I N S T A L L A T I O N M A N U A L F O R U N D E R C O U N T E R S ,
W O R K T O P S , S A N D W I C H / S A L A D & P I Z Z A P R E P
TUC-27G
U N D E R C O U N T E R S , W O R K T O P S ,
U N D E R C O U N T E R S , W O R K T O P S ,
S A N D W I C H / S A L A D & P I Z Z A P R E P
S A N D W I C H / S A L A D & P I Z Z A P R E P
(636)-240-2400 • FAX (636)272-2408 • INT'L FAX (636)272-7546 • (800)325-6152
TSSU-48-10
TUC-60D-4
TPP-67D-2
TWT-93
TPP-93D-6
............ www.truemfg.com ............
............ www.truemfg.com ............
TRUE FOOD SERVICE EQUIPMENT, INC.
2001 East Terra Lane • P.O. Box 970 • O'Fallon, Missouri 63366
Parts Department (800)424-TRUE • Parts Department FAX# (636)272-9471
TABLE OF CONTENTS
Installing TSSU Hood Cover
Leveling Cabinet
Cleaning Condenser Coil
*Spanish, German, and French versions included.
CONGRATULATIONS!
You have just purchased the finest commercial
refrigerator available. You can expect many years of
trouble-free operation.
1
2
3
3
4
4
4
5
6
6
7
7
8
9
9
10
11-12
13
14-15
16
