STC SMART TOUCH CONTROLS - HP4-X 25/35 FM
Hopper Ban
OPERATING MANUAL
Contents
FM DRYERS ................................................................................................................... 2
INSTALLATION PROCEDURE ....................................................................................... 5
QUICK START-UP GUIDE .............................................................................................. 6
DRYER OPERATION TROUBLE SHOOTING ................................................................ 6
PART LIST ...................................................................................................................... 8
SMART TOUCH CONTROLS GUIDE ........................................................................... 10
MAIN OPERATING SCREEN: ...................................................................................... 10
SYSTEM SETUP SCREEN: .......................................................................................... 11
7 DAY TIMER: ............................................................................................................... 11
FACTORY SETTINGS: ................................................................................................. 12
SETBACK (option) ........................................................................................................ 13
LOADER RECEIVER (option) ....................................................................................... 15
RECIPE MENU: ............................................................................................................ 16
DIAGNOSTICS SCREEN: ............................................................................................. 17
INPUTS: ........................................................................................................................ 17
OUTPUTS: .................................................................................................................... 18
TEMPS: ......................................................................................................................... 18
TREND GRAPHS: ......................................................................................................... 19
EVENT LOG: ................................................................................................................. 20
ALARMS: ...................................................................................................................... 21
DIGITAL KEYPAD SCREEN: ........................................................................................ 22
ALPHA-NUMERIC KEYPAD: ........................................................................................ 23
TROUBLESHOOTING: ................................................................................................. 24
1
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Dri-Air Industries FM Series
Summary of Contents for Dri-Air Industries FM Series
-
Page 1: Table Of Contents
STC SMART TOUCH CONTROLS – HP4-X 25/35 FM Hopper Ban OPERATING MANUAL Contents FM DRYERS ........................2 INSTALLATION PROCEDURE ..................5 QUICK START-UP GUIDE ....................6 DRYER OPERATION TROUBLE SHOOTING ..............6 PART LIST ........................8 SMART TOUCH CONTROLS GUIDE ................10 MAIN OPERATING SCREEN: .................. -
Page 2: Fm Dryers
FM DRYERS FEATURES: The FM series dryers are the traditional dryer and hopper where the dryer is on the floor positioned next to the molding machine and the hopper is mounted on top of the molding machine. They are ideal where floor space is limited and material changes are infrequent. The FM dryer series utilize the HP4-X four bed design that provides a constant supply of dry air to the material hopper. - Page 3 STC Smart Touch Controls The FM series are supplied with the Smart Touch Control (STC). The new STC (Smart Touch Control) was introduced for optimum operation of the dryer and is as user friendly as possible. The easy-to-see, menu driven HMI allows access to all operating parameters and enables the operator to navigate through all settings and data.
-
Page 5: Installation Procedure
INSTALLATION PROCEDURE Electrical Connection: Open electrical access door on the front of the machine by turning the disconnect off and turning the lower clamping screw 1/2 turn counterclockwise. Locate the disconnect by following the operating handle down to the electrical panel. Insert the incoming power cable or conduit through the hole provided on the side of the machine. -
Page 6: Quick Start-Up Guide
QUICK START-UP GUIDE Operating this unit is very simple. Once the dryer is connected to the facility power supply, the unit can be started by turning the disconnect handle located in the upper right-hand corner of the electrical panel enclosure to the ON position and pressing the START button on the HMI. To shut the dryer off, simply push the STOP button on the HMI. - Page 7 Control Circuit: 11. Using the PLC motherboard indicator lights as a guide for the dryer regeneration cycle, check that all inputs/outputs are proper for the part of the regeneration cycle that the machine is in. 12. Monitor the PLC output lights to ensure the corresponding LED on the power solid state relay is illuminated and there is an output voltage to the heater.
-
Page 8: Part List
PART LIST Description Part # Amount Valve Zone STC 24V Assembly 89167 Smart touch Blower 25CFM 3PH 86867 Sensor RH STC Control for 85374 84936 RH Board Assembly Gasket 6” for 18-35 towers 81028 Filter Element 25-35 CFM for 81055 DAC 25-35 CFM Dryers Thermocouple 1/8”... - Page 9 Description Part # Amount Contactor 12A 600V 4P 24VDC 85355 Overload .4-.63 Amp Overload .63-1 Amp 85358 – LS Interchangeable w/ Carlo 85359 Gavazzi Relay SS 40A 480V 2P 15-32 85364 Switch Disconnect 40A (Handle, 85365 Shaft, Switch) Relay 1P DT 24VDC 6A card 89384 wago STC HMI...
-
Page 10: Smart Touch Controls Guide
SMART TOUCH CONTROLS GUIDE MAIN OPERATING SCREEN: The operating screen displays all of the dryer performance information in an easy-to-read format visible from a long distance. The large STOP/START button is incorporated into the screen rather than being located remotely. All common operator inputs are located on this main screen including starting and stopping the dryer, closed loop loader... -
Page 11: System Setup Screen
SYSTEM SETUP SCREEN: To enter the setup screen, first tap the main menu button in the top right of the touch screen, then select the “SETUP” button. All of the parameters of the dryer are accessed through this screen that is very explanative. To access the area of interest, simply press the associated button. -
Page 12: Factory Settings
To enter a start or stop time, press the time box on the day selected and a keypad will be displayed to make the entry desired. Note that 99 in the hour field turns off the time for that setting. All times are displayed in military time where the day is 24 hours. -
Page 13: Setback (Option)
SETBACK (OPTION) Temperature setback allows the dryer to automatically lower the process temperature after a period of time to keep from over drying the material. Here you can enable or disable the setback as well as setting setback parameters. The factory set parameters will work for most setback applications. - Page 14 Restore Temp = The temperature that the setback thermocouple must drop down to or below for it to come out setback and revert to the original setpoint. (Settable 0-999℉) Factory default settings will work fine for most temperature setback applications.
-
Page 15: Loader Receiver (Option)
LOADER RECEIVER (OPTION) For those dryers with the closed-loop loader option to load the dried material to the press, this screen is used to configure the loading cycle. The FILL TIME is the time in seconds the loader sends material to the receiver and is normally in the range of 5 to 10 seconds. -
Page 16: Recipe Menu
RECIPE MENU: *PDII Pictured The process temperature can also be set using the RECIPE MENU screen. From the MAIN OPERATING SCREEN, press the MAIN MENU, then press the RECIPE button to access this screen. To change the name of the recipe or any other designation you prefer and the temperature, press the section to change and a screen will appear to make the changes. -
Page 17: Diagnostics Screen
DIAGNOSTICS SCREEN: To enter the diagnostics screen, first tap the main menu button in the top right of the touch screen, and then select the “DIAGNOSTICS” button. All diagnostic information about the dryer is in this screen, this includes temperature data, alarms, and event logs. -
Page 18: Outputs
OUTPUTS: The outputs screen displays different sources of outputs, in this screen you can independently tell which output sources are on or off. You can also switch from Auto to Manual mode to test output operation. TEMPS: The temps screen is used to display all of the thermocouple temperatures to trouble shoot a problem. -
Page 19: Trend Graphs
Write CSV will write a CSV file to an SD card; this is how you can send a file to Dri-Air Industries. Note: the Write CSV button will only write a CSV file for the data on the current screen, if you want other tracked data to be written to an SD card you will need to press the Write CSV file on those screens as well. -
Page 20: Event Log
Write CSV will write a CSV file to an SD card; this is how you can send a file to Dri-Air Industries. Note: the Write CSV button will only write a CSV file for the data on the current screen, if you want other tracked data to be written to an SD card you will need to press the Write CSV file on those screens as well. -
Page 21: Alarms
Write CSV will write a CSV file to an SD card; this is how you can send a file to Dri-Air Industries. Note: the Write CSV button will only write a CSV file for the data on the current screen, if you want other tracked data to be written to an SD card you will need to press the Write CSV file on those screens as well. -
Page 22: Digital Keypad Screen
DIGITAL KEYPAD SCREEN: This keypad is used to enter all temperatures, times, and digital information. Press the desired numbers and then ENT to make the change. Close Clear entry Unused... -
Page 23: Alpha-Numeric Keypad
ALPHA-NUMERIC KEYPAD: To enter a new recipe or other designation, press the center description area and the keypad as shown will appear. Type the new entry using the keypad and press enter. To enter the temperature, press the associated temperature display to access the entry keypad. SPACE Close out of keyboard Clear entry... -
Page 24: Troubleshooting
TROUBLESHOOTING: Below is a list of the possible error codes that might appear if an error occurs in a dryer. Fault_Overload_Alarm -Blower overload has tripped, Check incoming power and fuses Fault_L1_Zone1_Bottom_TC_Backwrd -Bottom left thermocouple on desiccant bed, Check thermocouple plug connection (white wire +, Red wire -) Fault_L1_Zone1_Bottom_TC_Broken -Bottom left thermocouple broken, Check thermocouple and thermocouple plug connections... - Page 25 Fault_P1_Process_Hopper1_TC_Backwrd -Hopper 1 air inlet thermocouple, Check thermocouple plug connection (white wire +, Red wire - Fault_P1_Process_Hopper1_TC_Broken - Hopper 1 air inlet thermocouple, Check thermocouple and thermocouple plug connections Fault_S1_Setback_Hopper1_TC_Backwrd -Hopper 1 return air thermocouple, Check thermocouple plug connection (white wire +, Red wire Fault_S1_Setback_Hopper1_TC_Broken - Hopper 1 return air thermocouple, Check thermocouple and thermocouple plug connections Fault_L2_Zone2_Bottom_TC_Backwrd...
- Page 26 Fault_H2_Zone2_Top_TC_Backwrd -Top thermocouple on right, Check thermocouple plug connection (white wire +, Red wire -) Fault_H2_Zone2_Top_TC_Broken -Top thermocouple on right, Check thermocouple and thermocouple plug connections Fault_P2_Process_Hopper2_TC_Backwrd -Hopper 2 air inlet thermocouple wiring backwards, Check thermocouple plug connection (white wire +, Red wire -) Fault_P2_Process_Hopper2_TC_Broken -Hopper 2 air inlet thermocouple broken, Check thermocouple and thermocouple plug connections...
- Page 27 Fault_P1_Over_Temp -Hopper 1 air inlet temperature alarm, Check solid state relay and zone value position Fault_P2_Over_Temp - Hopper 2 air inlet temperature alarm, Check solid state relay and zone value position Fault_Hopper1_Loop_Break -Hopper 1 air inlet not coming up to set point, Check thermocouple position, Check process heater element and solid-state relay Fault_Hopper2_Loop_Break - Hopper 2 air inlet not coming up to set point, Check thermocouple position, Check process...
- Page 28 -Material level in hopper 1 below proximity sensor, Check material levels, Check proximity switch calibration Alarm_Hopper2_Low_Material - Material level in hopper 2 below proximity sensor, Check material levels, Check proximity switch calibration Alarm_High_Dew_Point_Level -Dew point exceeded set alarm level, Check dryer filter, Check desiccant for contamination Fault_L1_Over_Temp -Zone 1 bottom thermocouple exceeded 850℉, Check thermocouple and plug connection, Check zone 1 bottom heater relay...
- Page 29 Please consult Dri-Air for product dimensions as this is a model representation.
