CONVERTIBLE SANDBOX & PICNIC TABLE
ASSEMBLY
INSTRUCTIONS
Assembly requires 1 adult
(approx. 1 hour assembly time)
Warning! For outdoor domestic use only.
Adult supervision recommended at all times.
Not suitable for children under 36 months until fully
assembled – Small parts – Choking hazard.
Min. User Age: 18 months. Max. User Weight: 110 lbs.
PG505W
817 Maxwell Avenue • Evansville, IN 47711 • 1-800-GO-SWING • www.escaladesports.com • ©2020 Escalade® Sports
Advertisement
Related Manuals for Jack & June PG505W
Summary of Contents for Jack & June PG505W
- Page 1 Not suitable for children under 36 months until fully assembled – Small parts – Choking hazard. Min. User Age: 18 months. Max. User Weight: 110 lbs. PG505W 817 Maxwell Avenue • Evansville, IN 47711 • 1-800-GO-SWING • www.escaladesports.com • ©2020 Escalade® Sports...
-
Page 2: Routine Maintenance
Advisory Section To ensure the safety of you, the installer and your children, it is important that these instructions are read fully before commencing the positioning and assembly of this product. Assemble table on a clean flat area. Keep your sandpit safe for the children 1. - Page 3 P G 505 W S TA N D A R D PA R T S L I S T 4 " 2 " C1529 C1535 C1530 QTY. 1 QTY. 4 QTY.2 " 4 " 4 " C1534 C1533 C1568 QTY. 2 QTY.
- Page 4 H A R D WA R E #8 X 2” PHILLIPS FLAT HEAD WOOD SCREW QTY. 64 M6X40mm QTY. 16 M6X15mm QTY. 16 T O O L S N E E D E D PHILLIPS SCREW DRIVER (NOT INCLUDED) NOTE: An electric screwdriver is helpful in assembly.
-
Page 5: Side View
HARDWARE NEEDED (ACTUAL SIZE) STEP 1 #8 X 2” WOOD SCREW QTY. 4 On a clean flat surface attach C1568 boards to C1536 board as shown. PARTS NEEDED (NOT TO SCALE) NOTE: Tighten, but DO NOT strip out any screws. 4 "... - Page 6 HARDWARE NEEDED (ACTUAL SIZE) STEP 2 #8 X 2” WOOD SCREW QTY. 4 Attach a second C1536 board to other end as shown. PARTS NEEDED (NOT TO SCALE) NOTE: Tighten, but DO NOT strip out any screws. 4 " C1536 QTY.
- Page 7 HARDWARE NEEDED (ACTUAL SIZE) STEP 3 #8 X 2” WOOD SCREW QTY. 4 Attach C1569 board as shown. PARTS NEEDED (NOT TO SCALE) NOTE: Tighten, but DO NOT strip out any screws. C1569 QTY. 1 8 " C1569 HARDWARE NEEDED (ACTUAL SIZE) STEP 4 Attach C1531-1 wide board flush to the end &...
- Page 8 HARDWARE NEEDED (ACTUAL SIZE) STEP 5 Place all C1531 boards starting with the end board first #8 X 2” WOOD SCREW (make sure its flush to the end). Evenly space, if QTY. 32 necessary, and attach all board using the 2” screws. 4 "...
- Page 9 HARDWARE NEEDED (ACTUAL SIZE) STEP 7 Attach C1534 board as shown using Allen M6X40mm M6X15mm Wrench. Start bolts but do not tighten QTY. 4 QTY. 4 completely yet. ý þ C1534 STEP 8 Make sure the legs are level, tighten the bolts with the allen wrench until secure.
- Page 10 STEP 9 REPEAT Steps 6-8 to attach boards C1534 & C1535 to the other end of the table. HARDWARE NEEDED (ACTUAL SIZE) STEP 10 #8 X 2” WOOD SCREW Attach C1533 Seat boards making sure they are flush to QTY. 8 the leg boards as shown.
- Page 11 HARDWARE NEEDED (ACTUAL SIZE) STEP 11 #8 X 2” WOOD SCREW Attach C1530 board as shown, pay close attention to QTY. 2 the location of the pre-drilled pilot holes. C1530 Pre-drilled pilot hole STEP 12 Line up pre-assembled C1529 panel and lay it C1529 flush next to the C1530 board as shown.
- Page 12 HARDWARE NEEDED (ACTUAL SIZE) STEP 13 #8 X 2” WOOD SCREW Attach C1530 board as shown leave less than 3/16” gap QTY. 2 so that the panel C1529 can be removed. C1529 C1530 C1530 HARDWARE NEEDED (ACTUAL SIZE) STEP 14 Secure C1530 boards with screws C1530 #8 X 2”...
- Page 13 STEP 15 Remove panel C1529 and insert two D1570 sand liners as shown. Always cover the table with panel C1529 when not in use. D1570 D1570 -13-...
