- Page 1 User Manual Swivel 11.6" Patent Pending sidetrak.com...
- Page 2 Thank you for your recent SideTrak purchase. We are confident that you will be satisfied with your new portable monitor. Driven by our passion to provide you with a more convenient, productive, and agile day, our team is dedicated to creating premium solutions designed to fit your professional needs and flexible lifestyle.
-
Page 3: Table Of Contents
Contents Component List Installation 12 Features 13 Configuration for PC 14 Configuration for Mac 15 FAQs 17 Troubleshooting 18 Technical Specifications 19 Limited Liability Warranty... -
Page 4: Component List
Component List Swivel 11.6" Metal plate Bezel Menu buttons Device-safe magnets Mounting frame Screen USB-C port Removal tool USB-C to USB-C cord Extra metal plate with USB-A adapter... - Page 5 Component List cont. Up/Down Menu/Enter Close-up of USB-C port Close-up of menu buttons (on the side of the Bevel)
-
Page 6: Installation
Installation Connecting Your SideTrak Scan QR code to watch Check the ports on your laptop installation video. First, check your laptop’s USB-C port if you do not have a Chromebook or Mac laptop. If your laptop’s USB-C port has one of the below symbols, then your USB-C port is compatible. - Page 7 Installation cont. Attach Your Monitor to Your Laptop Close laptop Make sure your laptop is closed and that the laptop opening is facing you. Laptop opening Back of laptop Align mounting guide Use the mounting guide that is included in your box to attach the metal plate to either the left or the right side of your laptop.
- Page 8 Installation cont. Left-side attachment Place the mounting guide on top of your laptop WHICH SIDE OF YOUR LAPTOP DO YOU and move it all the way to the left side of your Make sure your laptop is closed and have the laptop opening facing you.
- Page 9 Simply plug one end of the USB-C cord into your monitor and the other end into your laptop. Now, you are all set to start using your new SideTrak monitor! Adjust Settings Press the Menu/Enter button to bring up the menu on the screen.
- Page 10 Everyday Use: How to Attach and Detach Your Monitor SideTrak’s metal plate will stay on your laptop, making it easy for you to attach and detach your SideTrak whenever you need! To reattach your monitor, angle the SideTrak slightly, “hooking”...
- Page 11 Pack Your Monitor for Travel You can easily travel with your monitor attached to your laptop! SideTrak stays securely attached to the metal plate. To securely store your monitor for travel, simply follow the steps below: Fold the mounting frame inwards toward Detach your monitor from your laptop.
-
Page 12: Features
Features Slide SideTrak’s magnets glide across the attached metal plate so you can slide your SideTrak out and adjust to your viewing preferences. Rotate Rotate your screen 180° to easily share your screen with others. -
Page 13: Configuration For Pc
Drag and drop screen icons to match your setup. Display settings dialogue box on Windows 7 and older. If your SideTrak is installed to the left of your laptop, arrange your screens to reflect this. Select “Extend these displays” to use the SideTrak as an extension of your laptop. -
Page 14: Configuration For Mac
Select “Arrangement” tab at the top of the window, then drag and drop the screen icons to match your setup. If your SideTrak is installed to the left of your laptop, arrange your screens to reflect this. Display settings dialogue box on Mac operating systems. -
Page 15: Faqs
FAQs Do I need a download? Can the SideTrak be placed on the left of my laptop? If you do not have a Chromebook, Mac laptop, or a compatible USB-C port, you will Yes! Simply follow the left side attachment need to download the DisplayLink driver. - Page 16 What if I need a new cord or a new metal plate? semi-permanently attached to my laptop? Replacement parts can be purchased at You can use the SideTrak as a freestanding sidetrak.com or by scanning QR code below. monitor without the metal plate, but to...
-
Page 17: Troubleshooting
5. Test the SideTrak with a different USB-C cord properly placed. if you have any extra. 6. If you are still having trouble with your SideTrak, contact us. We are happy to help you! Email us at customerservice@sidetrak.com or call us at (240) 580-8725. -
Page 18: Technical Specifications
Technical Specifications Screen Size: 11.6" Refresh Rate: 60Hz Response Time: 25ms Brightness: 250cd/m² PPI: Aspect Ratio: 16:9 Contrast Ratio: 1000:1 Color Depth: 262k Power Consumption: 3.9W Panel Type: TFT Resolution: 1366x768 Connection Type: USB-C... -
Page 19: Limited Liability Warranty
This limited warranty gives you specific legal rights and you may also have other rights. Which vary from state to state. The limited warranty can also be found online at sidetrak.com/pages/warranty and in the documentation we provide with this product. We warranty that during the warranty period, the product will be free from defects in materials and workmanship. - Page 20 (240) 580-8725...
