Risco RVCM11W15 Quick Start Manual

Cube 2mp wi-fi camera
Hide thumbs
Table of Contents
  • Defining IP Camera Settings
  • Product Specification
  • Spécifications du Produit
  • Especificaciones del Producto
  • Specifiche Tecniche

Advertisement

Available languages

Available languages

Quick Links

Download this manual
VUpoint
Cube 2MP Wi-Fi Camera
Model: RVCM11W15
EN
FR
ES
IT
Quick Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RVCM11W15 and is the answer not in the manual?

Questions and answers

Related Manuals for Risco RVCM11W15

Summary of Contents for Risco RVCM11W15

  • Page 1 VUpoint Cube 2MP Wi-Fi Camera Model: RVCM11W15 Quick Guide...
  • Page 2 Language Page...
  • Page 3 Reset/WPS button for 8 seconds; the light turns off. Indication Status Green light slow IP Camera is not connected to the RISCO Cloud. Please check for flashing internet connection. Green light steady on IP Camera is successfully connected to the RISCO Cloud.

  • Page 4: Defining Ip Camera Settings

    Defining IP Camera Settings Step 1 Connect one end of the network cable (LAN) to the camera Ethernet port and the other side to your router. Power up the camera with an appropriate power supply. Step 2 If the camera is connected to a VUpoint NVR, refer to the VUpoint Network Video Recorder Installation Guide for further installation instructions.
  • Page 5 Step 5 Select a wireless network from the available list If your network is password protected, enter a password into the displayed password field Click for Wi-Fi network connection Step 6 Click OK...

  • Page 6: Product Specification

    Product Specification Parameter Description Image Sensor 1/2.7” 2Megapixel progressive CMOS IR Distance 10 m Focal Length 2.8 mm Power Supply 12V DC, Power Consumption <3.5W Wi-Fi Power Output 20dBm max. Wi-Fi Frequency 2.4 GHz...
  • Page 7 8 secondes ; le voyant s'éteint. Logement pour carte Micro SD Indication État Voyant vert clignotant lentement La caméra IP n'est pas connectée au RISCO Cloud. Vérifiez la connexion Internet. Voyant vert allumé normalement La caméra IP a bien été connectée au RISCO Cloud.
  • Page 8 Définition des paramètres de la caméra IP Étape 1 Raccordez l'une des extrémités du câble réseau (LAN) au port Ethernet de la caméra, et l'autre extrémité à votre routeur. Alimentez la caméra avec une alimentation appropriée. Étape 2 Si la caméra est raccordée à un enregistreur vidéo réseau (NVR) VUpoint, consultez le guide d’installation du NVR VUpoint pour obtenir des instructions d’installation.
  • Page 9 Étape 5 Sélectionnez un réseau sans fil dans la liste Si votre réseau est protégé par mot de passe, saisissez le mot de passe dans le champ prévu à cet effet Cliquez pour établir la connexion au réseau Wi-Fi Étape 6 Cliquez sur...

  • Page 10: Spécifications Du Produit

    Spécifications du produit Paramètre Description Capteur d'image CMOS 1/2.7” de 2 Mégapixel progressif Distance IR 10 m Focale 2.8 mm Alimentation 12V DC Consommation <3.5W Puissance disponible Wi-Fi 20dBm max. Fréquence Wi-Fi 2.4 GHz...
  • Page 11 Ranura para tarjeta Micro SD Indicación Significado Verde con parpadeo lento La cámara IP no está conectada a RISCO Cloud. Compruebe la conexión a Internet. Verde normalmente encendido La cámara IP está conectada correctamente a RISCO Cloud.
  • Page 12 Definiendo la configuración de la cámara IP Paso 1 Conecte un extremo del cable de red (LAN) al puerto Ethernet de la cámara y el otro extremo al router. Paso 2 Si la cámara está conectada a un NVR de VUpoint, consulte la Guía del grabador de vídeo en red (NVR) de VUpoint para ver más instrucciones de instalación.
  • Page 13 Paso 5 Seleccione una red inalámbrica de la lista Si la red está protegida con contraseña, introduzca una contraseña en el campo de contraseña Pulse para establecer la conexión de red Wi-Fi Paso 6 Pulse OK...

  • Page 14: Especificaciones Del Producto

    Especificaciones del producto Parámetro Descripción Sensor de imagen 1/2.7” 2Megapixel CMOS progresivo Distancia IR 10 m Distancia focal 2.8 mm Fuente de alimentación 12V DC Consumo de energía <3.5W Salida de alimentación Wi-Fi 20dBm max. Frecuencia Wi-Fi 2.4 GHz...
  • Page 15 Reset/WPS per 8 secondi; l’indicatore luminoso si spegnerà. Vano Micro SD Stato LED Significato Lampeggio lento del La telecamera non è connessa al cloud RISCO. Controllare la LED verde connessione internet. LED verde accesa La telecamera è connessa al cloud RISCO.
  • Page 16 Configurazione parametri telecamera IP Passo 1 Collegare un cavo LAN alla porta ethernet della telecamera e con l’altro capo del cavo collegarsi al router. Alimentare la telecamera con un alimentatore appropriato. Passo 2 Se la videocamera è collegata a un NVR VUpoint, consultare la Guida all'installazione del videoregistratore di rete VUpoint per ulteriori istruzioni di installazione.
  • Page 17 Passo 5 Inserire la password Selezionare della rete una rete WiFi WiFi, se dalla lista protetta e delle reti cliccare su disponibili Connetti Passo 6 Cliccare su OK...

  • Page 18: Specifiche Tecniche

    Specifiche Tecniche Parametro Descrizione Sensore video 1/2.7” 2Megapixel progressivo CMOS Distanza a IR 10 m Lunghezza Focale 2.8 mm Alimentatore 12V DC Assorbimento <3.5W Potenza trasmessa Wi-Fi 20dBm max. Frequenza Wi-Fi 2.4 GHz...
  • Page 19 Rapport de Conformité de RED: Par la présente, RISCO Group, déclare cet équipement est en conformité aux conditions essentielles et à d'autres dispositions appropriées de la directive 2014/53/EU. Vous pouvez trouver la copie complète de la déclaration de conformité à la directive 2014/53/EU sur notre site web, à l’adresse suivante : www.riscogroup.com.
  • Page 20 RISCO, for a period of (i) 24 months from the date of delivery of the Product ( the “Warranty Period”). This Limited Warranty covers the Product only within the country where the Product was originally purchased and only covers Products purchased as new.
  • Page 21 Software and applications distributed or made available by RISCO in conjunction with the Product (with or without the RISCO brand), including, but not limited to system software, as well as P2P services or any other service made available by RISCO in relation to the Product, are not covered under this Limited Warranty.
  • Page 22 FACILITIES, INCLUDING THE INTERNET, GSM OR OTHER MEANS OF COMMUNICATIONS AND THAT RISCO’S PRODUCTS, MAY BE SUBJECT TO LIMITATIONS, DELAYS, AND OTHER PROBLEMS INHERENT IN THE USE OF SUCH MEANS OF COMMUNICATIONS. RISCO IS NOT RESPONSIBLE FOR ANY DELAYS, DELIVERY FAILURES, OR OTHER DAMAGE RESULTING FROM SUCH PROBLEMS.
  • Page 23 Contacting RISCO RISCO Group is committed to customer service and Product support. You can contact us through our website (www.riscogroup.com) or at the following telephone and fax numbers: United Kingdom Belgium (Benelux) Tel: +44-(0)-161-655-5500 Tel: +32-2522-7622 support-uk@riscogroup.com support-be@riscogroup.com Italy Tel: +39-02-66590054 Tel: +1-631-719-4400 support-it@riscogroup.com...
  • Page 24 All rights reserved. No part of this document may be reproduced in any form without prior written permission from the publisher. © RISCO Group, 03/2021. All rights reserved. 5IN2889 B...
