Note:
If the Bluetooth connection fails or is not possible, make
sure there are no solid obstacles between your phone and
the robotic vacuum cleaner and that the two devices are
close together.
Adding the Robotic Vacuum Cleaner to the Device List via a QR Code
• The robotic vacuum cleaner can also be added to the Sencor HOME
application using the QR code provided below. On the home screen
of the application, click on the "+" icon and on the Add device screen,
click on the [–] icon in the top right hand corner.
• After scanning the QR code, you will be prompted to select a Wi-Fi
network. Select the network, enter your password and click "Next".
• You will be prompted to reset the device. Hold down the button
for about 3 seconds. Control buttons will flash. This means that the
robotic vacuum cleaner is ready for pairing. Instructions can also be
found on the application screen.
• In the app, confirm that the backlight of both buttons is flashing and
click "Next".
• Click on "Connect". Then in the Wi-Fi settings on your mobile device
connect the Wi-Fi to the robotic vacuum cleaner. Then return to the
application and wait until the pairing of the robotic vacuum cleaner is
complete.
• In the device list on the main screen, click on the icon of the robotic
vacuum cleaner to enter control interface.
QR code for adding the control panel of the robotic vacuum cleaner to the
application Sencor HOME
SRV 9120BK
Manually Adding the Robotic Vacuum Cleaner to the Device List
• On the main screen, click on "Add device" or "+" in the upper right
corner and click on "Add device".
• A screen with appliance categories and a list of appliances will appear.
• Click on "Robotic vacuum cleaners" and from the list, select the
robotic vacuum cleaner model.
• On the next screen, you will be prompted to select a Wi-Fi network.
Select the network, enter your password and click "Next".
• You will be prompted to reset the device. Hold down the button
for about 3 seconds. Control buttons will flash. This means that the
robotic vacuum cleaner is ready for pairing. Instructions can also be
found on the application screen.
• In the app, confirm that the backlight of both buttons is flashing and
click "Next".
• Click on "Connect". Then in the Wi-Fi settings on your mobile device
connect the Wi-Fi to the robotic vacuum cleaner. Then return to the
application and wait until the pairing of the robotic vacuum cleaner is
complete.
• In the device list on the main screen, click on the icon of the robotic
vacuum cleaner to enter control interface.
Wi-Fi Reset
• Press and hold the button for 3 seconds, or press the
the remote control to reset the Wi-Fi function. Control buttons will
flash.
Note:
We recommend that you turn off mobile data in your
mobile phone settings when connecting to Wi-Fi.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2023,
SRV 9185BK
.
DUST AND DIRT COLLECTION STATION
(SRV 9185BK only)
• The collection station is equipped with a dust bag into which the
robotic vacuum cleaner empties the contents of the dust container
after the cleaning is completed, or if it detects that the dust container
is full. In this case, the robot vacuum cleaner locates the collection
station and drives to it so that the opening in the dust container is
aligned with the suction opening at the bottom of the collection station.
Once contact is made, both openings open and pressure sucks
the contents of the container into the dust bag. The holes are then
closed and the robotic vacuum cleaner will start charging or continue
cleaning.
• To ensure proper operation of the collection station, make sure it is
connected to power.
Note:
The collection station can be purchased for the
SRV 9120BK model. The model number is SRX 0030.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CLEANING AND MAINTENANCE

• Before cleaning, always turn off the vacuum cleaner with the
button, place it outside the collection station / charging station and
disconnect it from the power supply.
• Never use abrasive cleaners, thinners, etc. for cleaning.
• Neglecting cleaning and maintenance may negatively affect
the working order of the vacuum cleaner and lead to its reduced
performance.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ROBOTIC VACUUM CLEANER
Emptying the Dust Container (model SRV 9185BK)
• On the SRV 9185BK model, the container is automatically emptied
into the dust collection container both after every use and also during
the cleaning process when the vacuum cleaner detects the maximum
amount of dirt and dust in the container. It is possible to set how
frequently the dust container will be emptied out.
Emptying the Dust Container (model SRV 9120BK)
1. In order to be able to remove the dust container, press the dust
container release button and pull the dust container out of the
vacuum cleaner – see figure G1.
2. Take the dust container over a garbage bin and turn it upside down
so that the lid of the dust container points downwards.
3. Press the dust container lid release button and carefully tilt open the
lid. Dump the contents of the dust container into the garbage bin –
see figure G2.
4. Close the lid and gently push on it until you hear a click. This
indicates that the lid is properly secured in place.
Cleaning the Dust Container
1. In order to be able to remove the dust container, press the dust
container release button and pull the dust container out of the
vacuum cleaner – see figures G1.
2. Press the dust container lid lock and tilt open the dust container lid.
3. Press the coarse filter lock. Take the coarse filter, foam filter and the
HEPA filter out of the lid – see figure G3.
4. Tap out the HEPA filter and the foam filter and remove the dirt and
dust from them using a fine brush or soft wiping cloth. In the event of
heavy soiling, you can vacuum them out using a different vacuum
button on
cleaner with an attached brush nozzle. Do not wash the HEPA filter
in water. This may damage the lid. In the event that the HEPA filter
is already heavily soiled or deformed, replace it with a new one. We
recommend replacing the HEPA filter based on the frequency of use
at least once every six months.
5. Rinse the coarse filter under running water and wipe dry with a clean
wiping cloth.
6. Wipe the dust container out using a lightly dampened sponge and
wipe dry using a clean wiping cloth. If necessary, you can pour
a small amount of water into the dust container and wipe it out with
a sponge. Then thoroughly wipe it dry using a clean wiping cloth.
7. Insert the HEPA filter, the foam filter and then the coarse filter into
the area in the lid. Gently push down on the coarse filter until you
