- Page 1 Operation Manual Charles Hanse 508...
-
Page 2: Table Of Contents
Operation Manual INTERIOR Control Panel Battery Charger Location Interior / Exterior Radio GMDSS General Switches Service Engine Thruster Thermal Fuses Anchor fuse Batteries Location Service Engine Thruster Water System Location of fresh water pump Location bilge pump Operation of toilet pumps Operation of shower pumps Operation /Location of Waste tanks/valves Oven/Stove... - Page 3 Autopilot Operation Engine Control Panel Platform and Exterior Tables Operation Outboard Entries Water Entries Diesel Chain marking Sails Main Sail Genoa Σελίδα από...
-
Page 4: Interior
INTERIOR Control Panel Yacht control panels are electronic devices for the remote control of one or more pieces of equipment including windlasses, navigation lights, and thrusters. These devices can control the windlass, thrusters, navigation lights, alarms, video surveillance systems, windshield wipers, engines, fuel, water and oil levels, generators and other equipment. -
Page 5: Interior / Exterior Radio
Interior / Exterior Radio Radio works by transmitting and receiving electromagnetic waves. The radio signal is an electronic current moving back and forth very quickly. A transmitter radiates this field outward via an antenna; a receiver then picks up the field and translates it to the sounds heard through the radio. -
Page 6: Vhf
A very high frequency (VHF) transceiver is a device that is composed of a transmitter and receiver that operates between 30 megahertz (MHz) to 300 megahertz (MHz). The wavelength of a VHF transceiver varies between 39.37 inches (1 m) to 393.70 inches (10 m), mainly depending on the frequency used. - Page 7 12. 16 (Radio, handset mic and wireless handset) Short press to change to priority channel. Press again to return to original channel. The default Priority Channel is CH16. 13. DISTRESS (Radio and wireless handset) Short press to start a distress call, where the nature of distress can be selected from a list.
-
Page 8: Gmdss
GMDSS The Dual Energy Power Supplies and Battery Chargers are designed and developed for charging and maintenance of voltage on lead-acid batteries and provide consistent and uninterrupted power supply (main or backup). You will find it at the chart table area. -
Page 9: General Switches
General Switches This battery master switch functions as a battery isolator and a theft deterrent device. The battery master switch is commonly used in vehicle applications, such as marine, transportation and automotive. The switch has an impact-resistant housing and has a detachable key for added security. -
Page 10: Thermal Fuses
Thermal Fuses Fuses are mechanisms that are inserted into an electrical circuit in order to interrupt the supply of electricity throughout the electrical installation or in individual circuits of the installation, when large current values occur due to short circuit or overload to protect the wiring lines. -
Page 11: Engine
You will find the service batteries on the right side of the chart table and under the living room cushion. Engine You will find the engine battery inside the engine room. Thruster You will find the thruster battery at the skipper cabin under the bed. - Page 12 You will find the fresh water pump at the bow cabin, under the bed. Σελίδα από...
-
Page 13: Location Bilge Pump
Location bilge pump A bilge pump is a water pump used to remove bilge water. You will find it on the floor in front of the stairs. On this yacht the bilge pump is automatic. So keep the corresponding button always on. Operation of toilet pumps The toilet is one of the most used pieces of equipment on your boat. -
Page 14: Operation Of Shower Pumps
When the bowl is empty, Open ( ) the Flush Control again, and continue to pump until all waste has either left the boat, or reached the holding tank (allow 7 complete up/down strokes per meter (yard) length of discharge pipework). -
Page 15: Location Of Gas Valves Inside
In order to turn on the oven or a hob, press the respective switch inwards and turn clockwise. Without letting go light up the hob with a lighter and hold for 5 seconds, then release. If the flame does not hold try holding in the switch for longer. -
Page 16: Location Of Gas Bottles
Location of Gas bottles For more safety if you want to close all system of gas you need to go outside at the starboard side and to open the locker. There, you will find the bottle gas. If you turn the valve clockwise you open the gas system and when you turn the valve from the other direction you close the gas system. -
Page 17: Engine Oil Check
This yacht has two diesel tanks. When you want to change the diesel tank you need to go in front of the stairs and to open the cup. When the valve is on the right you take diesel from the 1 diesel tank and when the valve is go at the stern right side on the left you take diesel from the 2 diesel tank. -
Page 18: Εχterior
ΕΧTERIOR Thruster Controller Thrusters are designed with propellers facing in a sideways direction so when they are turned on, they push the bow or stern of a boat sideways through the water, in either direction. If only one thruster is used, for example in the bow, then the boat will also turn and change orientation. -
Page 19: Autopilot Operation
Autopilot Operation Σελίδα από... - Page 20 Σελίδα από...
-
Page 21: Engine Control Panel
Engine Control Panel An engine control unit (ECU), also commonly called an engine control module (ECM), is a type of electronic control unit that controls a series of actuators on an internal combustion engine to ensure optimal engine performance. How to turn on your engine? You press continuously the power, and then you press the start continuously until the engine stars. -
Page 22: Platform And Exterior Tables Operation
Platform and Exterior Tables Operation On this boat the platform works with this black button. When you want to open it you press down the button and if you want to close it press up the button. With the same way are works the exterior tables. Outboard How to start the outboard: 1. -
Page 23: Entries Diesel
Entries Diesel This yacht hast two diesel tanks. When you want to refill it you need to go at the right and left side in the middle on the deck. There you will find the diesel caps. It writes up diesel. Chain marking The boat has approximately 80 meters chain total. -
Page 24: Sails
Sails Main Sail On this yacht you have full batten main sail with 3 reefs, which means when you want to open the main sail you must release all reefs and pick up the main halyard. This procedure must be simultaneously. If you want to close the main sail you must take back one by one all the reefs and to release the main halyard. -
Page 25: Genoa
Genoa On this yacht you have genoa sheets, which means when you want to open the genoa you must release the genoa sheet and to take out the genoa furling. This procedure must be simultaneously. If you want to close the genoa sail you must release the genoa sheet and to pull the furling rope.
