- Page 1 QS30 & QS45 Series 1- & 2-Axis Galvo Scanners User Guide...
-
Page 2: Table Of Contents
Chapter 6 Heat Sink Requirements ....................9 Chapter 7 Mounting Requirements ....................10 Chapter 8 Thermal Drift Reduction ....................11 Chapter 9 Limited Warranty ......................12 Chapter 10 Regulatory ........................13 Chapter 11 Thorlabs Worldwide Contacts ..................14 Chapter 12... -
Page 3: Chapter 1 Warning Symbol Definitions
QS30 & QS45 Series Galvo Scanners Chapter 1: Warning Symbol Definitions Warning Symbol Definitions Chapter 1 Below is a list of warning symbols you may encounter in this manual or on your device. Symbol Description Direct Current Alternating Current Both Direct and Alternating Current Earth Ground Terminal Protective Conductor Terminal Frame or Chassis Terminal... -
Page 4: Chapter 2 Safety
QS30 & QS45 Series Galvo Scanners Chapter 2: Safety Safety Chapter 2 2.1. Safety Information The following safety symbols may be used throughout the handbook and on the equipment itself. CAUTION Caution is given when there is a possibility of damage to the product. WARNING Given when there is danger of injury to users. - Page 5 Every servo driver is tuned to accept a specific input voltage range. Using input command voltages outside of this range may cause hardware damage. Thorlabs will not be responsible for damage as a result of command input voltages that exceed the specified voltage range.
-
Page 6: Chapter 3 Description
Description Chapter 3 This manual covers the installation and use of Thorlabs’ QS30 & QS45 Series 1- & 2-Axis Galvo Scanners. Each of these galvos uses a ceramic rotor to reduce rotor inertia and increase rotor stiffness. Increased rotor stiffness increases the galvanometer’s first resonant frequency, which in turn improves step response. -
Page 7: Chapter 4 Quick Connect Guide
Failure to re-tune units after mirror changes can result in hardware damage. If you need to remove the mirror in order to mount your galvanometer, please contact Thorlabs Tech Support for guidance. Note: For systems using more than one galvanometer and servo amplifier, the galvanometer is match-tuned to a specific servo amplifier. -
Page 8: Chapter 5 Specifications
QS30 & QS45 Series Galvo Scanners Chapter 5: Specifications Specifications Chapter 5 5.1. Galvo Scanner Specs Item # Prefix QS30 QS45 Max Beam Diameter 30 mm 45 mm Mirror Substrate Fused Silica Silicon Carbide Step Response Time (0.4° Optical) 1200 µs 1200 µs Mechanical &... -
Page 9: Chapter 6 Connectors
QS30 & QS45 Series Galvo Scanners Chapter 6: Connectors Connectors Chapter 6 There are two connectors on the QS30 and QS45 series galvo scanners. The four-pin connector carries the two differential position detector signals (ib and ia), the AGC voltage (Oscillator Power), and ground. These signals connect to the position detector connector on the servo drive board (see servo drive manual for more details). -
Page 10: Chapter 7 Heat Sink Requirements
QS30 & QS45 Series Galvo Scanners Chapter 7: Heat Sink Requirements Heat Sink Requirements Chapter 7 CAUTION The servo driver board MUST be attached to an additional heat sink before applying power. Failure to provide proper heat sinking could result in damaged components and void the manufacturer’s warranty. -
Page 11: Chapter 8 Mounting Requirements
QS30 & QS45 Series Galvo Scanners Chapter 8: Mounting Requirements Mounting Requirements Chapter 8 The diagram below shows the mounting surface of the galvo. Chassis isolation is usually done with a thin layer of Kapton or Mylar tape wrapped carefully around the mounting area of the galvanometer. The galvanometers should be mounted in a C-type compression clamp built into a rigid structure. -
Page 12: Chapter 9 Thermal Drift Reduction
QS30 & QS45 Series Galvo Scanners Chapter 9: Thermal Drift Reduction Thermal Drift Reduction Chapter 9 All galvanometers are influenced by changes in the thermal environment. The effect is noticed by drift on the zero and gain of the position detector. The galvanometers are inherently superior in performance due to carefully selected electrical components and the thermal insulation between motor stator and position detector. -
Page 13: Chapter 10 Limited Warranty
Thorlabs warrants material and production of the device, excluding the mirror coatings, for a period of 24 months starting with the date of shipment in accordance with and subject to the terms and conditions set forth in Thorlabs’ General Terms and Conditions of Sale, which can be found at: https://www.thorlabs.com/Images/PDF/LG-PO-001_Thorlabs_terms_and_%20agreements.pdf... -
Page 14: Chapter 11 Regulatory
Waste Treatment is Your Own Responsibility If you do not return an “end of life” unit to Thorlabs, you must hand it to a company specialized in waste recovery. Do not dispose of the unit in a litter bin or at a public waste disposal site. -
Page 15: Chapter 12 Thorlabs Worldwide Contacts
QS30 & QS45 Series Galvo Scanners Chapter 12: Thorlabs Worldwide Contacts Chapter 12 Thorlabs Worldwide Contacts For technical support or sales inquiries, please visit us at www.thorlabs.com/contact for our most up-to-date contact information. USA, Canada, and South America UK and Ireland Thorlabs, Inc. - Page 16 www.thorlabs.com...
