U-Line CO29BTP Specifications

COMBO ICE MAKER/REFRIGERATOR

Model COMBO 29BTP

FEATURES

1. Manual Defrost Ice Maker
2. Stainless hinges and mounting hardware
3. Travel pin – Factory installed
4. 2.1 cubic feet of refrigeration
5. Front vented for built-in installation
6. No drain required for water
7. Conserves on water
8. Field reversible door with integrated door
handle
9. Accepts custom door panel
10. In-door storage
11. Tempered glass shelves

ADDITIONAL FEATURES:

• See through, removable ice bucket, stores 13 lbs. of ice
• Available in 110/115V – 60 cycle or 220/230 – 50/60 cycle
• Shipping weight: 97 lbs.
• Black vinyl clad steel cabinet and door panel
• Door panel size: H 21-13/32" x W 19-13/16"
KCC Printed in U.S.A.
20-13/16 (52.9)
* WATER
VALVE
LOCATION
* POWER CORD
3-5/16
(8.4)
3-5/16
(8.4)
* ON BACK OF UNIT

BENEFITS

Greater daily ice production capacity. Less affected by warmer ambients.
Produces up to 18 lbs. of ice per day in a 70° ambient temperature.
Corrosive resistant.
Helps keep the door secure when en route. Pre-installed at factory.
Ice making and refrigeration in one compact unit.
No need for extra fans, air space, or special venting to the outside of the
cabin. Do not obstruct front grille.
Easy and inexpensive to install. Only needs 1/4" outside diameter water
line connection.
Only 2-1/4 gallons of water needed to produce approximately 18 lbs. of ice.
Flexible installation capabilities to ensure easy access. With left hand door
swing installation, allow for 145° door opening to ensure easy removal of
ice bin.
Match surrounding cabinets.
2 door shelves with clear bottle retainers for greater storage and easy
access.
Generous amount of shelving space, easy to clean, helps contain spills.
All specifications subject to change without notice.
28-1/2
(72.4)
1-9/16
(4.0)
4-1/2
(11.4)
1-7/16
(3.7)
INCHES (CENTIMETERS)
8900 N. 55th Street
Milwaukee, Wisconsin 53223
(414) 354-0300
FAX (414) 354-7905
www.u-line.com
24 (61.0)
WATER INLET
VALVE
21-7/16 (54.5)
P/N COMBO 29BTP
