- Page 1 TG1006 10MHz DDS Function Generator SERVICE MANUAL...
-
Page 2: Table Of Contents
Table of Contents Specifications Safety Installation General Calibration Parts List... -
Page 3: Specifications
Specifications Specifications apply at 18°- 28°C after one hour warm-up, at maximum output into 50Ω. WAVEFORMS Standard waveforms of Sine, Square, Triangle and DC. Sine Range: 1mHz to 10MHz. Resolution: 1mHz or 6 digits. Accuracy: 10 ppm for 1 year; ± 1mHz below 0.2Hz. Temperature Stability: Typically <1 ppm/ºC outside 18°... - Page 4 Amplitude Modulation Carrier Frequency: From 1mHz to 10MHz. Carrier Waveforms: All. Modulation Frequency: 400Hz internal. DC to 20kHz external. External Modulation: AM/COUNT IN socket. Frequency Shift Keying (FSK) Phase coherent switching between two selected frequencies at a rate defined by the switching signal source.
- Page 5 Count In The AM/COUNT IN socket is set to external frequency measurement when EXT COUNT is selected. Input Impedance: 1MΩ//20pF. Input Sensitivity: 50mVrms (sinewave). Maximum Allowable 30Vdc/30V to 50Hz/60Hz with respect to ground , reducing to Input Voltage: 1Vrms above 1MHz. DISPLAY FUNCTIONS The LCD shows generator frequency setting at a resolution of 4 digits simultaneously with output amplitude/offset, together with various status annunciators.
-
Page 6: Safety
Safety This instrument is Safety Class I according to IEC classification and has been designed to meet the requirements of EN61010-1 (Safety Requirements for Electrical Equipment for Measurement, Control and Laboratory Use). It is an Installation Category II instrument intended for operation from a normal single phase supply. -
