Summary of Contents for Gaggenau DI250440
- Page 1 DI250440...
-
Page 3: Table Of Contents
en Table of contents Intended use Additional options Power Safety instructions Half load HygienePlus Before you switch ON the appliance Intensive Delivery extraDry Installation In daily use Operating the appliance Door lock Damage Programme data Disposal Aqua sensor Switching on the appliance Protection of the environment Remaining running time display Timer programming... -
Page 4: Intended Use
Intended use Intended use Safety instructions ▯ This appliance is intended for use in the This appliance may be used by children over home and domestic environments. the age of 8 years old and by persons with reduced physical, sensory or mental ▯... -
Page 5: Installation
Safety instructions ▯ If you cannot obtain any information from Installation the manufacturer, you must not install ▯ Following installation, ensure that the dishwasher above or below these the back of the dishwasher is not freely appliances. accessible (protection against contact ▯... -
Page 6: Door Lock
Safety instructions Childproof lock (door lock) Warning D o o r l o c k The description of the childproof lock is at Risk of injury! the back in the envelope. ▯ To prevent injuries, e.g. caused by * depending on model stumbling, open the dishwasher only briefly in order to load and unload the dishwasher. -
Page 7: Protection Of The Environment
Protection of the environment Protection of the environment Warning Risks to children! Both the packaging of new appliances and the old ▯ If fitted, use the childproof lock. An exact appliances themselves contain valuable raw materials description can be and recyclable materials. found in the back of the envelope. -
Page 8: Getting To Know Your Appliance
Getting to know your appliance Appliance interior Getting to know your appliance 1" Interior light * 1* Cutlery drawer Diagrams of the control panel and the interior of the 12 Top basket appliance can be found in the envelope at the front. 1: Upper spray arms Individual positions are referred to in the text. -
Page 9: Water Softening System/Special Salt
Water softening system/Special salt Water hardness table Water softening system/Special salt To ensure good washing results, the dishwasher requires soft water, i.e. containing low amounts of lime, otherwise white limescale will be deposited on the utensils and inner container. Tap water above 1.2 mmol/l must be softened. The water is softened with special salt (regeneration salt) in the water softening system of the dishwasher. -
Page 10: Detergents With Salt Component
Rinse aid Using detergents with salt component Rinse aid D e t e r g e n t s w i t h s a l t c o m p o n e n t If combined detergents with a salt component are used, salt can usually be omitted up to a water As soon as the rinse-aid refill indicator h is lit on hardness of 21°... -
Page 11: Setting Amount Of Rinse Aid
Utensils Setting amount of rinse aid Utensils The amount of rinse aid can be set from §:‹‹ to §:‹‡. Please set rinse aid on §:‹… to obtain very good drying results (§:‹… is already set in factory). Not suitable Do not change the amount of rinse aid unless streaks ▯... -
Page 12: Loading The Dishwasher
Utensils Loading the dishwasher Cups and glasses Top basket 12 Remove large food remnants. It is not necessary to prerinse utensils under running water. Place the utensils so that ‒ they are secure and cannot tip over. ‒ all utensils with their openings face down. ‒... -
Page 13: Pans
Utensils Pans Chopstick basket* C h o p s t i c k b a s k e t Bottom basket 1j *depending on the model Chopsticks up to a length of 24 cm can be placed in the chopstick basket. Note Chopsticks, which exceed the specified length, will block the spray arm during the rinsing process and... -
Page 14: Cutlery Drawer
Utensils Cutlery drawer Small accessories holder * S m a l l a c c e s s o r i e s h o l d e r Arrange the cutlery in the cutlery drawer 1* as * depending on model illustrated. -
Page 15: Detergent
Detergent Adding detergent Detergent If the detergent dispenser 9* is still closed, press the lock 92 to open the detergent You can use tablets as well as powder or liquid dispenser. detergents for dishwashers, but never use washing- Pour detergent into the dry detergent up liquid. -
Page 16: Combination Detergent
Detergent Combination detergent Notes ‒ You will obtain optimum rinsing and drying results Apart from conventional detergents (Solo), a number by using solo detergents and applying salt and of products are offered with additional functions. rinse aid separately. These products contain not only the detergent but also rinse-aid and salt replacement substances (3in1) ‒... -
Page 17: Overview Of Programmes
Overview of programmes Overview of programmes The max. possible number of programmes is illustrated in this overview. The corresponding programmes for your appliance can be found on the fascia. Type of utensils Type of soiling Programme Possible additional Programme sequence options pots and pans, non-sensi- Is optimised according to... -
Page 18: Additional Options
Additional options Additional options Operating the appliance * depending on model Programme data Additional options can be set with the buttons H. The programme data (consumption values) can be found in the summary of instructions. They refer to ¥ normal conditions and the water hardness set value •:‹…. -
Page 19: Remaining Running Time Display
Operating the appliance Remaining running time display Switching off automatically after the end of the programme * When the programme is selected, the remaining S w i t c h i n g o f f a u t o m a t i c a l l y a f t e r t h e e n d o f t h e p r o g r a m m e running time of the programme is indicated on the * depending on model digital display )". -
Page 20: Switching Off The Appliance
Operating the appliance Switching off the appliance Changing the programme When the START button P has been pressed, the Short time after the end of the programme: programme cannot be changed. Switch off ON/OFF switch (. The only way a programme can be changed is by Turn off the tap (not applicable if Aqua-Stop Cancel programme (Reset). -
Page 21: Cleaning And Maintenance
Cleaning and maintenance Special salt and rinse aid Cleaning and maintenance ▯ Check the refill indicators ` and h. If required, refill salt and/or rinse aid. A regular inspection and maintenance of your machine will help to prevent faults. This saves time and prevents problems. -
Page 22: Spray Arms
Fault, what to do? Spray arms Fault, what to do? Limescale and contaminants in the rinsing water may block nozzles and bearings on the spray arms 1: Experience has shown that you can rectify most faults and 1J. which occur in daily operation yourself. This ensures Check outlet nozzles on the spray arms that the machine is quickly available to you again. -
Page 23: Waste Water Pump
Fault, what to do? Check impeller wheel and remove any foreign Waste water pump objects. Large food remnants or foreign objects which were Place cover in the original position and press not captured by the filters may block the waste water down until it engages (click). -
Page 24: Fault Table
Fault, what to do? Fault table Fault Cause Remedial action “Check water supply” display X Supply hose kinked. Install supply hose without kinks. lights up. Tap turned off. Turn the tap on. Tap jammed or calcified. Turn the tap on. Flow rate must be min. - Page 25 Fault, what to do? Fault Cause Remedial action Refill indicator for salt ` and/or Refill indicator switched off. Activation/deactivation (see chapter Water sof- rinse-aid h is not lit. tening system/Special salt or Rinse aid). There is still enough special salt/rinse Check refill indicator, levels.
- Page 26 Fault, what to do? Fault Cause Remedial action Food remnants on the utensils. Utensils placed too closely together, Arrange utensils with adequate clearance utensils basket overfilled. between them ensuring that the spray jets can reach the surface of the utensils. Prevent con- tact points.
- Page 27 Fault, what to do? Fault Cause Remedial action White, stubborn coatings; limes- Detergent substances are deposited. Change detergent brand. cale on the utensils, container or These coatings cannot usually be Clean appliance mechanically. door. removed with chemicals (appliance cleaner, ...). Hardness range incorrectly set or water Set water softening system according to hardness greater than 8.9 mmol/l.
- Page 28 Fault, what to do? Fault Cause Remedial action Rust spots on the cutlery. Cutlery not adequately rust-resistant. Use corrosion-resistant cutlery. Knife blades are frequently more severely affected. Cutlery will also rust if rusting parts are Do not wash rusting parts. rinsed at the same time (pan handles, damaged utensil baskets, etc.).
-
Page 29: Customer Service
Customer service Customer service Installation and connection If you are unable to rectify the fault, please contact The dishwasher must be connected correctly, your customer service. We always find a suitable otherwise it will not function properly. solution, even to avoid unnecessary visits The specifications for the inlet and outlet as well as by technicians. -
Page 30: Delivery
Installation and connection Delivery Installation Your dishwasher has been checked thoroughly in the The required installation dimensions can be found in factory to ensure that it is in working order. This may the installation instructions. Level the appliance with cause small water stains. These will disappear after the aid of the height-adjustable feet. -
Page 31: Warm Water Connection
Installation and connection Warm water connection * Electrical connection W a r m w a t e r c o n n e c t i o n ▯ * depending on model Connect the appliance only to 200 V and 50 Hz or 60 Hz alternating current via The dishwasher can be connected to cold or hot water a correctly installed socket with protective... -
Page 32: Transportation
Installation and connection Transportation Protection against frost P r o t e c t i o n a g a i n s t f r o s t ( E m p t y i n g t h e a p p l i a n c e ) Empty the dishwasher and secure loose parts. - Page 34 *9001056515* 9001056515 (9801) 440MA...
