Wolf ATEX Turbolite Features
•
Ideal for task lighting in
hazardous marine and tank
cleaning applications.
•
ATEX, UKEX and IECEx
approved for Zone 1,2, 21 and 22
potentially explosive gas and dust
atmospheres.
•
Uniquely powered by a supply of
compressed air.
•
Compact and lightweight design.
•
Up to 9,000 lumens light output
at source.
•
Robust and durable nickel plated
aluminium construction.
•
IP66 ingress protection rating
when running.
•
Toughened glass lens/ball glass.
WOLF SAFETY LAMP COMPANY
Saxon Road Works, Sheffield, S8 0YA, England
Tel: +44 114 255 1051
E-mail: info@wolfsafety.com
Website: www.wolfsafety.com
A-1022 - Issue 3
Authorised Representative Service, 77 Camden Street Lower, Dublin, D02 XE80, Ireland
DF559
1180
0598
Authorised Representative (EU)2019R1020:
ATEX
TURBOLITE
A-TL44C
A-TL45C
Advertisement
Related Manuals for Wolf ATEX TURBOLITE A-TL44C
Summary of Contents for Wolf ATEX TURBOLITE A-TL44C
- Page 1 ATEX Wolf ATEX Turbolite Features TURBOLITE • Ideal for task lighting in hazardous marine and tank cleaning applications. A-TL44C • ATEX, UKEX and IECEx approved for Zone 1,2, 21 and 22 potentially explosive gas and dust A-TL45C atmospheres. • Uniquely powered by a supply of compressed air.
-
Page 2: Technical Data
EN IEC 63000:2018. 1. This equipment shall only be supplied with air from The Wolf Safety Lamp Co. Ltd has a policy of continuous product improvement. Changes in design This declaration is issued under the sole responsibility a clean, dry source that is free from contamination with details may be made without prior notice. - Page 3 Operating Instructions Setting Generator Voltage The Wolf ATEX Turbolite is a compressed air driven lamp. The operating pressure must be between 5 and 8 bar (70 to 120 psi). The ideal running and setting pressure is 5.5 bar (80 psi).
- Page 4 3. The use of non-Wolf spare parts and/or The fastening screws are high tensile A4 The regulating screw and lock nut should then be loosely fitted just inside the end of the piston improper fitting of spare parts will invalidate stainless steel specification.
- Page 5 Wolf ATEX Turbolite – A-TL44C and A-TL45C Inspection and replacement of generator Rotor Assembly sealed bearings 10mm Spanner Spare Parts To remove the rear cover, remove the 3x fastening screws, using a 5mm Allen key. The Item No. Part No.
- Page 6 Wolf ATEX Turbolite – A-TL44C and A-TL45C Torque 2.5Nm Torque 2.5Nm Torque 0.5Nm SECTION Note orientation of the baylight seal, with larger fig. 7 internal radius at the top as shown. Torque 2.2Nm Torque 1.5Nm Torque 0.5Nm Lock Screw Torque 0.5Nm Max.
