Summit Technology PowerSight PS3550 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
for
PowerSight
PS3550
Summit Technology, Inc.
2246 Monument Blvd
Pleasant Hill, CA 94523
Tel: 1-925-944-1212
support@powersight.com
www.powersight.com
Rev for FW 6.09 / SW 4.1J
Copyright 2022 by Summit Technology
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerSight PS3550 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Summit Technology PowerSight PS3550

Summary of Contents for Summit Technology PowerSight PS3550

  • Page 1 User’s Manual PowerSight PS3550 Summit Technology, Inc. 2246 Monument Blvd Pleasant Hill, CA 94523 Tel: 1-925-944-1212 support@powersight.com www.powersight.com Rev for FW 6.09 / SW 4.1J Copyright 2022 by Summit Technology...
  • Page 2 IEC61010-1:2001 for a 1000V input rating measurement category III, pollution degree II, double insulated electronic device. Model PS3550 is manufactured by Summit Technology, Inc in the U.S.A. The standard warranty period is 12 months from date of purchase. We encourage you to advise us of any defects of design or manufacture of any of our products.

  • Page 3: Table Of Contents

    Table of Contents Introducing PowerSight ............. 8 Connecting to PowerSight ............9 Voltage Test Leads ..................9 Current Probes ..................10 Connections to PowerSight ..............12 Introduction to Power Delivery Configurations ........ 14 Connecting to Single-phase Power ............16 Connecting to 120 V Outlet Adapter Box ..........17 Connecting to Multiple Single-phase Loads ........
  • Page 4 Measurement Types ..............52 Voltage Measurements ................52 Voltage Measurements in PowerSight ..........53 Voltage Measurements in PSM-A............55 Current Measurements ................56 Current Measurements in PowerSight ..........57 Current Measurements in PSM-A............59 Imbalance Measurements ............... 60 Imbalance Measurements in PSM-A ............ 61 Power Measurements ................
  • Page 5 Changing the Power Measurement Mode in PowerSight ....94 Changing the Power Measurement Mode in PSM-A ......94 Defining Inputs ..................94 Changing Input Ratios in PowerSight ..........96 Changing Input Ratios in PSM-A ............97 Voltage & Current Waveforms ..........98 Introduction ....................
  • Page 6 Setup Functions ..................139 Administrative Functions ..............140 Other Functions within PSM-A ..........142 Introduction ....................142 Remote Control of PowerSight ............142 Locating and Installing Software and Firmware ......143 Setting up Administrative Features of PowerSight via PSM-A ... 144 Putting it all Together (Monitoring for the First Time) ..

  • Page 8: Introducing Powersight

    Introducing PowerSight Congratulations on your decision to buy a PowerSight PS3550! The PS3550 is a complete upgrade of the previous PS3500. Some of the new benefits and features are:  New USB Communications  Faster Bluetooth Communications  Faster SD card transfers ...

  • Page 9: Connecting To Powersight

    Connecting to PowerSight Voltage Test Leads A Deluxe Voltage Probe set consisting of four leads is included with each PowerSight. Each of the voltage test leads is 6 feet (2 meters) long, with safety banana jacks at one end and safety plunger clamps at the other end.

  • Page 10: Current Probes

    Summit Technology also sells a fused voltage lead set (order DFV). The safety advantage of fused leads is that if a short occurs through the insulation of a lead to ground, the fuse in the handle should quickly blow out, preventing the lead from vaporizing in an explosion of molten metal.
  • Page 11 The HA5 offers two advantages over the HA1000, but these advantages come at a cost. Its advantages are that the HA5 is a very small size (5.25  2.00  1.35 inches) and second, it offers much greater sensitivity since it reads currents from 20 milliamps to 5 amps (as compared to the HA1000 measuring 1 - 1,000 amps).

  • Page 12: Connections To Powersight

    You must use added caution when connecting an FX series current probe around exposed conductors and bus bars since you must pull the tube around the conductor and thus get your hands and arms closer to it than when using HA series clamp-on type current probes.
  • Page 13 Current probes plug into the top end of PowerSight, just above the voltage inputs. Each current probe is labeled (I , or I ) and each jack is similarly labeled (I , or I ). When plugging a current probe into PowerSight, the flat side of the plug should be facing upwards so the label is readable.

  • Page 14: Introduction To Power Delivery Configurations

    120V, 240V, 480V, 600V, 4160V, or 12,500V. In most of the world, phase-to-phase service is usually supplied as 381V, 5,716V, or 11,431V. Summit Technology has voltage probes for direct connect to all of these services. Refer to...
  • Page 15 figure 7 for how to connect to a delta power service. When there is no access to measuring one of the currents, figure 8 presents the 2 current approach for measuring power. This approach is also useful for measurement of an open delta circuit as described in Connections to an Open Delta Circuit (2PT/3CT)figure Although phase-to-phase is the normal voltage measurement...

  • Page 16: Connecting To Single-Phase Power

    Connecting to Single-phase Power Figure 2 presents the basic connections to a single-phase system. sure to follow the safety warnings of the previous sections before making the connections. Clamp your phase 1 current probe onto the "Hot" wire. Make a metallic connection to neutral with the V voltage lead.

  • Page 17: Connecting To 120 V Outlet Adapter Box

    connections to PowerSight are as shown in figure 2, V will be some relatively large number like 120 volts and V will be a small voltage like 3 volts. If you then reverse the ground and neutral leads, V will now read slightly less, like 117 volts. If "hot" and "neutral"...

  • Page 18: Connecting To Multiple Single-Phase Loads

    Note: The 120ADPa is rated for continuous duty of up to 15 Arms. Do not exceed this continuous load. To evaluate the power usage of an appliance, simply plug the appliance into the top of the 120 V Outlet Adapter Box after the other connections have been made and verified.

  • Page 19: Connecting To Split-Phase (Two Phase) Power

    In this configuration, the voltage, current, and power of each load can be displayed directly or graphed on your PC using our PSM-A software. Connecting to Split-Phase (Two Phase) Power Fig 5 shows the recommended connections to a split-phase system as found in commercial and residential facilities, when measuring the supply to two single phase...

  • Page 20: Connecting To Three-Phase Four-Wire (Wye) Power

    change the measurement mode to phase-phase, V will be the hot-to-hot voltage that serves the high power appliance. Connecting to Three-Phase Four-Wire (Wye) Power Figure 6 presents the recommended connections to a three-phase system with voltages referenced to neutral, a "phase-neutral"...

  • Page 21: Connecting To Three-Phase Three-Wire (Delta) Power

    Connecting to Three-Phase Three-Wire (Delta) Power Figure 7 presents the recommended connections to a three-phase system with voltages referenced to each other instead of to neutral. This is a "delta", "phase- phase", or “three- phase three-wire” configuration. Be sure to follow the safety warnings of the previous...

  • Page 22: Connecting To Three-Phase Four-Wire Delta Power

    A variation of delta is “four-wire” (or “center-tapped”) delta (see figure 1D). In this configuration, if the main interest is in measuring phase-neutral voltage, then connect the neutral voltage to the neutral input for more accurate voltage readings Connecting to Three-Phase Four-Wire Delta Power Figure 6 presents the recommended connections to a three-phase delta system where a neutral is provided from the center of one of the phases.

  • Page 23: Connections Using 2 Current Approach

    Connections Using 2 Current Approach In the previous sections, the approach used to measure power has been based on determining the power of each phase and then summing them to get the total power. The 2 current approach (figure 8) allows you to determine the total power from...

  • Page 24: Connections To A 3 Ct / 3 Pt Metering Circuit

    this approach because he can save the cost of one current probe when buying a system in order to measure total power. Another motivation occurs in situations where one of the phases cannot be measured due to accessibility. This approach is also called the “2 wattmeter approach” because it mimics how two single-phase wattmeters can be used to measure total three-phase power.
  • Page 25  the voltage delivered to the load exceeds the 1000Vrms rating of PowerSight and you do not have other high voltage probes. A typical metering circuit showing PowerSight connected is shown in figure 9. This circuit has three CTs and, if higher voltage is present, may...
  • Page 26 5 amp range. The HA5 is best for this. The HA1000 or HA100 may be acceptable, depending on the current level. Once the current probes are attached, it is best to set the input ratios for each of the current probes (see the Setting Input Ratios section).

  • Page 27: Connections To A 2 Ct / 2 Pt Metering Circuit

    Connections to a 2 CT / 2 PT Metering Circuit Figure 10 shows recommended connections to a metering circuit with only 2 CTs or 2 PTs. This type of metering circuit may be preferable when cost is an issue (less instrument transformers are used) or when metering a delta...

  • Page 28: Connecting To Line-To-Dc (Ldc) Converter Accessory

    Connections to a 2CT / 2PT Metering Circuit section. For current connections, connect the phase 1 and phase 3 probes as shown in figure 10 and attach the phase 2 current probe to the phase 2 CT. You will not need to operate in the 2 Current Probe mode of power measurement since there are 3 currents being monitored.
  • Page 29 The LDC also comes with in- line fuse assemblies plugged into the stackable plugs. These red assemblies contain 1000V fuses. They provide protection if a short should occur in the LDC. The two voltage leads that would normally be plugged into PowerSight are plugged into the loose...

  • Page 30: Measuring Multiple Parallel Conductors

    red charging indicator near the jack will light up if everything is operating and connected properly. Note: If a fuse is burned out or missing, it will appear that there is no voltage at the source. Verify that the fuses are working properly before assuming that the source is dead.
  • Page 31 2. Start monitoring for 10 seconds or so and then stop monitoring (see the Starting Data Logging Stopping Data Logging sections). 3. Press the [Current] key and then the [More] key four times to view the average current for phase 1 (which is actually just one of the conductors of one of the phases).

  • Page 32: Measuring Currents Below The Range Of The Current Probe

    Measuring Currents Below the Range of the Current Probe A problem with measuring smaller currents arises when the current to be measured is below the range of the current probe. In such cases, the current may not be read or the reading may be inaccurate.

  • Page 33: Turning Powersight On

    Turning PowerSight On Connecting to Power Although PowerSight comes with Li-ion rechargeable batteries, those batteries are intended to keep PowerSight functioning during limited power failures and to allow quick measurements without the bother of always having to find a 120 Vrms source. When fully charged, the batteries can power the unit for up to 12 hours.

  • Page 34: Turning Powersight On

    (or when PowerSight is connected to the LDC4 or LDCm accessory). The internal batteries are not to be replaced by the user. Only batteries provided by Summit Technology are to be used in PowerSight. Turning PowerSight On...

  • Page 35: Communicating With Powersight

    Communicating with PowerSight Introduction The PS3550 uses Bluetooth wireless communications and USB to communicate with your PC. USB has been added for ease of use and quickly connecting to the PowerSight without the needing to pair to a PC. Although USB maybe easier, Bluetooth add a method that is safer.

  • Page 36: Connecting Via Bluetooth (Windows 7/8/10/11)

    PSM-A software and other information on getting the meter communicating with your computer. (Windows 7/8/10/11) Connecting Via Bluetooth With Windows 7/8/10/11, you will have to find a the small Bluetooth icon that shows up at the bottom right of your computer or go to the Devices screen by navigating to: Control Panel\Hardware and Sound\Devices and Printers.
  • Page 37 3. Select “Bluetooth” in the Add a Device Window 4. Double click on the meter you want to connect to 5. Either enter the Pairing code of “0000” or if asked if the PIN matches the meter, just press Connect.
  • Page 38 6. Once windows finishes, go back to the Bluetooth & other devices window and you should see your meter. On the right of the page (or at the bottom on some computers” find the blue link that says “more Bluetooth Options” and click on it.

  • Page 39: Connecting Via Usb Cable (Windows 7/8/10/11)

    8. Open up PSM-A and click on the “Click to Connect” button at the top middle of the screen. 9. Change the Serial Port to the one assigned by Bluetooth and press “Connect”. (Windows 7/8/10/11) Connecting Via USB cable To connect Via the USB port at the bottom of the PS3550 meter, you will need a USB cable that is capable of transferring Data (not the charge-only type cables).

  • Page 40: Using Removable Memory Cards

    Using Removable Memory Cards Introduction Your meter has adequate internal memory storage for most normal operating situations. However, the ability to use a removable memory card has several significant advantages: extra storage for very long monitoring sessions  faster transfer of data from meter to computer ...

  • Page 41: Downloading Data Via Memory Card

     Generally, any SD memory card that is from 64 MB through 32 GB in size will work in the meter. If it does not, the meter will display “Incompatible Format”.  The meter will not write over existing files and pictures on the memory card, so memory cards from cameras etc can be used when needed.
  • Page 42 4. Click on the folder with your meter’s serial number, you should then see 1 or more folders named by time & date in the format of “YrMoDy_HrMnSc”. These names are based on when the data inside was first started/created. For example, if you data log started on 10/13/2021 at 2:01:25 pm, you would have a folder with the name;...

  • Page 43: Verifying Connections Using Powersight (Surestart Tm )

    Verifying Connections Using PowerSight (SureStart Importance of Verifying Connections and Wiring After connecting to power, it is wise to check that everything is connected correctly and that the wiring of the facility is correct. There are two primary methods for doing this. You may either send waveforms from PowerSight to your PC and visually check that all connections are correct and all signal levels and shapes appear correct (see the...
  • Page 44 power will fall 33% and the power factor of each phase will become .12, .92, and .80.  Current probe not fully connected to PowerSight. The current probe connector needs to be fully seated within its socket. If it is not, the reading may be 0 (resulting in a loss of about 1/3 of the power of a three-phase system), the probe may be misidentified (resulting in current readings of a fraction or a multiple of the correct value), or the display may say “I...

  • Page 45: Identifying The Power System

    The SureStart feature briefly reports its findings in four groups of information. These are:  Identify System – after analyzing all the voltage and current inputs, PowerSight identifies what type of system is connected.  Error Summary – after analyzing connections, the number of possible errors detected is displayed, appearing for one second, each 6 seconds.

  • Page 46: Error Summary

    The bottom line of the display tells the specific voltage type of the general system that has been detected. For instance, a typical display is “277 / 480 V (p-n, p-p)”. This means the nominal voltages present are 277 Vrms phase-neutral and 480 Vrms phase-phase.
  • Page 47 probes are connected correctly, PowerSight will report that the current probes are rotated left one position. Although assuming that the voltage connections are not rotated identifies the phases incorrectly, the total power will be correct and the individual readings will be correct. The phases will be mislabeled. Another thing to consider is that in some cases, several possible explanations for the same error are listed as separate errors.

  • Page 48: Checking Connections Using Psm-A

     Two inputs have the same phase angle. The identified probes are of the same phase, but have different magnitudes. Check that the system is correct.  Non-standard phase angle. The phase angle between the identified phases is incorrect for the identified system. Check the system.

  • Page 49: Checking Voltage/Current Levels - Using Psm-A

    Checking Voltage/Current Levels – Using PSM-A Once you have downloaded a waveform using PSM-A, open it and then Check the boxes of which signals you would like to view. For checkout, first click the “V” icon and make sure all 3 phases of voltage are checked.

  • Page 50: Checking I Phase Sequence - Using Psm-A

    If you notice any issues, make your changes and then take another waveform. Do not start your monitoring session unit you are comfortable with your connections. Checking I Phase Sequence – Using PSM-A While still viewing all current waveforms of a three-phase system, notice how they reach their peak value.
  • Page 51 current. It should be close to the same. If one current leads voltage and the other two currents lag voltage by different amounts, then two of the voltage or current probes are probably switched. If the delays are the same for all phases, but they are more than 90 degrees, then the current probes are probably not...

  • Page 52: Measurement Types

    Measurement Types Voltage Measurements Voltage is the difference in electromotive potential between two points. Simply stated, it is the force that generates current flow and to measure voltage, two points of connection are required. In AC circuits, this force, measured in volts, usually varies continuously and always reverses direction.

  • Page 53: Voltage Measurements In Powersight

    When measuring DC volts the RMS value is the same as the DC value. Voltage crest factor is the ratio of peak voltage of a cycle over the  Vpk Vrms RMS voltage of the same cycle. . A perfect sine wave has a crest factor of 1.414 ( Maximum, minimum, and average voltage in power measurements refers to the maximum, minimum, and average of...
  • Page 54 For instance, if the average voltage between V and V is desired, press: [Voltage] (to display ) V , [Voltage] (to display V [More...] (to display maximum V ), [More...] (to display minimum ), and then [More...] (to display average V ).

  • Page 55: Voltage Measurements In Psm-A

    The total harmonic distortion (THD) of voltages is displayed using the THD function, discussed later in this chapter. Voltage Measurements in PSM-A The consumption data log can record maximum, minimum, and average RMS voltage for each phase for each logging period. The summary values at the top of the screen are the maximum, minimum, and average of all the values shown on the screen.

  • Page 56: Current Measurements

    The measurements of voltage presented on PowerSight can also be displayed in PSM-A by using the remote control feature. In addition our ReportWriter software will present maximum, minimum, and average voltage of each phase during any one or two intervals of time set by the user. If two time intervals are chosen, it will report the percent change and the actual change between the two intervals.

  • Page 57: Current Measurements In Powersight

    A measure that changes continuously is of limited use. A far more useful measurement is RMS current, wherein a single number is generated to describe a continuously varying current. The beauty of RMS current is that in power calculations, it makes a contribution to power roughly equivalent to a DC current of the same magnitude.
  • Page 58 For instance, if the average current of Phase 3 is desired, press: [Current] (to display I ), [Current] (to display I ), [Current] (to display I ), [More...] (to display maximum I ), [More...] (to display minimum I ), and then [More...] (to display average I ).

  • Page 59: Current Measurements In Psm-A

    section on Setting Measurement Modes. Remember that you need to have a DC current probe in order to read DC current. The total harmonic distortion (THD) of currents is displayed using the THD function, discussed later in this chapter. Current Measurements in PSM-A The consumption data log can record maximum, minimum, and average RMS current for each phase for each logging period.

  • Page 60: Imbalance Measurements

    The total harmonic distortion (THD) and K factor of currents is displayed using the THD function, discussed later in this chapter. Imbalance Measurements In a perfectly balanced three phase system, the voltages are of equal magnitude and the currents of the three phases are of equal magnitude.

  • Page 61: Imbalance Measurements In Psm-A

    Imbalance Measurements in PSM-A PSM-A performs imbalance calculations on both the voltage and current of a waveform set. To view the imbalance measurement, open a waveform set in PSM-A and then click on the phasor diagram icon. The imbalance measurements appear to the left of the phasor diagram.

  • Page 62: Power Measurements In Powersight

    Apparent power is defined as the sum of the products of the RMS currents and their associated RMS voltages:              In other words, if you measure the RMS voltage (measured in volts) and the RMS current (measured in amps) and multiply them together, you get the apparent power (measured in VA).

  • Page 63: Power Measurements In Psm-A

    For instance, if the maximum reactive power is desired, press: [Power] (to display watts), [Power] (to display VAR), and then [More...] (to display maximum reactive power). After showing the total VAR, a summary of each phase’s true power and VA power are shown.

  • Page 64: Power Factor Measurements

    voltage and current were recorded. If all phases are displayed, only the total true power is displayed at the top right. If a harmonic analysis of a phase is displayed, the true power of that phase is also displayed. If trending data is being recorded and in phase-phase voltage measurement mode, the average true power and average apparent power of each phase will be displayed and recorded.
  • Page 65 True power factor, as its name implies, is the true measurement of power factor. It is the ratio of true power over apparent power:   true ). When this ratio is less than 1.00, then reactive power is present. Reactive power may be the result of current lagging voltage due to the inductance of the circuit.

  • Page 66: True Power Factor Measurements In Powersight

    power. Typically all four power factor measurements are similar in magnitude. Displacement power factor can be determined for each phase. Terms for these measures are:    There is no such thing as total displacement power factor. Typically the displacement power factors of each phase are similar in magnitude.
  • Page 67 The maximum, minimum, and average power factors of the most recent monitoring session are displayed by repeatedly pressing [More...] after displaying the appropriate power factor. For instance, if the average power factor of Phase 3 is desired, press: [Power Factor] (to display PF ), [Power Factor] (to display ), [Power Factor] (to display PF ), [More...] (to display...
  • Page 68 In this way, by combining the [Power Factor] and [More...] keys, there are 16 true power factor measurements available. The display of true power factor gives an indication if current may be leading or lagging voltage. For instance, if current lags voltage in phase 1, the display will read "(V )".

  • Page 69: Displacement P.f. And Phase Measurements In Powersight

    Displacement P.F. and Phase Measurements in PowerSight PowerSight performs all commonly desired displacement power factor measurements. The displacement power factors of phases 1, 2, and 3 can be displayed. To view displacement power factor, press [Power Factor]. If the display says “Displacement P.F.”, then pressing [Power Factor] repeatedly will allow you to view the displacement power factors of phases 1, 2, and 3.

  • Page 70: Power Factor And Phase Measurements In Psm-A

    In this way, by combining the [Power Factor] and [More...] keys, there are 6 displacement power factor and phase angle measurements available. The display of power factor tells you if current is leading or lagging voltage. For instance, if current lags voltage in phase 1, the display will read "( V )".

  • Page 71: Energy Measurements

    In addition our ReportWriter software will present maximum, minimum, and average true power factor of each phase and of the total power factor during any one or two intervals of time set by the user. If two time intervals are chosen, it will report the percent change and the actual change between the two intervals.

  • Page 72: Energy Measurements In Powersight

    The estimated energy consumed per hour is the total energy consumed, divided by the hours of monitoring. For instance, if 5 KWH is consumed over a 10 minute period, then the estimated    energy consumed per hour is est hr The estimated energy consumed per year is the total energy consumed, divided by the fraction of a year that monitoring has...

  • Page 73: Energy Measurements In Psm-A

    Energy Measurements in PSM-A PSM-A presents all commonly desired energy measurements. When displaying a data log containing power information, PSM-A will graph the energy consumed over any interval. The user can choose to graph real energy use (KWH) or reactive energy use (KVARH).

  • Page 74: Cost Measurements In Powersight

    Useful measurements and estimates of cost are:  Cost of energy consumed (elapsed cost)  Estimated cost per hour  Estimated cost per month  Estimated cost per year The cost of energy consumed is the actual cost of energy consumed during a period of time such as since monitoring started or during a specific week.

  • Page 75: Cost Measurements In Psm-A

    These estimates are available by repeatedly pressing [More...] after displaying the cost measure. For instance, if the estimated cost per year is desired, press: [Cost] (to display total cost incurred during monitoring), [More...] (to display $ / hour), [More...] (to display $ / month), and then [More...] (to display $ / year).

  • Page 76: Demand Period Measurements

    Demand Period Measurements Utilities typically evaluate energy usage over fixed increments of time, such as 15-minute intervals. These time intervals are called “demand periods.” The average power consumed during each demand period is called the “demand” of that period. Typically, the utility will look for the demand period with the greatest demand over a period of time, such as a month, and call this the “peak demand period”.

  • Page 77: Frequency Measurements

    what point the average total power is at its peak. This point is the peak demand period. Put your cursor over it and observe the timestamp of the beginning of the peak demand period at the upper right of the graph. To find the peak demand, observe the average total power in watts at the point of the peak demand period.

  • Page 78: Frequency Measurements In Powersight

    purchased, the complete frequency spectrum from 5,000 to 100,000 Hz can be determined. Frequency Measurements in PowerSight PowerSight performs all commonly desired frequency measurements when operating in the variable frequency measurement mode. The fundamental frequency is displayed by pressing [Freq]. If consumption is being monitored, the maximum, minimum, and average frequency is displayed by repeatedly pressing [More...] after displaying the frequency.

  • Page 79: Duty Cycle / Power Cycle Measurements

    The measurements of frequency presented on the PS3550 can also be displayed in PSM-A by using the remote control feature. In addition, our ReportWriter software will present maximum, minimum, and average frequency during any one or two intervals of time set by the user. If two time intervals are chosen, it will report the percent change and the actual change between the two intervals.

  • Page 80: Duty Cycle / Power Cycle Measurements In Powersight

    be helpful in determining problems with control of a system (such as thermostat problems). Duty Cycle / Power Cycle Measurements in PowerSight If power consumption is being monitored, the percent of the time that current is flowing in phase 1 is displayed by pressing [On/Off Cycles].

  • Page 81: Time And Capacity Measurements

    Time and Capacity Measurements PowerSight performs the following time and capacity measurements:  present time and date  time capacity of consumption log  elapsed time of monitoring  time remaining to fill consumption log record capacity of log  ...

  • Page 82: Time And Capacity Measurements In Powersight

    The record capacity of the log is how many records can be recorded before the log fills. The default number for consumption logging is 5000 records. This number can be changed by changing the variables selected to be recorded in the log using the Data Setup feature of PSM-A (see the Setting Measurement Types...

  • Page 83: Time And Capacity Measurements In Psm-A

    Time and Capacity Measurements in PSM-A The Data Setup window allows you to review and change many of the time and capacity measurements. The time capacity of the consumption log, the record capacity of all the logs and the programmed start and stop time of monitoring (if one exists) can be reviewed and changed.

  • Page 84: Harmonic Measurements

    The measurements of time and capacity presented on the PS3550 can also be displayed in PSM-A by using the remote control feature. Harmonic Measurements French mathematician Jean Baptiste Fourier determined 150 years ago that any periodic waveform can be mathematically defined to be the sum of a fundamental frequency equal to the periodic rate and additional frequencies that are multiples of the fundamental frequency.
  • Page 85 and the 5 harmonic has an amplitude of 30 amps, then the 5 harmonic has a magnitude of 30 amps or a relative magnitude of 50%. The harmonic phase angle is the number of degrees that it leads the fundamental frequency. Comparing the difference in the phase angle between voltage and current of a given harmonic allows you to determine the “direction”...

  • Page 86: Harmonic Measurements In Powersight

         Irms 138.3             120 1 60 3 30 5 15 7     factor         ...

  • Page 87: Measurement Modes

    The measurements of voltage presented on the PS3550 can also be displayed in PSM-A by using the remote control feature. In addition our ReportWriter software will present average THD-F for voltage and current of each phase during any one or two intervals of time set by the user.

  • Page 88: Phase-Neutral Vs Phase-Phase Vs 2 Current Mode

    Phase-Neutral vs Phase-Phase vs 2 Current Mode There are three voltage measurement modes:  Phase-Phase  Phase-Neutral  2 Current Mode. When measuring voltages, you either need them recorded in phase-neutral format or in phase-phase format. A phase-neutral voltage reading is the difference in potential between one of the phase inputs (V , and V ) and the neutral input (V...

  • Page 89: Changing The Voltage Measurement Mode In Powersight

    not necessarily accurate. This is not due to any accuracy problem with PowerSight. Instead, it is the result of each phase's current being the result of two different phase-phase voltages, whereas a phase’s power and power factor calculations rely on only one of the phase-phase voltages.

  • Page 90: 50/60/400Hz Vs Dc Vs Variable Frequency

    Monitoring Setup menu and read what appears in the Voltage Mode box or operate in Remote Control mode and press the key combinations described above. To change the voltage measurement mode using PSM-A, either go to the Monitoring Setup menu, choose “View Meter’s Data Setup, cycle through the sections until you get to “How should the meter operate”...
  • Page 91 When operating in variable frequency measurement mode, PowerSight determines the fundamental frequency of the voltage or current that is attached to it every second. The fundamental frequency is recorded and is used to determine the true RMS values of all voltages and currents. This mode of measurement is only recommended if performing: ...

  • Page 92: Changing The Frequency Measurement Mode In Powersight

    Changing the Frequency Measurement Mode in PowerSight To determine which frequency measurement mode PowerSight is in, simply press the [Measure Mode] key twice and read the display. To change the frequency measurement mode from what is displayed, press the [No/Reject] key and then press [Yes/Accept] when the desired measurement mode is displayed.
  • Page 93 Most users perform measurements on equipment that is either always consuming power or always generating power. However, there are cases in which you may wish to measure power use on equipment that is alternatively consuming and generating power (like an oil well pump jack). Always Positive Power measurement mode and Negative Power Allowed measurement modes are provided to allow ease and accuracy of measurement in both types of situations.

  • Page 94: Changing The Power Measurement Mode In Powersight

    Changing the Power Measurement Mode in PowerSight To determine which power measurement mode PowerSight is in, simply press the [Measure Mode] key three times and read the display. If PowerSight is in Always Positive Power measurement mode, the display will read "Power Readings Always Positive". If PowerSight is in Negative Power Allowed measurement mode, the display will read "Negative Power Readings Allowed".
  • Page 95 input does not represent what it actually is. In these cases, the user needs to define the inputs for PowerSight or for PSM-A. The chief need for defining inputs is to enter in input ratios for voltage or current. There are several occasions when this is necessary.

  • Page 96: Changing Input Ratios In Powersight

    Finally, in measuring high voltages, if you use a high voltage probe, enter the ratio of the probe (for instance, 100 : 1) and record the actual voltage being measured. Using these techniques, you can measure anything with PowerSight. The measurement range extends from 1 milliamp to more than 4 million amps, 1 volt to more than 4,000 kilovolts, 1 watt to more than 40 megawatts! Note: When PowerSight is turned off, its input ratio settings are...

  • Page 97: Changing Input Ratios In Psm-A

    Changing Input Ratios in PSM-A To determine or change the input ratios using PSM-A, go to the Monitoring Setup menu and click on the “Input Ratios:” drop down box and choose “Custom”. This leads to the presentation of the Input Configuration summary display.

  • Page 98: Voltage & Current Waveforms

    Voltage & Current Waveforms Introduction Waveforms are very different from logs and other graphs. A waveform is the most basic direct measurement. It displays the instantaneous levels of voltage and current as they continually vary, as you see on an oscilloscope. All other measurements are derived from them.
  • Page 99 is separate from the space reserved for other types of data. Therefore it does not limit the size of your logs or write over any other type of data. Whenever you store a waveform set in PowerSight it writes over the oldest waveform set that is stored in the meter.

  • Page 100: Receiving Stored Consumption Waveforms

    Receiving Stored Consumption Waveforms Waveform sets that are stored inside of a connected PowerSight can be received by PSM-A in either of two ways. At the Main Menu, you can click on the “Data Analysis” button and then the “Receive & View Data” button.

  • Page 101: Viewing Consumption Waveforms

    Viewing Consumption Waveforms To select a waveform set to view, at the main menu, click on “Data Analysis”, then “View Consumption Data”, or click on “File” and then “View Data”. This will result in the View Sessions Data screen being shown.
  • Page 102 There is a wealth of features related to viewing and analyzing waveforms. Voltage and current can be viewed together and multiple phases of signals can be viewed together. Portions of waveforms can be zoomed into and panned left/right or up/down. Refer to Working with Graphs and Wavefoms...
  • Page 103 You can easily display a phasor diagram of the signals by clicking on the “Phasors” icon. Phasor diagrams present each voltage and current as a vector on a graph. A vector combines two measurement properties into one object. In this case, the properties are magnitude and phase lag.
  • Page 104 Another feature added in PSM-A is the “Analysis” tab. Here you can create labels on the waveform graph, add vertical and/or horizontal cursors and add crosshairs. This allows you to customize your graph for presentation. Once you are done customizing your graph, you can save the graph as an image and print it or import it into a report for demonstration.

  • Page 105: Monitoring Power Consumption

    Monitoring Power Consumption Introduction When PowerSight is first turned on, it operates like a reporter, describing what it sees. New measurements are generated each second that replace old measurements. Old measurements are discarded. These are the “present” values that are displayed as you press various keys.

  • Page 106: Basic Consumption Data Logging

    This is the act of recording summarizing information once every logging period. With PowerSight, the logging period is set by the user, whereas the measurement updating period is always once per second. This insures that you don’t miss valuable information related to the actual power used and the maximums and minimums present.
  • Page 107 that you can measure and record just about anything you need to. To simplify things, we provide a default data logging setup and have that installed when you receive your unit, so you are ready to begin logging under general circumstances. The default data logging setup is: ...
  • Page 108  voltage from phase 2 to phase 3 (phase-phase mode)  voltage from phase 3 to phase 1 (phase-phase mode)  current in phase 1  current in phase 2  current in phase 3  current in neutral  true power in phase 1 ...

  • Page 109: Receiving The Data Logging Session From Powersight

    this way, you could leave a unit logging unattended for months and always have the most recent data available for analysis. To have logging stop when the log is full or to set a programmed start or stop time, refer to the Custom Consumption Data Logging chapter.

  • Page 110: Viewing The Data Logging Session In Psm-A

    Viewing the Data Logging Session in PSM-A To view any of our file types from your data logging session in PSM-A, you will first have to download the data from the meter either via Bluetooth, USB or SD card. After the data is downloaded and saved to your PC, you can view your sessions under “Data Analysis”...

  • Page 111: Working With Graphs And Waveforms

    Working with Graphs and Waveforms Presentation of the Graph It is important to us to allow you to work with and manipulate the various graphs and waveform presentations in PSM-A. We try to make the features that accomplish this look and feel the same throughout the program so you can handle all waveforms and graphs in the same way as much as possible.

  • Page 112: Reading Graphs And Waveforms

    Normally, the color of the signals is set automatically by PSM-A to give good color contrast on a color monitor. However, that contrast may not stand out on your monitor or on your color printer or especially with your black and white printer.
  • Page 113 measurements (such as when displaying voltage and current) there will be a vertical name and metric on the left side and a different one on the right side of the graph. 4) The horizontal axis is usually time. Logs have time and date stamps to help determine when events occurred and how long they lasted.

  • Page 114: Zooming And Panning

    Zooming and Panning Perhaps the most powerful tool of graphical analysis is zooming. This feature allows you to expand an area of interest of a graph or waveform so that it fills the screen. It also allows you to trim off areas that you don’t want displayed (for instance, you may only want one week of a 30 day log...
  • Page 115 example on the right does a good job of focusing in on this area of particular interest. The example on the previou page showing the full log has several features of interest highlighted. Notice that the cursor is positioned near the center of the display. The data associated with that point appears in the heading, in parentheses.

  • Page 116: Custom Data Logging

    The collection of choices that are made on how to operate is called a “setup” file. You can use the “default” setup file, supplied by Summit Technology or you can create, store, and retrieve your own. Starting Data Logging There are several methods to initiate data logging.

  • Page 117: Stopping Data Logging

    and time will be stored in the unit, until a new date and time are written over it. This is a great way to synchronize several PowerSights to start logging at the same time, so there data logs can be synchronized. It is also a great way to log for a specific number if minutes or hours or days or whatever when combined with the mode of stopping data logging at a specific date and time.

  • Page 118: Setting The Data Logging Period

    Setting the Data Logging Period One of the most important settings is the choice of logging period. This is the length of time between the creation of data records. This has no effect on the measurement rate or the sampling rate. Unlike inexpensive data loggers that only take measurements when a record is created, PowerSight measures all its variables every second, regardless of the recording rate.

  • Page 119: Setting Measurement Types

    seconds or minutes and to accept the final entry. To change the logging interval number, use the numeric keypad of the meter, using [Yes] when done. Setting Measurement Types By default the PS3550 records ALL variables available. This is because with the addition of an SD card and larger memory size, you can fit larger logs in the meter.

  • Page 120: Setting Measurement Modes

    have to get all the data from the SD card as the internal memory will only have the last records recorded compared to the thousands on the card. When done modifying the measurement types, be sure to click “Accept” and then save the new setup to file and/or send it to the connected PowerSight.

  • Page 121: Loading Data Setups From The Memory Card (Sd Card)

    button on the main menu, then select the “View Stored Data Setup” button. This will open up the windows dialog box to choose a saved data setup file. To view the connected meter’s data setup, you can choose “View Meter’s Data Setup” and PSM-A will upload the setup installed in the PowerSight meter.

  • Page 122: Saving Data Setups To The Memory Card (Sd Card)

    Saving Data Setups to the Memory Card (SD Card) It is beneficial to store a copy of the present data setup onto the SD card to document how a monitoring session was set up. This is done automatically when an SD card is installed. Each time monitoring starts and an SD card is in the meter, a serial number directory is created if it is not already present and a logging directory is created to hold the various files created by the...

  • Page 123: Reportwriter Software

    ReportWriter Software Introduction PSM-A comes with a ReportWriter Software program. The ReportWriter software provides concise reports to summarize and document findings. Comparison reports are excellent for presenting before/after comparisons of power usage and projected cost. Separate logs can be compared or sections of the same log can be compared for this analysis.
  • Page 124 After you press “Proceed” you will see the “ReportWriter Titles and Data Source” screen. Here you will create a Report Title then choose between doing a summary report or a comparison report. A summary report provides a concise summary of data from one consumption log.
  • Page 125 The next screen is the “ReportWriter Variables” screen. Each measurement type that can be included in the report has its own checkbox. They are organized in a matrix that allows ease of locating a specific signal and ease in enabling or disabling entire columns or phases of them.

  • Page 126: Viewing A Report

    to edit the look of the graphs in the report. You can select from “Half-Page Graphs” which will put 2 graphs per page, “Full-Page Graphs” which will put 1 large graph per page, and “No Graphs” which will just put the summary table in the report.
  • Page 127 column is the one number summary for the measurement type for the “before” time period. If it is an average (like “Voltage, Phase 1, Avg.”) the value is the average over the “before” timeframe. If it is a maximum (like “Voltage, Phase 1, Max.”), it is the maximum over the “before”...

  • Page 128: Testplan Manager In Psm-A

    TestPlan Manager in PSM-A What is TestPlan Manager TestPlan Manager is a new way to organize your multi-point power quality testing. TestPlan Manager allows you to create a Testplan for multiple systems or for 1 system with multiple test points, load it into PowerSight, then quickly test and gather the data via SD card.

  • Page 129: Opening An Existing Testplan In Psm-A

    From here you can either open and existing plan from your computer or SD card, or create a new plan. The idea is to organize multiple meters or multiple test points, store the files in predetermined locations on the SD card, then with TestPlan Manager, and download those tests from 1 or more cards easily and efficiently.

  • Page 130: Create A New Testplan In Psm-A

    Create a New TestPlan in PSM-A Open TestPlan Manager, then start filling in the required fields. These fields will be used to create the test plan file name. 1. Enter “Test Plan ID”. This is the unique name for the test plan.
  • Page 131 equipment (i.e. the Equipment ID) rather than by the test plan, since the test plan identifiers may be different each time you test the same equipment. For example: You monitor the performance of motors at a facility and reevaluate them twice a year. You want to keep track of the results by each Equipment ID to group the data by each specific motor so you can see the trend of performance over time.
  • Page 132 1-0-0(the main entrance), 1-1-0(1 branch), 1-2-0(2 branch), 1-1-1 (1 load of 1 branch), 1-1-2 (2 load of 1 branch), 1-2-1 (1 load of 2 branch), etc e. Destination Filename: (Automatic) this is the filename that will be used for all test data retrieved for this test point.
  • Page 133 p. Comment: (Optional) any other relevant details for that test point. 6. Next is to print your TestPlan. This is useful to give those doing the individuals doing the test point a detailed list of the points and any comments relevant to their particular tests.

  • Page 134: Using Testplan Manager With Powersight

    Using TestPlan Manager with Powersight Once all the PowerSight meters have their SD cards loaded with the TestPlan, it is time to get them out into the field to start testing. TestPlan Manager in PowerSight makes it easy to apply the right test to the right test point, eliminating mistakes.

  • Page 135: Retrieving The Testplan Data In Psm-A

    Note: following the test, the next time the user attempts to perform a test, the meter will automatically assume the meter is at the next test point of the test plan. 6. If the meter does not suggest the test point that the meter is at, the user can either step through each test point by rejecting each one (pressing the “No”...
  • Page 136 4. Click on the Get Test Data Files button. 5. A window will open showing any drives of your computer that can have data for the test plan. 6. Make sure that your SD card is selected for the source. Then make sure that the correct destination drive is selected, normally the C: drive, then click “OK”.
  • Page 137 8. Click on “Transfer Data” button and get confirmation that the test data has been received, routed, and named automatically. 9. The following valuable operations just occurred: a. Each data file for the test plan was sent to the path specified in the “Save Test Data to”...

  • Page 138: Opening Testplan Data In Psm-A

    Opening TestPlan Data in PSM-A Since the files created by the TestPlan Manager are the same as the PowerSight’s normal data logs, waveforms, etc, You will open these files just like you would if you downloaded the data via Bluetooth or USB. See the sections above on “Viewing the Data Logging Session in PSM-A”...

  • Page 139: Setup Functions

    Setup Functions Several functions used in setting up measurements are available using the [Setup] key. They include:  Loading Setup from Memory Card  Log Interval  Check Trigger Levels (Not applicable on the PS3550) Setting the Utility Rate  Setting the on/off Current Level ...

  • Page 140: Administrative Functions

    Hardware revision level (what level of hardware compatibility it is). These identifiers are important in any communications with Summit Technology about your unit. Viewing the options that are loaded results in a display such This display indicates that Extended Memory (“M”) is active. This information may be important in communications with Summit Technology.
  • Page 141 The date, 6/24/07 is the date that the warranty expires on the product. Contact Summit Technology to extend the warranty prior to that date since re-instating the warranty after that date will cost extra. The next number is for the use of Summit Technology personnel.

  • Page 142: Other Functions Within Psm-A

    Other Functions within PSM-A Introduction In addition to the many power analysis functions of PSM-A that have been presented in previous chapters, there are several other functions available. These are functions of convenience, functions for setting up attached PowerSight meters, and functions for setting up the PSM-A program.

  • Page 143: Locating And Installing Software And Firmware

    Locating and Installing Software and Firmware A tradition of PowerSight models is that the products continue to improve and as they improve, those enhancements and features are made available to users who elect to stay under our enhanced warranty. Our PSM-A software continues to improve and is available for download via the web.

  • Page 144: Setting Up Administrative Features Of Powersight Via Psm-A

    When you start the upgrade process either via the automatic pop up or manually pressing the “Install…” button, you will then see a “Firmware Upgrade” pop up window. It should be populated with the firmware version for you to upgrade to. If it has not, you can press the “Change”...

  • Page 145: Putting It All Together (Monitoring For The First Time)

    will pop up. The present personal greeting, date and time will be displayed. Simply make any changes that you wish and then click “Set New Date Time” to apply the computers date and time to the meter, or “Set New Greeting” to apply the greeting changes to the meter.
  • Page 146 time and location and then PowerSight can be transported to the site of logging. The first step is to set up or check the parameters for logging. 1. Review the chapter Communication with PowerSight to ensure that Bluetooth communications are established between the PC operating system and the meter after the meter is turned 2.

  • Page 147: Troubleshooting & Frequently Asked Questions (Faq)

    2. How do I connect to my laptop if it does not have Bluetooth communications capability? You can buy a Bluetooth Adapter from Summit Technology (order BTA). This adapter will plug into one of your USB ports. Other brands will likely work, but cannot be guaranteed to work with PowerSight.
  • Page 148 4. Why doesn't my PowerSight read Voltage/Current correctly? There are many reasons why PowerSight may not be reading voltage or current. First, check that you have all the voltage and current leads connected correctly. Then if that doesn't solve your problem, check that the frequency mode of the PowerSight is in the correct mode for your situation.
  • Page 149 type will take to fill up. You can also press the "Time" button 3 times to see the "time to fill log" displayed on the screen of PowerSight. 9. What is a Logging Interval? The logging interval is the amount of time that passes between PowerSight making entries into its internal data log.
  • Page 150 12. Can I use other manufacturers’ current probes with PowerSight? Unfortunately, no. Only current probes made by Summit Technology can be used with the PowerSight Products. This is because all of our probes are "self-identifying". This means the user does not have to use an input ratio to use the probes. If there is a special need to use a certain probe, let us know at support@SummitTechnology.com.

  • Page 151: Overview Of The Keypad Functions

    Overview of the Keypad Functions One of the best features of PowerSight is its user interface. A surprising amount of capability is quickly available through the touch of a button. We have attempted to make the interface intuitive and flexible. Many functions can be accomplished in several ways.

  • Page 152: Compatibility Guide

    Although we attempt to make all products and accessories compatible, there are limitations to what devices and versions can work well together. The PS3550 must be used with PSM-A software of at least the 4.1 series. Compatibility of the PS3550 with Summit Technology accessories is as follows:...
  • Page 153 Accessories PS3550 120ADP-a 120ADP (discontinued) not compatible (use 120ADP-a) 15KVP 5KVP 5KVP (version with ext. not compatible (use new version) box) CAS3 CASW CHG1 Yes, for Euro 220V standard CHG2 not compatible CHG3 not compatible CHG4 Yes, for US 120V standard COMM not compatible DC600...

  • Page 154: Specifications

    Specifications* Size   3.88” (9.86cm) Wide 7.72” (19.61cm) Long 1.58” (4.01cm) Deep in Hand-held region, 2.14” (5.44cm) deep at the top end Weight 1.1 pound (0.5 kg) Operating Range 0 - 50 degrees C (32 - 122 degrees F) Relative humidity to 70% (non-condensing) Meets mechanical shock requirements of MIL-PRF 28800F for a class 1 (harshest) environment...
  • Page 155 Measure Rate: Measure every second of every input. Frequency Response: dependent on current probe attached. With HA1000: no de-rating of accuracy for harmonics through 3900 Hz) Frequency Range: DC, 22 - 200 Hz, 360 – 440 Hz fundamental frequency DC and 22 - 4500 Hz included in RMS 22 - 3900 Hz for harmonic measurements Accuracy: 0.25%...

Table of Contents
