Summary of Contents for Club 3D CSV-1560
- Page 1 www.club-3d.com...
- Page 2 SenseVision USB Type C MST Charging Dock...
- Page 3 SenseVision USB Type C MST Charging Dock USER INSTRUCTIONS CSV - 1560...
- Page 4 SenseVision USB Type C MST Charging Dock Video output; USB Type C output on source system needs to have Displayport ALT Mode support • Single display - DP output: Supports 4K resolution up to 3840 x 2160 @ 30Hz - HDMI™ output: Supports 4K resolution up to 3840 x 2160 @ 30Hz •...
- Page 5 Step USB Type C MST Charging dock , your laptop, two screens and other devices. This is a USB C device - No driver installation needed.
- Page 6 Power Cable USB C Cable Step Connect your USB Type C MST Dock with your laptop via the bundled USB C Cable...
- Page 7 Step Connect your USB Type C MST Dock with the needed cables to add your devices You can use Club3D Cables: CAC-1310 or CAC-1066 for your video needs...
- Page 8 Ethernet Cable 2x USB A DP Cables HDMI Cables Step This hub offers you 2xFull HD from a single USB C source plus enjoy all the features from a dock I n MST Mode - Mirror/Extended mode supported...
- Page 9 Step Keep your desk clutter free with this Dock...
- Page 10 Headphone USB Stick USB C Cable Step Single mode it supports 4K@30Hz from DP1.2 output I n Single Desktop Mode Only Mirror is possible...
- Page 11 Step Enjoy all your favourite devices via one connection...
- Page 13 Thanks for watching www.club-3d.com...
