CARE AND MAINTENANCE If the glass is chipped or broken, stop using the product and consult the place of purchase. Do not drop, drag or strike glass. Do not sit or stand upon the glass surfaces. Do not place very hot or cold items on the glass unless adequately thick table mats are used to prevent such items coming in contact with the glass.
