Panasonic RQ-218S-E Service Manual

Service Ma
ORDER NO. ARD-7503021C
nual
Portable Cassette Recorder
RQ-218S RQ-218S-E
Mini Cassette Recorder with Built-in Microphone
RS-218S MECHANISM SERIES
Specifications (Catalog specifications for sales)
Power requirement:
Motor:
Frequency response:
Recording system:
Operation:
Tape speed:
Program time:
National Panasonic
Battery; 6V, (four-UM-3, R6 size dry
batteries)
AC; with optional AC adaptor/charg-
er RP-667, RP-667-E in Europe
Car boat battery: with optional
car/boat adaptor RP-916, RP-914-
E in Europe
Rechargeable battery: with optional
rechargeable battery pack RP-093
Electrical governor motor
100~ 8,000 Hz
AC bias
Pushbutton one-touch operation
with Auto-Stop mechanism
4.8cm/s, (1-7/8 ips)
1 hour with C-60 cassette tape
Fast forward time:
Rewind time:
Track system:
Input:
Output:
Speaker:
Dimensions:
Weigt:
Approx. 270 seconds with C-60
cassette tape
Approx. 150 seconds with C-60
cassette tape
2-track monaural recording and
playback
MIC; sensitivity 0.28mV/applicable
microphone impedance 200 ~
6002 (recommended microphone
WM2202, WM2213N)
DC IN; 6V
MONITOR; 89
REMOTE; for start and stop at hand
5cm, (2"') PM dynamic speaker
8.9cm (W) x 14.2cm (H) x3.8cm (D)
550g, 1-1/4 lbs.
Specifications are subject to change without notice for further improvement.
Matsushita Electric Trading Co., Ltd.
P.O. Box 288, Central Osaka Japan
