- Page 1 Operation Manual Alice Bavaria Cruiser 51 2016...
-
Page 2: Table Of Contents
Operation Manual INTERIOR Control Panel AC Distribution Standard 230V Battery Charger Location Interior Radio Exterior Radio GMDSS General Switches Service Engine Thruster Thermal Fuses Anchor fuse Batteries Location Service Engine Thruster Water System Location of fresh water pump/ Location water tank switch Location bilge pump Operation of toilet Operation of shower pumps... - Page 3 Thruster Controller Autopilot Operation Outboard Entries Water Entries Diesel Chain marking Sails Main Sail Genoa Σελίδα από...
-
Page 4: Interior
INTERIOR Control Panel Yacht control panels are electronic devices for the remote control of one or more pieces of equipment including windlasses, navigation lights, and thrusters. These devices can control the windlass, thrusters, navigation lights, alarms, video surveillance systems, windshield wipers, engines, fuel, water and oil levels, generators and other equipment. -
Page 5: Ac Distribution Standard 230V
AC Distribution Standard 230V GENERAL SWITCH WATER HEATER/BOILER OUTLETS HEADS OUTLETS CABIN AND SALON CHARGER, MICROWAVE etc Σελίδα από... -
Page 6: Battery Charger Location
Battery Charger Location A battery charger or recharger is a device that stores energy in a battery by running an electric current through it. The Cristec Charger supplies a maximum capacity wherever you are via auto-ranging. You will find it at the floor under of the chart table. Σελίδα... -
Page 7: Interior Radio
Interior Radio Radio works by transmitting and receiving electromagnetic waves. The radio signal is an electronic current moving back and forth very quickly. A transmitter radiates this field outward via an antenna; a receiver then picks up the field and translates it to the sounds heard through the radio. - Page 8 Σελίδα από...
- Page 9 Σελίδα από...
-
Page 10: Exterior Radio
Exterior Radio Σελίδα από... -
Page 11: Vhf
A very high frequency (VHF) transceiver is a device that is composed of a transmitter and receiver that operates between 30 megahertz (MHz) to 300 megahertz (MHz). The wavelength of a VHF transceiver varies between 39.37 inches (1 m) to 393.70 inches (10 m), mainly depending on the frequency used. -
Page 12: Gmdss
GMDSS The Dual Energy Power Supplies and Battery Chargers are designed and developed for charging and maintenance of voltage on lead-acid batteries and provide consistent and uninterrupted power supply (main or backup). You will find it inside the seat of the chart table. General Switches This battery master switch functions as a battery isolator and a theft deterrent device. -
Page 13: Engine
Engine You will find the main switch that turns off the boat's currents under the stairs. Thruster The switch that turns off the Thruster battery power will be found at the bow cabin inside the closet. Thermal Fuses Fuses are mechanisms that are inserted into an electrical circuit in order to interrupt the supply of electricity throughout the electrical installation or in individual circuits of the installation, when large current values occur due to short circuit or overload to protect the wiring lines. -
Page 14: Batteries Location
Batteries Location A battery is a device that stores chemical energy and converts it to electrical energy. The chemical reactions in a battery involve the flow of electrons from one material (electrode) to another, through an external circuit. The flow of electrons provides an electric current that can be used to do work. -
Page 15: Water System
Water System Freshwater pumps deliver water to fixtures onboard a boat. Pressurized water systems make life aboard more comfortable by providing water "on tap" for dishwashing, showers and other applications. Location of fresh water pump/ Location water tank switch If you want to change the water tanks, you need to go at the stern right toilet, under the bath sink, you will find the valves. -
Page 16: Operation Of Toilet
Operation of toilet The toilet is one of the most used pieces of equipment on your boat. Correct operation of the toilet is essential for the safety and comfort of your crew and craft. Half flush option provides a flush operating for five seconds with approximately two liters water delivery. -
Page 17: Operation /Location Of Waste Tanks/Valves
Operation /Location of Waste tanks/valves A stop-and-waste valve is a fitting that attaches to your irrigation sprinkler lines, and it prevents waste from freezing. When closed, they go to waste tank until you open the valve. As all valves, when it's vertical to the tube connected to it, it is closed and the excrement ends at the waste tanks. -
Page 18: Oven/Stove
Oven/Stove In order to turn on the oven or a hob, press the respective switch inwards and turn clockwise. Without letting go light up the hob with a lighter and hold for 5 seconds, then release. If the flame does not hold try holding in the switch for longer. Also make sure no liquids are spilled on the hobs. -
Page 19: Engine
Engine An engine is some machine that converts energy from a fuel to some mechanical energy, creating motion in the process. Emergency stop IN CASE OF EMERGENCY AND ONLY IN THIS CASE!!! If you need to turn off the engine, you will be directed to the engine room, you have a picture of the engine as in the photo. -
Page 20: Εχterior
ΕΧTERIOR Engine Control Panel An engine control unit (ECU), also commonly called an engine control module (ECM), is a type of electronic control unit that controls a series of actuators on an internal combustion engine to ensure optimal engine performance. Make sure engine is in neutral. -
Page 21: Autopilot Operation
direction you wish the bow to move. Other controls like footswitches or toggle- switches on the throttle can be used. These are normally logically installed, so by engaging the port control, the bow goes port etc. In case of any doubts, try in open waters first. -
Page 22: Outboard
Outboard How to start the outboard: Make sure there is plenty of gasoline/petrol in the outboard fuel tanks. Open the fuel valve. Open the air from the top. Set the outboard to neutral. Place your ignition key. Set the throttle to 2/3 and Pull the rope until the outboard turns. -
Page 23: Entries Water
Entries Water This yacht has three water tanks. When you want to refill the 1 water tank you need to go at the stern-middle right side on the deck. There you will find the water cap. It writes up water. When you want to refill the 2 water tank you need to go at the middle right side on the... -
Page 24: Chain Marking
Chain marking The boat has approximately 80 meters chain total. Every ten (10m) meters the chain marked with colors as follows: 10 meters White. 20 meters Blue. 30 meters Green. 40 meters Yellow. 50 meters Red. The last 10 meters are painted with full Red and secured with Rope. ATTENTION 1. -
Page 25: Sails
Sails Main Sail On this yacht you have furling main sail, which means when you want to open the main sail you must release the furling rope you will take out the outhaul. This procedure must be simultaneously. If you want to close the main sail you must release the outhaul then you will take the furling ropes.
