True TA1FRI-1S Specifications

For additional information regarding dimensions/specifications, please contact factory.
• Oversized and balanced, environmen-
tally friendly (R404A), refrigeration
system, factory sealed and pre-lubri-
cated for long life.
• Freezer holds -10°F (air off evaporator
coil, -20°F) for the best in food preser-
vation.
• An ideal -10°F for roll-in racks support-
ing frozen food and ice cream.
• Accepts roll-in rack (inboard castor) with
maximum dimensions of
27"W x 29"D x 66"H.
(supplied by others).
• Exterior - 300 series stainless steel
doors, front, back & bottom.
Stainless steel sides.
Toll Free Number • 1-800-325-6152
TA1FRI-1S
• Exterior mounted digital electronic
thermometer features manual defogger.
• Interior - attractive, NSF approved,
white aluminum sides and back. 300
series stainless floor and door liner.
Lifetime guaranteed recessed door
•
handles.
• Door locks standard.
• Three rugged cam-lift hinges per door-
lifetime guaranteed. Designed for easy
product access with a full 180 degree
open capability and stay open feature at
120 degrees.
• Heavy gauge stainless steel ramp
standard.
• Incandescent interior lighting.
Interior bumpers protect cabinet.
•
Parts Department • 1-800-424-TRUE
Roll-In Freezer
Swing Cu.
Model Doors Ft.
SOLID DOORS
TA1FRI-1S 1 37
* Height does not include 1" for system mechanical components.
TA Series
Crated Cabinet Dimensions
HP Amps Weight L
3 / 12.2 485 35 x 34
4
All dimensions rounded up to the nearest 1/8".
FEATURES/BENEFITS
Foamed-in-place polyurethane high
•
density cell insulation (CFC Free).
• Automatic defrost system time-initiated,
temperature-terminated.
• Automatic evaporator fan motor delay
during defrost cycle.
• Minimum wattage heater in cabinet
frame.
• Energy saver switch.
• Standard backguard improves airflow.
• Field reversible door swing.
• Self-contained system.
• Reversible wiper gaskets for positive seal.
Remote cabinets available 14% off list (condensing units
supplied by others; system comes standard with
404A expansion valve and requires R404A refrigerant).
Consult factory technical service dept. for BTU information.
True Website: www.truemfg.com
D H*
1 x 83 3
/ /
2 4
