Motorcycle Lift JMP Lux 300 EH
For motorcycles and scooters up to an overall weight of 300 kg.
Motorcycle Bike Lift "JMP Lux 300 EH"
EN
Plataforma moto "JMP Lux 300 EH"
ES
Ponte sollevatore per motociclette "JMP Lux 300 EH"
IT
Podośnik motocyklowy "JMP Lux 300 EH"
PL
Motorcykle Lift "JMP Lux 300 EH"
DA
Plošinový zvedák „JMP Lux 300 EH"
CS
Motorheftafel 'JMP Lux 300 EH'
NL
Pont élévateur pour motos „JMP Lux 300 EH"
FR
Johannes J. Matthies GmbH & Co. KG
Hammerbrookstr. 97
20097 Hamburg, Germany
www.jmproducts.eu
info@jmproducts.eu
JM-No. 674 02 92
1
Advertisement
Table of Contents
Related Manuals for JMP Lux 300 EH
Summary of Contents for JMP Lux 300 EH
- Page 1 For motorcycles and scooters up to an overall weight of 300 kg. Motorcycle Bike Lift “JMP Lux 300 EH“ Plataforma moto “JMP Lux 300 EH“ Ponte sollevatore per motociclette “JMP Lux 300 EH“ Podośnik motocyklowy “JMP Lux 300 EH“ Motorcykle Lift “JMP Lux 300 EH“...
-
Page 2: Table Of Contents
Contents: Summary of safety instructions ......................1 Important information for your safety ....................1 Scope of supply ..........................1 Technical data ............................ 1 Area of use ............................1 Installation ............................2 Operation ............................2 Maintenance and safety ........................3 Troubleshooting ..........................3 10. -
Page 3: Summary Of Safety Instructions
Please read these operating instructions carefully and follow the instructions in this manual prior to commissioning the JMP Lux 300 EH lift. Please contact the Matthies Workshop Service in the event of questions. Caution - electrical voltage. Only entrust installation to a specialist company. -
Page 4: Installation
6.1. Installation and commissioning of the JMP Lux 300 EH lift should only be realised by qualified persons. 6.2. The JMP Lux 300 EH lift should only be installed and operated in dry indoor spaces. A level surface measuring a mini- mum of 250 x 200 cm is required for installation. -
Page 5: Maintenance And Safety
8. Maintenance and safety Regular maintenance of the lift is required for safe operation. Please ensure that a complete inspection of the lift is conduc- ted every 24 months at the latest. 8.1. Daily inspection Check the smooth and correct function of the safety catch regularly. - The safety catch should engage independently and smoothly on raising the lift. -
Page 6: 10. Spare Parts
10. Spare parts Maintenance and repair of the JMP Lux 300 EH lift should only be realised by qualified technicians. Ensure when replacing parts that only spare parts are used that correspond fully to the original components in terms of quality and design. Please contact the Matthies Workshop Service or your distribution partner if necessary to discuss further steps. -
Page 7: 11. Circuit Diagrams
11. Circuit diagrams Mains connection Pump Transformer Pump control Magnetic shutdown Button for emergency stop Fuse Button for raising Mains connection Button for lowering Pressure relief valve Upper limit deactivation Transformer AC/DC converter Solenoid 12. Hydraulics Cylinder Lowering valve Pump motor Non-return valve Throttle valve Filter... -
Page 8: 13. Ec Declaration Of Conformity
In case of alteration of the machine, not agreed upon by us, this declaration will lose its validity. Bezeichnung der Maschine: Motorrad Hebebühne Machine Description: Motorcycle Bike Lift Maschinentyp: JMP Lux 300 EH Machine Type: Handelsmarke: Trade name Maschinen-Nr.: Serial Number Einschlägige EG-Richtlinien:...
