Freelap FxChip BLE BA-0001 Quick Start Manual

Further information
Battery and battery life
Your FxChip BLE runs on a CR 2032 battery (provided) with a 2'000 hours battery life.
• Low battery indicator:
- Place the FxChip BLE in the detection field of a transmitter turned on. If the red led of
the FxChip BLE doesn't light up, it means that your FxChip BLE's battery is too low.
- When the battery becomes low, you are notified on your MyFreelap account.
- You can check the battery level whenever you want using Freelap Device Manager app
too.
• Replace the battery:
Unscrew the 4 screws on the back of the device using a screwdriver, then remove the
cover and the gasket. Remove the old battery, and insert a new CR 2032 battery. Make
sure that the new battery is the right way round. Put back the gasket, the cover, and
screw back the 4 screws.
Technical sheet
• Weight: 17 g
• Dimensions: 36 x 48 x 14 mm
• Technology: Bluetooth smart
• Compatibility: e-Starter, Tx Touch Pro, Tx Pad Pro, Tx Pro Team, Tx Junior Pro, Tx
Track Pro, PowerUnit, Tx Gate Pro, Tx Fulltrack Pro, CxUnit, LED Display.
• Accuracy: 1/100 of a second
• Memory: 10 intermediate LAP times
• Minimum time between 2 transmitters: 0,7 second
• Battery: CR 2032
• Battery life: 2'000 hours
• Water resistance: IP67
• Operating temperatures: -20°C to +50°C
Technical support
Find our FAQ (Frequently Asked Questions), as well as other manuals and user guides,
on our website at: www.freelap.com/support
If you cannot find the answers to your questions, please contact your Freelap dealer.
Find the list of Freelap dealers at: www.freelap.com/freelap-contact
After-sales service & warranty
The FxChip BLE is guaranteed 2 years. If you have any questions or if you need
assistance with your device, please contact your Freelap dealer.
FREELAP SA
Av. D.-Jeanrichard 2A CH-2114 Fleurier – Switzerland
+41 32 861 52 42 - www.freelap.com
@freelap
FxChip BLE
FxChip BLE
BA-0001
V160823
