- Page 1 AT ESC INSTRUCTION fixed wing series...
-
Page 2: Specifications
CAUTIOUS Thanks for purchasing T-Motor AT ESC product. Please read this declaration carefully before use, Brushless power systems can be very dangerous and any improper use may cause personal injury and damage to the product and related devices, here we assume you have read and agreed with all the instruction carefully, then follow it strictly. - Page 3 Connect battery to ESC, the motor will Connect battery to ESC, motor will emit“♪123” to indicate the ESC is emit“♪123”to indicate the ESC is powered on normally. powered on normally. The motor will beep number short Then the motor will emit two short “♪...
-
Page 4: Factory Default Parameter
Factory default Value parameter Parameters Helicopter Fix wing Flight mode Fix wing external governor Auto Auto Lipo cells 6~14S calculation calculation Soft cutoff Soft cutoff Voltage cutoff model Hard cutoff low voltage Turn off 2.8V~3.8V Turn off protection value 0~21 Response Time Governor Parameter P... - Page 5 ESC self-test process chirps the wrong number of battery sections, you can adjust this to correct the detection. 3. Voltage Cutoff Type Soft Cutoff : if this item is selected, the ESC will gradually reduce the output to 50% of the full power when the voltage cutoff protection is activated.
- Page 6 standstill from rotation). The higher the value, the more powerful the brake force and the shorter the time (from rotation to standstill) . 12. Timing This item is for adjusting the ESC timing, it’s adjustable between 0 and 30°. 13. Motor Rotation This item is for setting the rotation direction of the motor, it’s “CW”...
- Page 7 ESC will cutoff the output completely and won’t resume it if the regulated value is exceeded again. If you encounter any problem in use, please contact local distributor or T-MOTOR for techinical support.
