HoverCam ORBIT Quick Start Manual

QUICK START GUIDE
A Wireless USB Setup
Connect Wireless Reciever dongle to computer
1
DO NOT use cable marked "power only". Reciever will power-on automatically and search for camera.
Aim Wireless Reciever antenna towards Camera's antenna
2
Line-of-sight is required. See the backside for more details.
Power-On Orbit Camera
by pressing the power button on the side of the camera.
3
Open any camera software on computer
4
We recommend using the free HoverCam Flex software downloadable from hovercam.com/software
Wait for Orbit to Connect.
5
indicators on Camera (TX) and Reciever (RX) are solid blue, connection is complete. Connection takes ~ 30 sec.
B
Wireless HDMI Setup
Mount Wireless Reciever dongle to display
1
Connect Wireless Receiver to display
2
Connect Wireless Receiver to power source
3
or USB-C to C cable to connect to USB port on display (or to wall using power brick)
Aim Wireless Reciever's antenna towards Camera's antenna
4
Line-of-sight is required. See the backside for details.
Power-On Orbit Camera
5
by pressing power button on side.
Power-On Display
6
and switch input to correct HDMI port.
Wait for Orbit to Connect.
until camera connects. When wireless status indicators on
7
Camera and Reciever are solid blue, connection
is complete. Connection takes ~ 30 seconds.
Back of
Display
Orbit Camera Wireless Receiver
(TX)
with either the USB-C to A or USB-C to C cable.
and select "HoverCam Orbit" as camera input.
Loading screen will display until camera connects. When wireless status
using the included HDMI cable.
Use either USB-C to A
Loading screen will display
4
1
2
3
Power Brick USB-C to USB-C Cable
For Charging Camera Connects to Reciever
(RX)
5 3
CAMERA CONTROLS
WHAT'S IN THE BOX
USB-C to USB-A Cable HDMI Cable
Connects to Reciever
Connects to Reciever
(HDMI Mode Only)
CHARGING
IMPORTANT: MUST USE USB-C
CABLE MARKED "POWER ONLY"
IMPORTANT: ONLY CHARGE
CAMERA USING LEFT USB-C PORT
BATTERY LIFE: ~6-8 Hrs
CHARGING TIME: ~3 Hrs
IMPORTANT: CAMERA AND RECEIVER
MUST HAVE "LINE-OF-SIGHT"
2
1
Enable Autofocus
Camera will constantly
adjust focus
Autofocus Lock
Focus will be locked until
AF is pressed again.
Battery Status
Wireless Status Indicator
Stop Recording
Note: These buttons for local recording with Micro-SD card only, but you can
download HoverCam software to take snapshots / record videos onto computer.
Freeze Image
Record Video
Take Snapshot
Wireless Status
Indicator:
USB-C to USB-C Cable
For Charging Only
Battery Indicator:
Lights Flashing 1, 2, 3: Charging
3 Lights: 75% - 100% Remaining
2 Lights: 50-75% Remaining
1 Light: 25-50% Remaining
1 Light (Flashing): Less than 25% Remaining
SEE BACKSIDE
FOR MORE INFO
4
Zoom-In
Flip 180º
Zoom-Out
Flashing: Searching for Camera
Solid: Connected
Off: Camera/Receiver Off
