KitchenAid KGCC766RSS Use & Care Manual page 5

Model KGCC566 (36" [91.4 cm] shown)
Model KGCC506 (30" [76.2 cm] not shown)
Control Panel
A. Left front burner control knob
B. Control knob off position
Cooktop
E
D
C
B
A
A. 17,000 BTU burner
B. Surface burner cap
C. Left surface burner grate
D. 6,000 BTU burner (9,100 BTU burner
on 30" [76.2 cm] models)
OFF
C
Lite
Hi
Lo
Med
B
OFF
A
Lite
Hi
Lo
Med
C. Left rear burner control knob
D. Center rear burner control knob
(on 36" [91.4 cm] models only)
E. Model and serial number plate
(under cooktop)
F. 9,100 BTU burner
(on 36" [91.4 cm] models only)
G. Center grate
D
OFF OFF
Lite Lite
Hi Hi
Lo
Med Med
Lite
Hi
Med
F
G
K
H.12,500 BTU burner
I. Right surface burner grate
J. 6,000 BTU burner
K. Control panel
E
Lo
OFF
F
Lo
E. Right rear burner control knob
F. Right front burner control knob
H
I
J
5
