Sofirn SC21 Pro Manual
Contact us@sofirnlight.com or eu@sofirnlight.com if you need assistance.
Sofirn SC21 Pro is the upgraded version of SC21. It features the latest Anduril 2.0 UI, which is different
from its predecessor. SC21 Pro is a powerful EDC flashlight for indoor or outdoor use. It uses a single
16340 battery and features a USB-C port for convenient charging, super bright LH351D LED with up to
1100 lumens to meet your different lighting uses.
ANSI/NEMA FL1 Chart
Mode
A
Luminous
1100lm
Flux [lm]
Runtime
1h
Beam
131
Distance [m]
Peak
4267
Intensity [cd]
Impact
Resistance
Water
Resistance
Charging
Specification
Thank you for purchasing Sofirn products.
B
C
600lm
450lm
54min
52min
99
82
2450
1667
(up to 2 meter under water, not for diving
USB-C port, input DC 5V 1A
D
E
250lm
150lm
1h18min
1h54min
64
51
1025
642
1m / 3.28 ft.
F
G
80lm
25lm
3h51min
9h52min
35
21
308
116
H
5lm
-
10
23
Advertisement
Table of Contents
Related Manuals for Sofirn SC21 Pro
Summary of Contents for Sofirn SC21 Pro
- Page 1 Contact us@sofirnlight.com or eu@sofirnlight.com if you need assistance. Sofirn SC21 Pro is the upgraded version of SC21. It features the latest Anduril 2.0 UI, which is different from its predecessor. SC21 Pro is a powerful EDC flashlight for indoor or outdoor use. It uses a single 16340 battery and features a USB-C port for convenient charging, super bright LH351D LED with up to 1100 lumens to meet your different lighting uses.
- Page 2 It also turns off automatically if the voltage gets too low. Please recharge the battery. Advanced Temperature Regulation (ATR) technology: As the temperature rises, SC21 Pro is programmed to automatically step down and step up the brightness to prevent over-heating.
- Page 3 Power Indicator The LED indicator in the side switch shows the power status for 5 seconds after turning SC21 Pro on. Green = remaining battery power is good. Red = remaining battery power is poor (less than 30%). Flashing Red = critical power, replace or recharge battery as soon as possible.
- Page 4 means ten clicks but hold the final press. Simple UI Diagram Not everything is covered in the diagram, please read the text. Simple UI By default, the light uses a simple UI. This is useful if you lend the light to someone else, or if you just don't want to bother with any crazy disco modes.
- Page 5 Some other modes and functions are available too. When the light is off, these are the options: - 3C: Battery check mode. (displays voltage once, then turns off) - 4C: Lockout mode. - 10H: Switch to Advanced UI. - 15C or more: Version check. In Lockout mode with Simple UI, there are a few functions: - 1H: Momentary moon - 2H: Momentary low...
- Page 6 Please do not allow children to play with it. Strobe mode may cause seizure in persons with photosensitive epilepsy. Operating SC21 Pro for a long time in high powered modes will quickly heat up the flashlight. This is normal.
- Page 7 Troubleshooting and Maintenance Disassembling the sealed head can damage the flashlight and voids the warranty. Sofirn, Ltd. recommends using high-quality brand batteries. Damage by battery leakage voids the warranty. Remove the battery if the flashlight will not be used for an extended period of time.
