Below are the basic steps for programming an Eclipse Master Remote
for use with the Eclipse Dimmer Controller and Eclipse Portable
outdoor heater.
1. To begin you will need to confirm the compatibility.
Turn the Eclipse Standard Dimmer Remote and the Eclipse Master Remote over and confirm they have the same
frequency (916 each) listed on the back label.
2. Select a zone on the 42-channel remote: Zone 1-6
Press the left or right button under the red led lights to select the desired zone. The buttons will move the
selection left or right.
Once selected the LED will go out but the zone will be remembered during the programming process.
You can program multiple remotes to a single zone or change zones for each remote. It is recommended that you
confirm the desired zone before each remote is programming to ensure the remotes are zoned as planned.
Bromic.com
3. Paring the Heater Functions
Locate the P3 button on the back of the standard remote.
Using a paper clip, press the P3 button. You will hear a
continuous beep.
Press the corresponding top heat button (100%) on the
master remote. You will hear an intermittent beep.
The heat functions are now paired.
The programming has been completed for this dimmer.
Turn the remote over and press the top heat button (100%).
