Three phase inverters 3 to 6 kW
ASW LT-G2 Pro Series
Easy-to-install
• Toolless DC connection via Phoenix
Contact connectors
• Quick setup and commissioning
with AiSWEI apps
• Compact wall mount design
Erneuerbare Energie
Reliable
• International quality standards
• 150 % PV array oversizing for higher
yields
• IP66 rated design for outdoor use
Models:
ASW3K-LT-G2 Pro
ASW4K-LT-G2 Pro
ASW5K-LT-G2 Pro
ASW6K-LT-G2 Pro
User-friendly
• User friendly app interface
• 16 A input current, ideal for bifacial
and large area PV modules
• Wide MPP voltage range
150V-1000V
