Tritton AX Micro TRI-BH200 User Manual

Pairing the AX Micro
Pairing mode lasts for 3 minutes, after this period the AX Micro
returns to standby mode.
If the AX Micro is on, turn it OFF
Click and hold the Multi-function Button until LED status
indicator light starts flashing red and blue (appx 7 seconds).
If prompted for a pin number to establish a connection on the
paired Bluetooth device, enter 0000.
When connected, the AX Micro LED status indicator light will
turn off.
Wearing the AX Micro
The AX Micro can be worn on the left or right ear. When the
headset is not in use, you can clip the headset onto the lanyard for
convenience and portability.
Select one of the two rubber grippers that fits most comfortable
and securely.
Place the headset in the ear so that the rubber grippers hold the
headset snugly against the ear wall.
8
CONTENTS
Introduction..........................................................................................................2
Safety Instructions..............................................................................................3
Product Features..................................................................................................4
Package Contents................................................................................................5
Description of Parts............................................................................................6
Charging the AX Micro Battery........................................................................7
Switching the TRI-BH200 ON/OFF..................................................................7
Pairing the AX Micro ..........................................................................................8
Wearing the AX Micro.........................................................................................8
Basic Handsfree Operations for the AX Micro............................................9
Product Specifications....................................................................................11
Product Warranty..............................................................................................12
Phone Support: 800-431-1176
Online Support: www.TRITTONUSA.com
Email Support: support@trittonusa.com
1
Basic Handsfree Operations for the AX Micro
End Call
Answer Call
Long click Multi-Function Button during 'Talk Mode' .
An alert sound will output from both phone and headset.
Short click Multi-Function Button to answer call. NOTE: If the other party ends the call first, the AX Micro will
automatically return to standby mode.
Make Call
Dial and place a call from phone and automatically be transferred
Reject Call
to headset.
Long click Multi-Function Button while phone is ringing.
Short click Multi-Function Button to switch the call to the headset.
NOTE: Some phones will automatically transfer call.
Call Transfer
Short click Multi-Function Button during 'Talk Mode' to transfer
Redial
call from headset to phone or vise versa.
Double click Multi-Function Button when in idle state
NOTE: Double click on some phones will display the number last
called or received. In this case, double click Multi-Function Button Call Waiting
again to redial. Long click Multi-Function Button during 'Talk Mode' to answer
an incoming call.
Voice Dial
Short click Multi-Function Button twice to switch between calls.
Make sure your phone supports voice dialing, that it is activated
NOTE: This function can only be used if user has subscribed for
and the voice tags have been recorded if needed. such services.
Long-click Multi-Function Button when in idle state.
Microphone Mute
Follow the instruction message from phone to complete
Long click the (+) and (-) buttons simultaneously during 'Talk
voice dialing.
Mode' if you do not want to mute your voice for privacy .
Double click Multi-Function Button once.
Long click the (+) and (-) buttons simultaneously to cancel
Volume Control
mute function.
Short click (+) or (-) to adjust volume during handsfree mode.
Reconnect
NOTE: Beep tones will be heard at maximum or minimum volume.
Short click Multi-Function Button twice to reconnect headset
with phone
9 10
Introduction Safety Instructions
Thank you for purchasing the Tritton Bluetooth Headset TRI-BH200, Know the law: Make sure to check to local laws and regulations
the AX Micro. The AX Micro is a high-tech wireless headset for on the use of mobile phones and handsfree equipment in the
handsfree operations at its best. The AX Micro can be connected to areas you intend to use them.
any Bluetooth device that supports either headset or handsfree Extended use of headset devices at high volume levels may
Bluetooth profiles. The AX Micro features a revolutionary finger-like cause hearing damage.
rubber gripping mechanism that holds the headset firmly against When cleaning the device, do not use any type of scouring pad,
the auricle (Outer flap of the ear, also called the pinna), making it abrasive powder or solvents as these may permanently dull the
convenient to wear and comfortable even when used for extended finish.
hours. Additionally, the symmetrical design is one that can be Charge the battery for at least 2 hours before first use.
easily switched from one ear to the other Do not use in prohibited areas such as hospitals or on airplanes.
Do not expose components to extreme temperatures,
prolonged sunlight, moisture or vibrations.
Keep headset and charger cradle away from reach of children.
Do not place metal objects, such as coins or jewelry, on charger
cradle contacts. This may cause a short circuit with the risk of
fire or explosion.
2 3
Product Specifications Product Warranty
Tritton Technologies warrants this product against all defects in
Standards Bluetooth Specification V2.0
material and workmanship for a period of one year from the date of
RF Frequency Range 2402 ~ 2480 MHz
purchase by end user. The conditions for warranty are as follows :
Profiles Supported Headset, Handsfree V1.5
The warranty is valid only if the original receipt issued to the
0.25 ~ 2.5mW (Class 2)
Transmission Power
original purchaser by the dealer is presented with the product
10m (in open space)
Distance to be repaired or replaced.
Li-Ion Polymer The warranty is void if the serial number, date of purchase and
Battery Type
product label had been removed.
Battery Life Standby > 150 hrs,
The warranty does not cover any failure or damage of the
Voice Connection : 4 hrs
product due to normal wear and tear, physical abuse, improper
installation, misuse, modification or repairs by unauthorized
Charging Time < 3 hrs
third parties.
9.5g
Weight
Tritton Technologies does not assume responsibility for any loss
-10 ~ +50°C,
Operating Temp. or damage incurred during shipment and as a result of force of
Rel. Humidity 0 ~ 95% nature.
& Humidity
Tritton Technologies is not liable for any incidental or
Certification BQB, FCC, CE
consequential damages arising from the use or misuse of the
product.
All warranty claims are limited to repair or replacement of the
defective product at the sole discretion of Tritton Technologies.
If Tritton Technologies repairs or replaces the product, the
repaired or replaced product shall be warranted for the
remaining time of the original warranty period. Repair or
replacement may involve the use of functionally equivalent
reconditioned units. Replaced part or product becomes the
property of Tritton Technologies.
Consumable components, such as batteries, are not included in
the warranty obligation.
11 12
Product Features Package Contents
Bluetooth V1.2, 2.0 compliant 1. Tritton Bluetooth Headset TRI-BH200, AX Micro
Supports headset and handsfree profiles for hands free function 2. Charger Cradle
with Bluetooth phones 3. AC/DC Charger Adapter
Unique finger-like rubber grippers to secure the headset on 4. Rubber Grippers (2 sizes)
your ear 5. Lanyard and clip
High performance built-in speaker and microphone 6. User Manual
Red and blue LED status indicator light
More than 4 hours of talk time and 150 hours of standby time
Convenient charging via cradle using standard Mini-USB
1 2 3
(not provided) or AC/DC Adapter
4
6
5
4 5
Disclaimer Notice
The manufacturer shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the furnishing,
performance or use of this material. This document contains proprietary
information, which is protected by international patent applications and
copyright. All rights reserved. No part of this document may be copied,
reproduced or translated without prior written consent of the manufacturer.
The manufacturer reserves the right to revise this publication and to make
changes from time to time in the contents hereof without obligation to
notify any person of such revisions or changes. The manufacturer also
reserves the right to change the specifications without notice.
European CE notice to users and product statements
This product is C E marked according to the provisions of the R & TTE
Directive (99/5/EC). Hereby, Tritton Technologies Co., Ltd, declares that this
product is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. For further information, please contact
http://www.trittonusa.com
FCC notice to users and product statements
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. Operation is
subject to the following two conditions; (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
WEEE Directive 2002/96/EC Art. 11(2)
The use of the symbol indicates that this product may not be
treated as household waste. By ensuring this product is disposed
of correctly, you will help prevent potential negative
consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this
product, please contact your local city office, your household
waste disposal service or the shop where you purchased the
product.
13
Description of Parts
! Improper battery charging can shorten usage times !
Charge the battery for at least 2.5 hours prior to first use.
During charging the headset LED status indicator light will
Multi-Function Button
be red.
When fully charged, the headset LED status indicator light will
be blue.
To connect charger
Volume Down (-) Volume Up (+) 1. Connect the charger cradle with the AC/DC Adapter.
2. Plug cord into power supply
3. Mount headset onto cradle
LED status indicator light
To Turn ON: Click and hold the Multi-Function Button until the
LED status indicator light turns blue and periodically flashes.
technologies To Turn OFF: Click and hold the Multi-Function Button until the
LED status indicator light turns red and then off.
Many of the buttons perform multiple tasks, based upon if they are tapped, or held down.
We call this "Short Click" and "Long Click" respectively throughout the manual.
6
TRI-BH200
Rev 1.0
7
