Asus ROG Rapture GT-BE98 Pro Quick Start Manual

Quick
Start Guide
ROG Rapture GT-BE98 Pro
BE30000 Quad-band Gaming Router
* If no 6GHz SSID is displayed, please check whether your OS and client device are fully licensed to support the newly
released 6GHz band. You can check with your OS and client device provider for Wi-Fi 6E / WI-FI 7 driver release
schedule.
Router Setup Steps
01
Prepare your Modem
Unplug the power of cable / DSL modem.
1
Unplug
If you are using DSL for internet,
you will need your username /
password from your Internet
service provider (ISP) to properly
configure your router.
Install your Router
02
Plug the adapter into the DCIN port, and press
1
the Power switch.
– Via app
[App] On your iOS or Android mobile device, go
3
to the app store, search for ASUS Router, and
download the app.
– Or via web browser
[Wired] Connect your PC to a LAN (LAN2~6) port
3
at the back side of the router using an additional
network cable.
Gain Another 10GE LAN Port
01
Set up 2.5GE WAN connection to release another 10GE LAN Port
– Under factory defaults
Connect to the 2.5GE WAN port
Connect the modem to the 2.5GE WAN port with a net-
work cable.
Connect your modem to the 10GE WAN port at the back side of the router
2
with the network cable provided.
Power on the modem. Plug
3
modem to the power outlet and
power on.
Modem back
[App] On your iOS or Android mobile device, tap Settings > Wi-Fi,
4
connect to the default network SSID shown on the product label on
the back side of the router. Or scan the code on the product label to
connect the default network SSID.
[Wireless] Connect to the network with default SSID
shown on the product label on the back side of your
router "ASUS_XX".
Login and Connect
[ASUS Setup Wizard] Select "Manual Setting".
1
Hardware Explanations
Power switch USB 3.0 port
2.5GE WAN/LAN1 port
Power (DCIN)
USB 2.0 port Reset button
port
2.5GE LAN2-4 ports
Specifications:
DC Power adapter DC Output: +19V with max 3.42A current
DC Output: +19.5V with max 3.33A current
Operating Temperature 0~40
o C
Operating Humidity 50~90%
Modem back
The Power LED will light up when the hardware is ready.
2
* XX refers to the last two
_
digits of 2.4GHz MAC
address. You can find it
on the label on the back
of your router.
[Wired / Wireless] Open a web browser.
4
You will be redirected to the ASUS Setup Wizard. If not, navigate to
http://www.asusrouter.com
Follow the instructions to
complete the setup.
http://www.asusrouter.com
2
10GE LAN LED
10 /2.5GE WAN
2.5GE/1GE
(Internet) LED
LAN LED
10GE WAN/LAN1 port
WPS button
1GE LAN5 port 10GE LAN6 port
Storage 0~70 o C
Storage 20~90%
Check the modem LED lights to ensure the connection is active.
4
Modem front
[App] Launch ASUS Router App and follow
5
the instructions to complete the setup.
[ASUS Setup Wizard] Select "2.5G WAN", then follow the instructions to
complete the setup of SSID and login information.
E22187
6GHz-2/6GHz-1/5GHz/
2.4GHz WiFi LEDs
Power LED
LED button
