Summary of Contents for AEG A18RIW38B
- Page 1 A18RIW38B Original instructions...
- Page 2 Important! It is essential that you read the instructions in this manual before assembling, operating and maintaining the product. Subject to technical modifications.
- Page 3 Belt clip screw Belt clip Belt clip mount screw hole Battery port Lock out lever Handle, insulated gripping surface Direction of rotation selector Switch trigger LED light Anvil...
- Page 4 START STOP...
- Page 6 Remove the battery pack before starting any work on the product. click...
- Page 7 75-100 % 50-75 % 25-50 % 0-25 %...
- Page 8 click...
- Page 10 START START STOP STOP...
- Page 11 Handle (insulated gripping surface)
- Page 12 LOCK UNLOCK...
-
Page 15: Technical Data
TECHNICAL DATA A18RIW38B Type Cordless ratchet wrench Battery voltage 18 V No-load speed 0-250 min Max torque* 74 Nm Max manual breaking torque 156 Nm Weight without battery pack 1.10 kg Weight according to EPTA-Procedure 01/2014 (L1820S) 1.52 kg Recommended ambient operating temperature -18...+50 ºC... - Page 16 Temperatures in excess of 50°C (122°F) reduce the performance of Do not dispose of used battery packs in the household refuse or the battery pack. Avoid extended exposure to heat or sunshine (risk by burning them. AEG Distributors offer to retrieve old batteries to of overheating). protect our environment.
- Page 17 Use only AEG accessories and AEG spare parts. Should components need to be replaced which have not been described, please contact one of our AEG service agents (see our list of guarantee/service addresses). If needed, an exploded view of the product can be ordered. Please state the Article No.
- Page 20 Techtronic Industries Australia Pty Ltd 31 Gilby Road, Mount Waverley, VIC, 3149, Australia Techtronic Industries N.Z. Limited Unit C, 70 Business Parade South, AEG is a registered trade mark used under Highbrook, Auckland 2013, New Zealand license from AB Electrolux (publ). 961096869-01A...
