WARRANTY
We strive to offer high-quality products, and we also try our
best to satisfy each and every customer that orders from us with
product or service as needed. We provide 30 days warranty
starting from the time you receive the item. Each customer must
provide a record of their order such as the order number, or
item receipt for any items that are out of the warranty period
you may also still receive replacement parts by purchasing them
with our company if they are available.
Are you having difficulty
with assembly? Missing parts?
Please send email with your order No
customerservice@hulalahome.com
For return, Please check the return policy with
the retailer or MarketPlace you bought from.
Appreciated your purchasing from us.
Pop up your life by our furniture piece!
ITEM NO. HSCLS0408
NOTE:
This brochure contains IMPORTANT safty info. Please read
and keep for future reference.
Advertisement
Related Manuals for HULALA HOME HSCLS0408
Summary of Contents for HULALA HOME HSCLS0408
- Page 1 Are you having difficulty with assembly? Missing parts? Please send email with your order No customerservice@hulalahome.com ITEM NO. HSCLS0408 For return, Please check the return policy with the retailer or MarketPlace you bought from. NOTE: Appreciated your purchasing from us.
- Page 2 PARTS MAINTAINANCE LIST AND WARNING Keep furniture away from heat. Do not clean furniture with harsh cleansers or polish. Do not use detergents, Solvents, abrasives, spray packs or leather cleaner. Use non-color mild soap with warm water clean A: X1 B: X1 C: X1 D: X1...
- Page 3 OVERVIEW...
- Page 4 HARDWARE ASSEMBLY LIST INSTRUCTIONS ①: X3 ②: X6 ③: X6 ④: X6 ⑤: X48 M3*14mm M3*14mm M3*14mm ⑫ ② ⑩: X12 ⑨: X12 ⑥： X6 ⑦: X6 ⑧: X6 ∅8*30mm ∅21mm M6*25mm ⑨ ⑫: X1 ⑪: X1 ⑬: X1 ⑮: X8 ⑯: X8 5*16mm M3*14mm...
- Page 5 ⑪ ⑩ ⑪ STEP 2: With help of adult partner, set the STEP 3: Use allen key #11, bolt #10 to attach feet L panel B vertically, use allen key #11, screw #14 to bottom of panel B, fasten all bolts to secure. to connect panel C/F/D with panel B.
- Page 6 ⑫ ⑨ ⑥ ⑫ ② STEP 4: Turn the assembled unit upright, unfold STEP 5: Place panel A upside down on clean padded surface, back panel H/I then carefully align and slide the 1.insrrt wooden dowel#9 into predrilled hole in panel A by hand. whole back panel into groove along rear edge of 2.Use screwdriver #12 to fasten cam bolt #6 into holes on panel A.
- Page 7 ⑫ ⑨ ⑥ ⑮ ⑦ ⑧ ⑫ STEP 6: Insert cam bolt #7 into panel C/F/D and STEP 7: Insert plastic bracket #15 in between back make sure the opening is facing upwards. Hold the panel and groove on panel A/B/C/D, use screwdriver #12 to fasten screws in order to secure back panel.
- Page 8 ④ ⑫ ⑤ ⑫ ⑫ ⑤ ④ ③ ⑫ J & K STEP 8: Use screwdriver #12 to fasten screws in order STEP 9: Hold the door J/K then use screwdriver #12 to secure handle #1 to door J/K. Use screwdriver #12 and screw #5 to attach door to panel C/F/D.
- Page 9 ⑬ STEP 10: Insert shelf pin #16 to desired level on panel C/ STEP 11: Please be sure to attach the tipping kits and keep it permanantly for safty. Fail to use tipping kits may F/D then insert adjustable shelf E/F. Remove the shelves leads to dangerous circumstances to kids during daily and relocate shelf pin freely as needed during daily use.
