The AK4951A is a low power 24-bit stereo CODEC with a microphone, headphone and speaker
amplifiers.
The AK4951A supports sampling frequency from 8kHz to 48kHz. It is suitable for a wide range of
application from speech signal processing for narrowband, wideband and super wideband to sound
signal processing for audio band.
The input circuits include a microphone amplifier, an automatic wind noise reduction filter of the
proprietary algorithms and a high performance digital ALC (automatic level control) circuit, therefore the
AK4951A can record with high-quality sound regardless of whether indoors or outdoors. In addition, the
output circuits include a cap-less headphone amplifier with a negative voltage generated by charge pump
circuit and a speaker amplifier with 1W output power. It is suitable for various products as well as portable
applications with recording/playback function.
The AK4951A are available in a small 32-pin QFN (4mm x 4mm, 0.4mm pitch) package saving mounting
area on the board.
Application:
 IP Camera
 Digital Camera
 IC Recorder
 Tablet
 Wireless Headphone
 Headset
1.
016001936-E-00
Arrow.com.
Downloaded from
24bit Stereo CODEC with MIC/HP/SPK-AMP
Recording Functions
 Analog Input: 3 Stereo Single-ended inputs with Selectors
 Microphone Amplifier: +30dB ~ 0dB, 3dB Step
 Microphone Power Supply: 2.0V or 2.4V, Noise Level= 108dBV
 Digital ALC (Automatic Level Control)
- Setting Range: +36dB  52.5dB, 0.375dB Step & Mute
 ADC Performance: S/(N+D): 83dB, DR, S/N: 88dB (MIC-Amp=+18dB)
S/(N+D): 85dB, DR, S/N: 96dB (MIC-Amp=0dB)
 Microphone Sensitivity Correction
 Automatic Wind Noise Reduction Filter
Selectable voice peak detection mode
 5-Band Notch Filter: Include Dynamic Gain Control
 Stereo Separation Emphasis Circuit
 Digital Microphone Interface

1. General Description

2. Features

- 1 -
[AK4951A]
AK4951A
2016/03
