Optimus PRO X77 Quick Start Manual

OPTIMUS*
Cat. No. 40-2072
PRO X77 5-Inch 2-Way Metal Cabinet
Speaker
INTRODUCTION
This speaker's internal elements were
exclusively designed to maintain
shape through all phases of opera-
tion, move diaphragm elements with
efficient speed, and reproduce high
frequencies extremely well.
The 5" driver in this speaker is
specially designed to accurately
produce all sonic information from 90
Hz to over 2.5 kHz. The pliable
diaphragm in the 3" x 31/2" driver can
accurately, and with extraordinarily low
distortion, produce sonic information
from 2.5 kHz to 25 kHz. Its unique
design means there is virtually no
physical limitation to its production of
high-frequency sound.
This speaker gives you amazing music
reproduction in a small enclosure. It
produces high sound quality with very
low distortion, and actually delivers de-
creasing distortion as the sound moves
to the higher frequency ranges.
Its features include:
Linzeum® Tweeter — uses a pliable
diaphragm to reduce or eliminate dis-
tortion caused by excess vibration. It
also can reproduce higher frequen-
cies (over 20 kHz) without being lim-
ited by its physical construction.
High-Compliance Woofer — accu-
rately tracks signals to provide out-
standing bass.
Acoustic Design — provides broad,
smooth frequency response.
SPEAKER PLACEMENT
For the best stereo image, place a
pair of speakers so the distance be-
tween them is about the same as the
distance between the listening area
and the point halfway between the
speakers.
Main
Listening —C)
Area
Distance Between Speakers for Stereo Effect
If you must place the speakers farther
apart, turn them slightly inward. If you
must place them closer to each other,
turn them slightly outward. You might
want to experiment with your speak-
ers' placement to discover the best lo-
cation for them.
© 1994 Tandy Corporation.
All Rights Reserved.
Optimus and Radio Shack are registered trademarks used by Tandy Corporation.
Linzeum is a registered trademark of Linzeum Corporation.
