PRO-LX5 II Two-Way Die-Cast Speaker
Your PRO-LX5 II Two-Way Die-Cast
Speaker is small in size, but not in
sound! Its 5-inch polypropylene woofer
accurately tracks signals to provide out-
standing bass, while the wide-angle di-
pole tweeter produces crisp, detailed
highs with 360 dispersion.
×
Your speaker's acoustic design match-
es the woofer and tweeter with the en-
closure and damping materials to
provide amazingly smooth and broad
frequency response.
Your PRO-LX5 II can handle up to 130
watts of power. The speaker is magnet-
ically shielded, so you can safely place
it next to your television or monitor.

UNPACKING

Your PRO LX5 II is shipped in protec-
tive packing materials. Before you use
the speaker, follow these steps to un-
pack it.
Caution: To avoid
speaker's tweeter, do not touch the
tweeter's film while you are unpacking
the speaker.
1. Remove the corrugated board and
the plastic foam packing box.
2. Remove the plastic cover from the
tweeter.
3. Carefully place the top grille on the
speaker, making sure not to touch
RadioShack is a registered trademark used by Tandy Corporation.
damaging the
©
1998 Tandy Corporation.
All Rights Reserved.
Cat. No.
the tweeter's plastic film with the
cover.
Top
Grille
Plastic Foam
Front
Grille
40-4078
Corrugated
Board
Packing
Box (Top)
Plastic
Cover
Tweeter
Tweeter
Film
