Dri-Air Industries AHM 2-4 Operating Manual

Adc advanced dryer control
Hide thumbs
Table of Contents

Advertisement

Quick Links

ADC ADVANCED DRYER CONTROL - AHM 2-4
Hopper Ban
OPERATING MANUAL
Contents
HM DRYERS ................................................................................................................... 2
INSTALLATION PROCEDURE ....................................................................................... 5
QUICK START-UP GUIDE .............................................................................................. 5
DRYER OPERATION TROUBLE SHOOTING ................................................................ 7
PART LIST ...................................................................................................................... 9
ADVANCED DRYER CONTROLS GUIDE .................................................................... 11
MAIN OPERATING SCREEN: ...................................................................................... 11
MENU INSTRUCTIONS: ............................................................................................... 11
TO START DRYER: ...................................................................................................... 12
TO SET TEMPERATURE: ............................................................................................ 12
MAIN MENU SELECTIONS .......................................................................................... 13
MAIN MENU SELECTIONS .......................................................................................... 14
MENU DEFINITIONS: ................................................................................................... 17
OTHER FEATURES: ..................................................................................................... 19
SETTINGS: ................................................................................................................... 20
ERROR MESSAGES: ................................................................................................... 21
TEMPERATURE SETBACK THEORY .......................................................................... 22
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AHM 2-4 and is the answer not in the manual?

Questions and answers

Related Manuals for Dri-Air Industries AHM 2-4

Summary of Contents for Dri-Air Industries AHM 2-4

  • Page 1: Table Of Contents

    ADC ADVANCED DRYER CONTROL – AHM 2-4 Hopper Ban OPERATING MANUAL Contents HM DRYERS ........................2 INSTALLATION PROCEDURE ..................5 QUICK START-UP GUIDE ....................5 DRYER OPERATION TROUBLE SHOOTING ..............7 PART LIST ........................9 ADVANCED DRYER CONTROLS GUIDE ..............11 MAIN OPERATING SCREEN: ..................

  • Page 2: Hm Dryers

    HM DRYERS FEATURES: The HM series dryers are a fully assembled dryer and hopper combination where the dryer is mounted on the hopper to be positioned on top of molding machines. They are ideal where floor space is not available and material changes are infrequent. The HM dryer series utilize the ARID-X dual bed design that provides a constant supply of dry air to the material hopper.
  • Page 3 ADC Advanced Dryer Controls The ARID-X series can be supplied with the Advanced Dryer Control (ADC). The new ADC (Advanced Dryer Control) was introduced for optimum operation of the dryer and is as user friendly as possible. The easy-to-see alphanumeric display indicates all operating parameters and leads the operator through a menu driven program for all settings and information.

  • Page 5: Installation Procedure

    INSTALLATION PROCEDURE Electrical Connection: Open electrical access door on the front of the machine by turning the disconnect off and turning the lower clamping screw 1/2 turn counterclockwise. Locate the disconnect by following the operating handle down to the electrical panel. Insert the incoming power cable or conduit through the hole provided on the side of the machine.
  • Page 6 Temperature: Set the process temperature by either pressing the “TEMP SET” button or “MENU” button. High Temp Alarm Delta: Press the “MENU” button and then arrow down to the ALARM MENU. Press enter to access setting. Enter a new delta using the keypad and press ENTER. Remember this setting is a delta above the set temperature and not an actual temperature.

  • Page 7: Dryer Operation Trouble Shooting

    DRYER OPERATION TROUBLE SHOOTING The Advanced Dryer Controls were designed for quick diagnosis of problems. .The following steps should be done before proceeding with other diagnostic steps. Alarm codes that occur on the ADC controls are further detailed in the controls section of this manual. Check the Power Circuit: 1.
  • Page 8 If the temp exceeds the set point check the following: 1. Remove the hose from the top of the hopper to check air flow. There should be air flow out of the hopper with a suction on the hose. If there is little or no flow, check the inlet hose.

  • Page 9: Part List

    PART LIST Description Part # Amount Valve Zone STC 24V Assembly 89167 Smart touch Blower 25CFM 3PH 86867 Sensor RH ADC Control for 85374 84936 RH Board Assembly Gasket 6” for 18-35 towers 81028 Filter Element 25-35 CFM 81055 Dryers Thermocouple 1/8”...
  • Page 10 Description Part # Amount Contactor 12A 600V 4P 24VDC 85355 Overload .4-.63 Amp Overload .63-1 Amp 85358 – LS Interchangeable w/ Carlo 85359 Gavazzi Relay SS 40A 480V 2P 15-32 85364 Switch Disconnect 40A (Handle, 85365 Shaft, Switch) Relay 1P DT 24VDC 6A card 89384 wago ADC Display Board...

  • Page 11: Advanced Dryer Controls Guide

    ADVANCED DRYER CONTROLS GUIDE Dryer MAIN OPERATING SCREEN: Process 180F Indicates Dryer is on.............. Setpoint (180) *Indicates Setback is Turned On Dewpoint -45 Z1H Indicates Dryer is operating at 180 °F........Dryer Process 180F Setpoint (180) Dewpoint -45 Z1H Indicates Dryer is in setback mode Dryer with a new setting of (180 °F)..........

  • Page 12: To Start Dryer

    TO START DRYER: Turn power on using disconnect. Dri-Air Industries Screen will show: >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>> Dryer is OFF Check for correct day and time. Time: Mon 09:42:05 Press Start Initializing Dryer Please Wait . . . Dryer is checking the rotation.

  • Page 13: Main Menu Selections

    MAIN MENU SELECTIONS Main Menu Set Process Temp Set temperature at hopper............↑ or ↓ to Scroll Use Enter to select Enable or disable temperature setback Main Menu Adjust delta Setback Setup Adjust setback temperature inhibit time........↑ or ↓ to Scroll Use Enter to select Set /Start and /Stop time per day.

  • Page 14: Main Menu Selections

    MAIN MENU SELECTIONS Main Menu Main Menu Setback Setup Set Process Temp ↑ or ↓ to Scroll ↑ or ↓ to Scroll Use Enter to select Use Enter to select Process Temp = ___ Enter password Key in new value Then press Enter Enter key to accept or Clear to Exit...
  • Page 15 MAIN MENU SELECTIONS (cont.) Main Menu Main Menu Alarm Setup Seven Day Timer ↑ or ↓ to Scroll ↑ or ↓ to Scroll Use Enter to select Use Enter to select Main>7Day Menu Setup Sunday ↑ or ↓ to Scroll Use Enter to select Start Time Stop Main>Alarm Menu...
  • Page 16 MAIN MENU SELECTIONS (cont.) Main Menu Main Menu Diagnostics System Setup ↑ or ↓ to Scroll ↑ or ↓ to Scroll Use Enter to select Use Enter to select Main>Diag Menu Select F or C Main>System Menu This will show the View Event Log Press 1 to turn F Degrees F or C,...

  • Page 17: Menu Definitions

    MENU DEFINITIONS: 1. Set Process Temp This screen allows the operator to easily change the process temperature. 2. Setback Setup For those dryers with the setback option, this screen allows the operator to activate the setback option and to enter the setback delta from the process temperature for the setback temperature.
  • Page 18 • Loader Delay time (With optional closed loop loader) 6. Factory Setup This section is reserved for factory settings and can only be accessed by a password. If settings need to be changed in the field, consult one of our servicemen to make the necessary changes.

  • Page 19: Other Features

    OTHER FEATURES: Blower Error If for any reason the phasing of the incoming power is incorrect, the blower will run in the wrong direction causing the dryer to malfunction. If the blower direction is not correct, the dryer will shut down and an error will be displayed. This condition can occur upon installation or when moved within the plant.

  • Page 20: Settings

    SETTINGS: Temperature: Set the process temperature by either pressing the “TEMP SET” button or “MENU” button. High Temp Alarm Delta: Press the “MENU” button and then arrow down to the ALARM MENU. Press enter to access setting. Enter a new delta using the keypad and press ENTER. Remember this setting is a delta above the set temperature and not an actual temperature.

  • Page 21: Error Messages

    ERROR MESSAGES: There are a few conditions that will cause an alarm condition. Check the following areas: • Clean or replace return air filter. Turn off the dryer while cleaning! Blockage in this area will affect the performance of the dryer and may cause an alarm. •...

  • Page 22: Temperature Setback Theory

    dryer will shut down and an error will be displayed. This condition can occur upon installation or when moved within the plant. TEMPERATURE SETBACK THEORY The optional temperature setback feature for the ADC control prevents over drying of the material due to excessive residence in a drying hopper at the suggested drying temperatures. This is especially true for Nylon, which can be over dried leading to degradation of the resin resulting in molding problems and brittle parts.
  • Page 23 Setback Display Selection of the setback option is shown on the main screen by an asterisk * prior to the hopper number. Parenthesis around the setpoint temperature indicates the temperature has been setback. The setback temperature is then displayed.
