Item #1009 484 659
Model #LR1321-RGBW-5M-
SENSER-1024
USE AND CARE GUIDE
16.4 ft RGBW COLOR CHANGING
RECHARGEABLE BATTERY STRIP
LIGHT WITH MOTION SENSOR
Questions, problems, missing parts? Before returning to the
store, call EcoSmart Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday
9 a.m. - 6 p.m., EST, Saturday
1-800-910-7164
HOMEDEPOT.COM/ECOSMART
Advertisement
Related Manuals for EcoSmart LR1321-RGBW-5MSENSER-1024
Summary of Contents for EcoSmart LR1321-RGBW-5MSENSER-1024
- Page 1 16.4 ft RGBW COLOR CHANGING RECHARGEABLE BATTERY STRIP LIGHT WITH MOTION SENSOR Questions, problems, missing parts? Before returning to the store, call EcoSmart Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday 9 a.m. - 6 p.m., EST, Saturday 1-800-910-7164...
-
Page 2: Table Of Contents
Table of Contents Installation ......... 6 Table Of Contents......2 Safety Information ...... 2 Operation ........8 Warranty ........4 Care and Cleaning ....11 Pre-Installation ......5 Safety Information PRECAUTIONS Read and understand this entire manual before you attempt to install or operate this product. - Page 3 Safety Information (continued) □ Increase the separation between the equipment and receiver. □ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. □ Consult the dealer or an experienced radio/TV technician for help. NOTICE: This device complies with Part 15 of the FCC Rules.
-
Page 4: Warranty
This warranty shall not apply to the nish on any portion of the product, such as surface and/or weathering, as this is considered normal wear and tear. Contact the Customer Service Team at 1-800-910-7164 or visit www.HomeDepot.com/EcoSmart. -
Page 5: Pre-Installation
Pre-Installation PACKAGE CONTENTS Part Description Quantity Strip light 1000mAh lithium rechargeable controller Iron sheet with adhesive USB charging cable Remote control Mounting Clips Screws... -
Page 6: Installation
Installation Prepare the strip light □ (optional) Shorten the strip light (A) to the desired length by cutting along the black lines with the scissor mark. Install the strip light □ Ensure that the mounting location is even, clean, and dry. □... - Page 7 Installation(continued) Connect the controller □ Connect the strip light with the controller according to the arrow indicator Install the controller □ Remove the protective lm from the back of the iron sheet(C) □ Find a proper place to mount it and press to reinforce it □...
-
Page 8: Operation
Operation Remote Operation CAUTION: The remote control included utilizes a 3V CR2025 battery; Do not dispose of batteries in fire as they may explode or leak. Please dispose of used batteries immediately and safely. Only replace with the same battery type. Examine devices and make sure the battery compartment is correctly secured, e.g. - Page 9 Operation(continued) Button Description ON: Press to turn on the light OFF: Press to turn off the light Dynamic Mode Button: * 1-color ash: red, green, blue, orange, yellow, cyan, purple. Press switch button(7) to choose color then press mode button(3) to achieve ash effect * 3-color jump: red, green, blue * 7-color jump: red, green blue, yellow, cyan.
- Page 10 Operation(continued) Controller Operation WARNING: Do not try to replace the lithium polymer battery. The rechargeable battery in controller is not replaceable. NOTE: 1. The controller is rechargeable and detachable. Get the controller fully charged before use it. 2. When the remote and the controller set the motion mode together, the nal effect depends on the last command...
-
Page 11: Care And Cleaning
Operation(continued) Description IR Remote PIR Motion Receiver Dynamic Mode Button: * 1-color ash: red, green, blue, orange, yellow, cyan, purple. Press switch button(4) to choose color then press dynamic button(3) to achieve ash effect * 3-color jump: red, green, blue * 7-color jump: red, green blue, yellow, cyan. - Page 12 Questions, problems, missing parts? Before returning to the store, call EcoSmart Customer Service 8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m.-6p.m., EST, Saturday 1-800-910-7164 HOMEDEPOT.COM/ECOSMART Retain this manual for future use.
