Tyco 1529L User Manual
Tyco 1529L User Manual

Tyco 1529L User Manual

15” lcd desktop touchmonitor, 3000 series
Hide thumbs Also See for 1529L:

Advertisement

* Shown with optional peripherals
Touchmonitor User Guide
1529L 15" LCD Desktop Touchmonitor, 3000 series
(Optional Magnetic Stripe Reader, Barcode Scanner,
Customer Display and Biometric available)

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1529L and is the answer not in the manual?

Questions and answers

Summary of Contents for Tyco 1529L

  • Page 1 * Shown with optional peripherals Touchmonitor User Guide 1529L 15” LCD Desktop Touchmonitor, 3000 series (Optional Magnetic Stripe Reader, Barcode Scanner, Customer Display and Biometric available)
  • Page 2: User Guide

    Elo TouchSystems 15” LCD Touchmonitor Optional Magnetic Stripe Reader, Customer Display, Barcode Scanner User Guide Revision G P/N 008603E Elo TouchSystems 1-800-ELOTOUCH www.elotouch.com...
  • Page 3: Trademark Acknowledgments

    Trademark Acknowledgments AccuTouch, CarrollTouch, Elo TouchSystems, IntelliTouch, Tyco Electronics and TE (logo) are trademarks of the Tyco Electronics group of companies and its licensors. Windows is a trademark of the Microsoft group of companies. Other product names mentioned herein may be trademarks or registered trademarks of their respective...
  • Page 4: Table Of Contents

    Solutions to Common Problems ... 39 Appendix A Touchmonitor Safety Care and Handling of Your Touchmonitor ... 41 Appendix B Technical Specifications Touchmonitor Specifications ... 43 15” LCD Touchmonitor (1529L) Dimension ... 44 15” LCD Touchmonitor (1529L) Dimension ... 44 Regulatory Information Warranty...
  • Page 5: Introduction

    NTRODUCTION Product Description The 1529L is a retail terminal designed to present information to the operator and the customer. The 1529L is available in serial and USB versions or combo touch monitor. The 1529L consists of a 15.0” LCD main display with a touchscreen and the following...
  • Page 6: Detailed Lcd Display Performance Requirements

    The hub also supplies two USB ports to the outside of the back of the 1529L for external use. The hub is only used by the USB version of the 1529L. The 1529L is powered by a universal AC power source or 12 VDC from external power source.
  • Page 7: Customer Display

    Customer Display The Customer Display is a twenty character two line vacuum fluorescent display (VFD). It consists of a VFD and VFD controller. Serial Version Optional Parameters Characters per row Number of rows Character configuration Character Height Character width Character configuration Character color MTBF...
  • Page 8: Theory Of Operation

    Specifications Sensor Image Capture Speed Image Transfer Speed Pixel Resolution USB Signaling Type Theory of Operation The USB host initiates communication with the FDU01 using operation commands (Sensor LED On, Fingerprint Capture Start and Stop). Fingerprint data are then cap- tured by the CMOS sensor at a total image size of 356 x 292 with 8-bit gray level.
  • Page 9: D Scanner

    The hub also supplies two USB ports to the outside of the back of the 1529L for external use. The hub is only used by the USB version of the 1529L. The hub meets the following requirements: Specification Full compliance with USB specification 1.0, 1.1 and HID Class Definition Rev 1.0.
  • Page 10: Installation And Setup

    C H A P T E R NSTALLATION AND SETUP This chapter discusses how to install your LCD touchmonitor and how to install Elo TouchSystems driver software. Unpacking Your Touchmonitor Check that the following items are present and in good condition: Touchmonitor USB Cable Video cable...
  • Page 11: Product Overview

    Product Overview Main Unit Note: Shown with optional Biometric & MSR. Rear View Note: Shown with optional Rear Facing Customer Display.
  • Page 12: Side View

    Side View Base Bottom View...
  • Page 13: Kensington™ Lock

    Kensington Lock The Kensington lock is a security device that prevents theft. To find out more about this security device, do to http://www. kensington.com.
  • Page 14: Remove The Cable Cover

    To set up the display, please refer to the following figures and procedures: Remove the Cable Cover The cables are connected at the back of the monitor. cable cover To remove the cover, grasp the lip of the cover and pull towards you until it snaps off.
  • Page 15 AUTION Before connecting the cables to your touchmonitor and PC, be sure that the computer and touchmonitor are turned off. Before connecting the cables to the touchmonitor, route all the cables through the hole in the second as shown in the picture above. 2-11...
  • Page 16 The following illustrations guide you step by step in connecting your touchmonitor using a USB cable connection. Power cord Connect one end of the power cord to the monitor and the other end to wall. Connect the power cable to the power port in the monitor. 2-12...
  • Page 17 Connect one end of the video cable to the rear side of computer and the other to the LCD. Tighten by turning the two thumb screws clockwise to ensure proper grounding. You can select DVI video cable or D-SUB15 video cable. Video cable DVI cable 2-13...
  • Page 18 Speaker cable Connect one end of the speaker cable to the speaker port in the computer and the other end to the port in the monitor. 2-14...
  • Page 19 USB cable Connect one end of the USB cable to the rear side of the computer and the other to the LCD monitor. The USB cable is for optional touch, MSR, CD and Finger Print Reader. Only one USB cable is needed because the device contains a self powered USB 1.1 Hub. Two self powered ports are available for running other USB devices.
  • Page 20: Remove The Cable Cover

    To set up the display, please refer to the following figures and procedures: Remove the Cable Cover The cables are connected at the back of the monitor. cable cover To remove the cover, grasp the lip of the cover and pull towards you until it snaps off.
  • Page 21 AUTION Before connecting the cables to your touchmonitor and PC, be sure that the computer and touchmonitor are turned off. Before connecting the cables to the touchmonitor, route all the cables through the hole in the second as shown in the picture above. 2-17...
  • Page 22 The following illustrations guide you step by step in connecting your touchmonitor using a USB cable connection. Power cord Connect one end of the power cord to the monitor and the other end to wall. Connect the power cable to the power port in the monitor. 2-18...
  • Page 23 Connect one end of the video cable to the rear side of computer and the other to the LCD. Tighten by turning the two thumb screws clockwise to ensure proper grounding. You can select DVI video cable or D-SUB15 video cable. Video cable DVI cable 2-19...
  • Page 24 Speaker cable Connect one end of the speaker cable to the speaker port in the computer and the other end to the port in the monitor. 2-20...
  • Page 25 For USB interface, connect one end of the USB cable to the rear side of the computer and the other to the LCD monitor. For Serial interface, connect one end of the RS-232 cable to the rear side of the conputer and the other to the LCD monitor.
  • Page 26: Replace The Cable Cover

    Replace the Cable Cover Cable cover lip cables Then you have attached all the cables to the monitor, gently bring all the cables toward the standard so they fit under the cover lip. Snap the Cable cover in place over the connections.
  • Page 27: Optimizing The Lcd Display

    • SecuBSP SDK for Windows: 41-100s101-7685871 • SecuBSP SDK for Windows CE: 42-100s101-1155462 • SecuBSP SDK: 51-100s101-5963137 Once the driver setup is complete, the demo program can be run from Touch Monitor Peripherals\Finger Print Readers\Fingerprint Reader 229L 1529L\Demo\ BSPDemo.exe 2-23...
  • Page 28: Magnetic Stripe Reader

    2 Open MS Word. 3 Slide the card through the MSR to view the data. Testing the USB-HID Class MSR 1 On the CD, browse to Touch Monitor Peripherals\Magnetic Stripe Card Readers\Demo. 2 Open the Readme.txt and follow instructions to test the unit.
  • Page 29: Convert Msr From Keyboard Emulation To Hid

    1.3 Click “Quit” to close the window. Rear Facing Customer Display 1. Insert your Elo TouchTools CD. 2. On the CD, browse to Touch Monitor Peripherals\Rear Facing Customer Display\Drivers\USB Drivers. Click on the folder that has the name of your operating system for the necessary drivers.
  • Page 30: Barcode Scanner

    Barcode Scanner 1. Insert your Elo TouchTools CD. 2. On the CD, browse to Touch Monitor Peripherals\Barcode Scanner Startup\Drivers. 3. Double-click on USB7210.msi and follow the prompts given by the setup file. 4. Once you have finished installing the above: Right click on My Computer and click on Properties.
  • Page 31 2) Now scan the barcode below to change your scanning pattern. Using this scanning pattern will allow you to read 2-D barcodes (you can still read 1-D barcodes also). The scanner module also adds a Hall Effect Switch (HE Switch) that enables the unit to automatically set the Trigger mode of the Scan Engine depending on the location of an external magnet (included in scanner cradle).
  • Page 32: Installing The Driver Software

    Windows starts. If Windows detects your touchmonitor, follow the instructions on the screen to install a generic plug-and-play monitor. Refer to the following appropriate section for driver installation instructions.
  • Page 33: Installing The Serial Touch Driver ( Not Applicable Toacoustic Pulse Recognition Monitor)

    NOTE: For Windows 2000 and NT4.0 you must have administrator access rights to install the driver. Make sure the serial connector (RS232) is plugged into the monitor and an open com port on the PC. 1 Insert the Elo CD-ROM in your computer's CD-ROM drive.
  • Page 34: Operation

    C H A P T E R PERATION About Touchmonitor Adjustments Your touchmonitor will not likely require adjustment. Variations in video output and application may require adjustments to your touchmonitor to optimize the quality of the display. For best performance, your touchmonitor should be operating in native resolution, that is 1280 x 1024 at 80k-75 Hz.
  • Page 35: Lcd Function Key

    15” LCD Function Key Controls Power Switch Select Menu Function Turns the display system power on or off. Displays the OSD menus on the screen and used to select (“Clockwise” and “Counter-clockwise” direction) the OSD control options on the screen. Adjusts the decreasing value of the selected OSD control option.
  • Page 36: Controls And Adjustment

    Controls and Adjustment OSD Lock/Unlock You are able to lock and unlock the OSD feature. The monitor is shipped in the unlocked position. To lock the OSD: 1 Press the Menu button and appear displaying “OSD Unlock”. Continue to hold the buttons down for another 2 seconds and the window toggles to “OSD Lock”.
  • Page 37: Osd Control Options

    OSD Control Options Brightness • Background Luminance of the LCD panel is adjusted. Contrast • Adjusts the contrast or the values of color gain (RED, GREEN or BLUE). Sharpness • The sharpness can be adjustable. Phase • Adjusts the phase of the dot clock. Auto Adjust •...
  • Page 38: Power-Save (No Input)

    (see following table). Mode Sleep We recommend switching the monitor off when it is not in use for a long period of time. Display Angle For viewing clarity, you can tilt the LCD forward up 67 to 90 degrees.
  • Page 39 CAUTION In order to protect the LCD, be sure to hold the base when adjusting the LCD, and take care not to touch the screen. 3-35...
  • Page 40: Osd Lock/Unlock

    Controls and Adjustment OSD Lock/Unlock You are able to lock and unlock the OSD feature. The monitor is shipped in the unlocked position. To lock the OSD: 1 Press the Menu button and appear displaying “OSD Unlock”. Continue to hold the buttons down for another 2 seconds and the window toggles to “OSD Lock”.
  • Page 41: Brightness

    OSD Control Options Brightness • Background Luminance of the LCD panel is adjusted Contrast • Gain of R, G, and B signal is adjusted. Sharpness • The sharpness can be adjustable. Phase • The phase of the dot clock is adjusted. Auto Adjust •...
  • Page 42: Recall Defaults

    Recall Defaults • Restore all original factory defaults. OSD Timeout • Adjust how long the OSD menu is displayed. Input Video Select • Select D-SUB Analog, dvi Digital signal. Volume • To increase or decrease the sound level. 3-38...
  • Page 43: Solutions To Common Problems

    ROUBLESHOOTING Suggestion(s) 1. Check that the monitor’s Power Switch is on. 2. Turn off the power and check the monitor’s DC power cord and signal cable for proper connection. Refer to the About Touchmonitor Adjustments section to adjust the brightness.
  • Page 44 This manual contains information that is important for the proper setup and maintenance of your touchmonitor. Before setting up and powering on your new touchmonitor, read through this manual, especially Chapter 2 (Installation), and Chapter 3 (Operation). 1 To reduce the risk of electric shock, follow all safety notices and never open the touchmonitor case.
  • Page 45: Care And Handling Of Your Touchmonitor

    This product consists of devices that may contain mercury, which must be recycled or disposed of in accordance with local, state, or federal laws. (Within this system, the backlight lamps in the monitor display contain mercury.) Waste Electrical and Electronic Equipment(WEEE) Directive In the European Union, this label indicates that this product should not be disposed of with household waste.
  • Page 46 C H A P T E R ECHNICAL PECIFICATIONS B-42...
  • Page 47: Touchmonitor Specifications

    Operating Conditions Temp Humidity Dimensions (HxWxD) Weight (Net) Certifications 1529L 15.0” TFT Active Matrix Panel 304.1(H) x 228(V) mm 0.297(H) x 0.297(V) mm VGA 640 x 350 (70 Hz) VGA 720 x 400 (70 Hz) VGA 640 x 480 (60 / 72 / 75 Hz)
  • Page 48: Lcd Touchmonitor 1529L) Dimension

    15” LCD Touchmonitor(1529L) Dimensions 15” LCD Touchmonitor(1529L) Dimensions B-44...
  • Page 49: Regulatory Information

    REGULATORY INFORMATION I. Electrical Safety Information: A) Compliance is required with respect to the voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified herein will likely result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed.
  • Page 50 D) General Information to all Users: This equipment generates, uses and can radiate radio frequency energy. If not installed and used according to this manual the equipment may cause interference with radio and television communications. There is, however, no guarantee that interference will not occur in any particular installation due to site-specific factors.
  • Page 51 III. Agency Certifications The following certifications have been issued for this monitor: • • • • • • • • • • Laser Notice CAUTION: Laser radiation when open. DO NOT STARE INTO BEAM. Argentina S-Mark Australia C-Tick Canada CUL...
  • Page 52 WARRANTY Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchmonitors and components of the product is 3 (three) years.
  • Page 53 THESE REMEDIES SHALL BE THE BUYER’S EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY. EXCEPT FOR THE EXPRESS WARRANTY SET FORTH ABOVE, SELLER GRANTS NO OTHER WARRANTIES, EXPRESS OR IMPLIED BY STATUTE OR OTHERWISE, REGARDING THE PRODUCTS, THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR MERCHANTABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE.
  • Page 54: Product Information

    To find out more about Elo’s extensive range of touch solutions, visit our Website at www.elotouch.com or simply call the office nearest you: North America Germany Elo TouchSystems Tyco Electronics Raychem GmbH 301 Constitution Drive, (Elo TouchSystems Division) Menlo Park, CA 94025 Finsinger Feld 1...
