- Page 1 FT 5686 Document Number= 2820526918_EN/ 17-05-18.(16:17)
- Page 2 Dear Customer, Please read this user manual first! Thank you for preferring a Cylinda product. We hope that you get the best results from our product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
CONTENTS 1 General safety instructions 1.1 Children's safety ...........................5 1.2 Product safety ..........................6 1.3 Electrical safety..........................6 1.4 Hot surface safety ........................7 1.5 Other ..............................7 2. Instructions for environmental protection 2.1 Compliance with WEEE Directive ..................8 2.2 Disposing of the waste product ................... 8 2.3 Package information ......................... - Page 4 8.4.8 Using starch ............................26 8.4.9 Using limescale remover ........................26 8.4.10 Using bleaches ........................... 26 9. Programmes and auxiliary functions 9.1 Programme selection ......................27 9.2 Programmes ..........................28 9.3 Programme table ........................33 9.4 Auxiliary function selection ....................35 9.4.1 Auxiliary functions ..........................36 9.4.2 Functions/Programmes Selected by Pressing the Function Buttons for 3 Seconds 36 10.
-
Page 5: General Safety Instructions
General safety instructions 1.1 Children's safety • Children under the age of should be kept away unless continuously supervised. • This product can be used by children at and WARNING! above years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack experience and knowledge provided that they are supervised or trained on the safe usage of the product and... -
Page 6: Product Safety
1.2 Product safety • Unplug the product when not in use. • Always have the repairing procedures carried out by the Authorised Service Agent. WARNING! • Do not force open the locked loading door. Door can be opened a few minutes after the washing cycle ends. -
Page 7: Hot Surface Safety
1.4 Hot surface safety • The glass of the loading door gets too hot while washing at high temperatures. Therefore, especially do not allow children touch the glass while washing. WARNING! 1.5 Other • Do not use combustible, flammable and other similar chemicals for product cleaning or other purposes. -
Page 8: Instructions For Environmental Protection
2. Instructions for environmental protection 2.1 Compliance with WEEE Directive This product does not contain harmful and forbidden materials described in the "Regulation on the Control of the Waste Electrical and Electronic Equipment" issued by T.R. Ministry of Environment and Urbanization. It complies with the WEEE Directive. -
Page 9: What You Can Do For Energy Saving
2.4 What you can do for energy saving • Comply with the information in the programme and consumption table section. - If the washing machine is overloaded, its washing performance will drop. CAUTION! - Moreover, noise and vibration problems may occur. Following information will help you use the product in an ecological and energy-efficient manner. -
Page 10: Your Product
4. Your product 4.1 Overview 1- Power cable 2- Top panel 3- Control panel 4- Water discharge hose 5- Loading door 6- Filter cap 7- Adjustable feet 8- Detergent drawer EN / 10 Washing Machine / User’s Manual... -
Page 11: Package Contents
4.2 Package contents Power cable Water discharge hose Transportation safety bolts Mains water inlet hose Liquid detergent container User manual Plastic plug group • Figures in this manual are schematic and may not match the product exactly. NOTE EN / 11 Washing Machine / User’s Manual... -
Page 12: Control Panel
4.3 Control panel Bomull Sköljprogram Bomull Eco Dunplagg Temperatur Smutsnivå På / Av Syntet Sport Snabbtvätt Mörka Kläder Expresstvätt 14 min Centrifug. Mixat Fläckar Ylle Skjortor/Blusar Handtvätt Fintvätt Intensiv/Hygien+ Centrifugering/ Extra Siden/ Förtvä Tyst Läge Start / Paus Tömning Sköljningar Trumren. -
Page 13: Screenshot
4.4 Screenshot Temperature indicator 2 - Temperature symbol 3 - No water symbol 4 - Programme follow-up indicator 5 - Soiling level indicator 6 - Duration information Auxiliary functions light 8 - Child lock enabled symbol 9 - Auxiliary functions light 10 - Delayed start enabled symbol 11 - Door lock is engaged symbol 12 - Auxiliary functions light... -
Page 14: Technical Specifications
5.Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark Cylinda Model name FT 5686 Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++ Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 0,940 Energy consumption of the standard 60°C cotton programme at partial load (kWh) -
Page 15: Installation
6. Installation 6.1 Appropriate installation location • Damaged products cause risks for your safety. - Prior to installation, visually check if the product has any defects on it. WARNING! - If so, do not have it installed. • Do not place the product on a floor without sufficient capacity to carry the load. -
Page 16: Removing Packaging Reinforcement
6.2 Removing packaging reinforcement • Seek someone's help for this procedure. - Risk of getting injured. CAUTION! To remove the packaging reinforcement; a) Tilt the product backwards. b) Remove the packaging reinforcement by pulling the ribbon. 6.3 Removing transportation safety bolts •... -
Page 17: Connecting Water Supply
c) After removing bolts, close the holes with plugs provided in the user manual bag. • Keep the transportation safety bolts in a safe place for reuse when the product needs to be moved again in the NOTE future. • Before moving the product, install the transportation safety bolts in reverse order of the disassembly procedure. -
Page 18: Connecting The Water Draining Hose To The Drain
a) Connect the straight end of the mains inlet hose provided with the product to the cold water tap and the warped end to the water inlet on the back of the product as shown in the figure. b) Tighten all hose nuts by hand securely. Never use a tool when tightening the nuts. -
Page 19: Adjusting The Feet
d) To prevent the waste water to go back into the product again and to ensure easy drainage, do not immerse the end of the hose into the waste water or do not insert it into the drain for more than 15 cm. If it is too long, cut it short. -
Page 20: Electrical Connection
a) Loosen the lock nuts on the feet by hand. b) Adjust the feet until the product stands level and balanced. c) Tighten all lock nuts again by hand. 6.7 Electrical connection • Damaged power cables must be replaced by the Authorised Service Agents. -
Page 21: Initial Use
7. Initial use 7.1 Drum cleaning • Apply drum cleaning without any laundry in the product. NOTE a) Use the Drum Cleaning programme. b) Set the temperature to the level recommended on the special drum cleaning agent package which can be provided from Authorised Service Agents. -
Page 22: Preparing To Wash
8. Preparing to wash 8.1 Sorting the laundry a) Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature. b) Follow instructions on the garment tags. c) Do not wash colours and whites together. New and dark coloured cottons may release a lot of dye. -
Page 23: Preparing Laundry For Washing
8.2 Preparing laundry for washing a) Remove the metal pieces such as support wire, belt buckle or metal buttons or wash the clothes by putting them in a laundry bag or pillow case. b) Take out all substances in the pockets such as coins, pens and paper clips, and turn pockets inside out before washing. -
Page 24: Using Detergent
8.4 Using detergent 8.4.1 Detergent drawer The detergent drawer is composed of three compartments: – (1) for prewash – (2) for main wash – (3) for softener – ( ) in addition, there is a siphon piece in the softener compartment. 8.4.2 Detergent, softener and other cleaning agents a) Add detergent and softener before starting the washing programme. -
Page 25: Choosing The Detergent
8.4.3 Choosing the detergent • Do not use Powdered Soap. • Use only detergents manufactured specifically for washing machines. CAUTION! • Detergent type to be used depends on the fabric type and colour. NOTE a) Use different detergents for coloured and white laundry. b) Wash your delicate clothes only with special detergents (liquid detergent, wool shampoo, etc.) used solely for delicate clothes. -
Page 26: Using Tablet And Capsule Liquid Detergents
8.4.6 Using tablet and capsule liquid detergents a) If tablet is a capsule with liquid detergent, put it directly into the drum before washing. b) Put tablet detergents into the main wash compartment or directly into the drum before washing. 8.4.7 Using softeners a) Pour the softener into the softener compartment of the detergent drawer. -
Page 27: Programmes And Auxiliary Functions
9. Programmes and auxiliary functions 9.1 Programme selection • Programmes are limited with the highest spin speed appropriate for that particular type of fabric. NOTE • When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature. -
Page 28: Programmes
9.2 Programmes • You can see laundry type and washing suggestions on clothing tags. NOTE • Bomull Eco (Cotton Eco) Use to wash your normally soiled, durable cotton and linen laundry. Although it washes longer than all other programmes, it provides high energy and water savings. - Page 29 "Woolens programme of this machine is approved by The Woolmark Company for washing machine-washable woolen products provided that the products are washed in accordance with the instructions on the product tag and the instructions published by the manufacturer of this machine. M13985 In the UK, Ireland, Hong Kong and India, the Woolmark trademark is a Certification trademark.
- Page 30 • Centrifugering+Tömning (Spin+Drain) Use to drain the water in the product. • Sköljprogram (Rinse) Use when you want to rinse or starch separately. • Skjortor/Blusar (Shirts) This programme is used to wash the shirts made from cotton, synthetic and synthetic blended fabrics altogether. It reduces wrinkles. When "Lightly Soiled"...
- Page 31 • Grovtvätt/Fläckar (StainExpert) The machine has a special stain programme which enables the removal of different types of stains in the most effective way. Use this programme only for durable colourfast cotton laundry. Do not wash delicate and pigmenting clothes and laundry in this programme. Before washing, garment tags should be checked (recommended for cotton shirts, trousers, shorts, t-shirts, baby clothes, pyjamas, aprons, table clothes, bed sheets, duvet covers, pillowcases, bath-beach towels, towels, socks, cotton underwear...
- Page 32 Coffee Fruit juice Ketchup Lightly Soiled Red wine Starch Coal • Select the stain programme. • Select the stain you want to clean by locating it on the groups above and selecting dirt level using Dirt Level Adjustment button. For detailed information, see the Programme settings section.
-
Page 33: Programme Table
9.3 Programme table Auxiliary functions Selectable Programme temperature range °C 1600 • • • Cold-90 2,50 Bomull 1600 • • • Cold-90 1,75 1600 • • • Cold-90 0,90 60** 1600 Cold-60 0,940 Bomull Eco 60** 1600 Cold-60 43,5 0,660 40** 1600 Cold-60... - Page 34 ** “Cotton Economic 40°C" and "Cotton Economic 60°C" are standard programmes. These programmes are known as "40°C cotton standard programme" and "60°C cotton standard programme" and indicated with the symbols on the panel. • Water and power consumption may vary from the above table subject to the changes in water pressure, water NOTE hardness and temperature, ambient temperature, type and...
-
Page 35: Auxiliary Function Selection
9.4 Auxiliary function selection • When you try to change an auxiliary function that is not allowed to be selected with the current programme, NOTE indicator light of the relevant auxiliary function will not flash, only an audio warning is given. Frames of available options will be lit. -
Page 36: Auxiliary Functions
9.4.1 Auxiliary functions • Förtvätt (Prewash) A Prewash is only worthwhile for heavily soiled laundry. Not using the Prewash will save energy, water, detergent and time. • Extra+ Sköljningar (Extra Rinse) This function enables the product to make another rinsing in addition to the one already made after the main wash. - Page 37 • Barnlås (Child lock) Use Child Lock function to prevent children from tampering with the product. Thus you can avoid any changes in a running programme. • You can switch on and off the product with On / Off button when the Child Lock is active.
-
Page 38: Programme Setting
10. Programme setting 10.1 Temperature selection a) Whenever a new programme is selected, the recommended temperature for the selected programme appears on the temperature indicator. b) To decrease the temperature, press the Temperature Adjustment button. Temperature will decrease gradually. c) It turns back to the beginning after "Cold" option and arrives at the highest temperature selectable according to the programme. -
Page 39: Soiling Level Selection (Smutsnivå)
• Rinse Hold If you are not going to unload your clothes immediately after the programme completes, you can use rinse hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled when there is no water in the machine. -
Page 40: Programme Steps
10.5 Programme steps a) The symbols below appear on programme follow-up indicator after the programme starts. - Wash - Rinse - Spin - End 2 45 2 45 • "No Water" symbol appears if water is not supplied to the product. Programme steps do not continue. -
Page 41: Programme Options
11. Programme options 11.1 Setting the end time • Do not use liquid detergents without a liquid cup when you activate End Time function. There is the risk of staining of NOTE the clothes. • When the End Time selection is completed, the time appears on the display is the the end time chosen plus the duration of the selected programme. -
Page 42: Cancelling The End Time Setting
Adding laundry during End Time countdown. a) Press the Start / Pause button. b) Wait for loading door to get unlocked. The door symbol disappears when the door is unlocked. c) Open the loading door and add laundry. d) Close the loading door. f) Press the Start / Pause button. -
Page 43: Switching The Machine To Pause Mode
11.2 Switching the machine to pause mode a) Press the Start/Pause button to switch the machine to pause mode while a programme is running. b) Start/Pause light and the programme step light in the programme follow-up indicator will start flashing. c) Loading door symbol will continue flashing until the loading door is unlocked. -
Page 44: Additional Features
12. Additional features 12.1 Activating and deactivating the audio warning a) Press and hold 1st and 2nd auxiliary function buttons for 3 seconds to activate and deactivate the audio warning. b) Programme selection display on the panel will count down as “3, 2, 1”. c) If the audio warning is active it will be deactivated and vice versa. -
Page 45: Maintenance And Cleaning
13. Maintenance and cleaning 13.1 Cleaning the detergent drawer • Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent NOTE accumulation of powder detergent in time. • If more than normal amount of water and softener mixture starts to gather in the softener compartment, the siphon must be cleaned. -
Page 46: Cleaning The Water Intake Filters
13.4 Cleaning the water intake filters There is a filter at the end of each water intake valve at the rear of the product and also at the end of each water intake hose where they are connected to the tap. These filters prevent foreign substances and dirt in the water to enter the product. -
Page 47: Cleaning Dirty Filters
13.5.1 Cleaning dirty filters • Temperature of the water inside the product may rise up to 90 ºC. To avoid the risk of scalding, clean the filter after the water inside the product has cooled down. CAUTION! a) Unplug the product. b) Open the filter cap. -
Page 48: Troubleshooting
14. Troubleshooting Problem Cause Solution Programs do not Start / Pause / Cancel button is • Press Start / Pause / Cancel button. not pressed. start after the It may be difficult to close • Reduce the amount of laundry and make loading door is sure that the loading door is closed the loading door in case of... - Page 49 Problem Cause Solution No water can be Water is inside the invisible • This is not a failure. part of the product. seen in the product during washing. Loading door cannot Loading door lock is activated • Drain the water by running the Pump or because of the water level in Spin programme.
- Page 50 Problem Cause Solution Programme There is unbalanced load in the • Automatic unbalanced load detection system is activated due to the product. time does not unbalanced distribution of the laundry in countdown. (*) the product. Product does not There is unbalanced load in the •...
- Page 51 Problem Cause Solution Washing Odours and bacteria layers • Leave the detergent drawer as well as the loading door of the product ajar are formed on the drum as a performance is result of continuous washing after each washing. Thus, a humid poor: Clothes smell at lower temperatures and/or environment favorable for bacteria...
- Page 52 Problem Cause Solution Detergent residue Detergent was put in wet • Dry the detergent drawer before putting in detergent. drawer. in the detergent drawer. (**) Detergent has gotten damp. • Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
- Page 53 Problem Cause Solution Laundry remains Excessive foam has occurred • Use recommended amount of detergent. and automatic foam wet at the end of absorption system has been the programme. (*) activated due to too much detergent usage. (*) The product does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the product and to its surrounding environment.
- Page 56 • Vi har service i hela landet / Nationwide service • Maskintyp / Model code • Problembeskrivning / Problem description • Gå in på www.cylinda.se / Visit www.cylinda.se • Serienummer / Serial number • Namn och adress / Name and address •...
