User's Manual
All U-Line units
Stainless Steel models) have
a zero clearance for the door
to open (see Figure 1). See
BUILT-IN INSTALLATION for
additional clearance require-
ments. Stainless Steel mod-
els require a minimum of 2-
1/2" door handle clearance
when installed against a wall.
3. Position the unit to allow free air flow through the front grille
(see Figure 2).
4. Wipe out inside of unit with a damp cloth.
5. Final finish of the wooden wine rack trim must be applied at least
24 hours before re-installing the wooden rack trim into the cabinet.
6. Be sure to install the Anti-Tip brackets. Follow the instructions pro-
vided with the Anti-Tip bracket kit.
NOTE
(except
DOOR
SWING
4
3
5
2
6
7
1
Figure 2
10
CABINET
OR WALL
0"
CLEARANCE
NEEDED
UL124A
Figure 1
OFF
ON
UL307
