UPRIGHT FREEZER
MODEL: EUF-N2288FF(BS)
Owner's Manual
Please read this manual carefully before
operating your set.
Retain it for future reference.
Record model number and serial number
of the set.
See the label attached on the set and
quote this information to your dealer
when you require service.
For The Warranty Terms & Conditions, Please Refer To Warranty Certificate

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EUF-N2288FF(BS) and is the answer not in the manual?

Questions and answers

Related Manuals for Elba EUF-N2288FF(BS)

Summary of Contents for Elba EUF-N2288FF(BS)

  • Page 1 UPRIGHT FREEZER MODEL: EUF-N2288FF(BS) Owner’s Manual Please read this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the set and quote this information to your dealer when you require service.

  • Page 2: Table Of Contents

    CONTENTS 1. SAFETY PRECAUTIONS……………………………………………………………………………….1 2. INSTALLATION…………………..……………………………………………………………………….2-3 3. PRODUCT DESCRIPTION…………………………………………………………………………………4 3.1 OVERVIEW………………………………………………………………………………………………4 3.2 CONTROL PANEL……………………………………………………………………………………5 3.2.1 TEMPERATURE SETTING……………………………………………………………………5 3.2.2 SUPER FREEZING MODE……………………………………………………………………5 3.2.3 ALARM BUZZER…………………………………………………………………………………5 3.2.4 POWER CUT-OFF MEMORY……………………………………………………………………5 3.2.5 POWER-ON DELAY………………………………………………………………………………5 3.2.6 FAULTY INDICATOR ALARM…………………………………………………………………5 4. DAILY TIPS…………………………………………………………………………………………………6 4.1 FREEZING FRESH FOOD……………………………………………………………………………6 4.2 RECOMMENDATIONS FOR PRESERVATION OF FROZEN FOOD……………………………6 5.

  • Page 3: Safety Precautions

    REMOVE ALL PACKING MATERIALS FROM THIS APPLIANCE BEFORE USING IT. THIS APPLIANCE MUST BE INSTALLED ON A FLAT SURFACE. PLEASE ENSURE THE ELECTRICITY SUPPLY TO THIS APPLIANCE IS DISCONNECTED BEFORE INSTALLING. Please read this instruction carefully. It is advisable to keep this instruction manual in a safe place for future reference.

  • Page 4: Installation

    2. INSTALLATION 1. This appliance is heavy. Care should be taken when moving it. 2. When you transport the appliance, the angle between the compartment body and the ground should not be less than 45º. WARNING: Never put the appliance upside down. 3.
  • Page 5 5. Allow the side of the appliance keep at least 100mm distance when installing and allow the door be open 125° 544mm 641mm 1,443mm 890mm 1,096mm 125° 50mm 100mm 6. Please make sure the appliance levelling feet according to the installation condition, please adjust the feet to the suitable level.

  • Page 6: Product Description

    3. PRODUCT DESCRIPTION 3.1 Overview 1. Control Panel 2. Flip Cover Compartment 3. Drawer Compartment 4. Level feet * The above image is for reference purpose only. The actual appliance maybe slightly different. 3.2 Control Panel 1. Temperature Indicator 2. Super Freezing Mode 3.

  • Page 7: Temperature Setting

    3.2.1 Temperature Setting Temperature can be adjusted by press the “SET” button. When the “SET” button is select, the indicator lights will light up according to temperature setting. Once the temperature is select, the selected temperature will activate after 5 seconds. The freezer thermostat control situated in the appliance regulates the temperature setting.

  • Page 8: Daily Tips

    4. DAILY TIPS 4.1 Freezing fresh food • It is recommended to wrap or cover the food before placing them in the freezer. • The food that you want to freeze must be fresh and in good quality. • Food must be divided into portions according to the family’s daily or meal based consumption needs.

  • Page 9: Cleaning And Maintenance

    5. CLEANING AND MAINTENANCE Always ensure that the electrical mains is turned off and unplug before cleaning the appliance. Do not open the door frequently and too long to save energy. Opening the door for prolonged period may cause the freezer unable to perform optimum cooling. Do not use chemical, steel, wooden or abrasive cleaners to clean the appliance.

  • Page 10: Troubleshooting

    6. TROUBLESHOOTIN Failure Failure Reason Possible Solution The power is off Turn on the power Plug in and turn on the The plug is not plugged in Appliance does not cool power The fuse on the plug has broken Change the fuse Check the thermostat and The thermostat is set to minimum regulate to normal position...

  • Page 11: Main Specification

    7. MAIN SPECIFICATION Model No : EUF-N2288FF(BS) Gross Capacity : 220 Litres Net Capacity : 166 Litres Climatic Type Insulation Class : CLASS I Rated Voltage : 220-240V / 50Hz Rated Current : 0.53 A Refrigerant : R600a (43g) NOTICE This appliance must not be disposed together with domestic waste.
